- Page 1 C-00181_manual-V2...
-
Page 2: Read First
Team Corally. Always take the time to read the instructions carefully in order to follow all the procedures to use your RC model safely for you and for other people and property in the area. -
Page 3: Use Precautions
Always take all necessary precautions when handling products (silicone oil, grease, thread lock, cyanolyte glue, fuel) for the operation of the model. (Refer to the manufacturer’s instructions) For your safety, to keep the warranty and obtain the best performance, always use original CORALLY genuine parts. Contains: LEAD (CAS 7439-92-1) ANTIMONY (CAS 7440-36-0) WARNING: This product contains a chemical known to the state of California to cause cancer and birth defects or other reproductive harm. -
Page 4: Warranty
If material defects or manufacturing faults should arise in a product distributed or manufactured by Team Corally / JSP Group Intl bvba, and purchased by a consumer, we Team Corally / JSP Group Intl bvba acknowl- edge the obligation to correct those faults or defects within the limitations described below. This manufacturers warranty is in addition to, and does not affect, the legal or contractual rights of the consumer which arise from the purchase of such products. - Page 5 • When the battery is empty, recharge it immediately. Do not store an empty battery, the battery will continue to dis- charge, it will fall below the minimum voltage and become unusable. KIT CONTENT (Depends on the selected model) www.corally.com/Downloads/ Transmitter RTR Model (Chassis with Body)
-
Page 6: Car Components
CAR COMPONENTS Front Differential Front Shock Absorber Anti-Roll Bar Suspension Arm Steering Block Steering Link Battery compartment Steering Servo Receiver Box Centre Differential Brushless Motor Speed Controller (ESC) Power Switch Rear Suspension Arm Anti-Roll Bar Wheel Axle Rear Upright Turnbuckle Rear Shock Absorber Rear Differential... - Page 7 QUICK START GUIDE READ THE INSTRUCTIONS CHARGE THE BATTERY INSTALL 4x AA BATTERY CHARGER BATTERY MAKE SURE THAT ALL SCREWS AND NUTS ARE INSTALL THE BATTERY TURN ON THE TRANSMITTER (Always First) TIGHTENED PROPERLY. CONNECT THE BATTERY TO THE ESC CHECK THE FUNCTIONS CHECK THE RADIO SYSTEM RANGE SWITCH ON THE ESC...
-
Page 8: Maintenance
Use 5000cps silicone oil for CENTRE. Use 3000cps silicone oil for REAR. www. corally.com/Chemicals/Silicone-Oils/ GEAR MESH ADJUSTMENT If the gear mesh is not correct, you wear out the spur gear prematurely, the transmission will make noise, give unnecessary load on the motor (higher consump- tion, heating of the transmission). - Page 9 Drain the oil from the shock absorber. Fill the shock absorbers with new silicone oil. Never use any other type of oil. Use 450cps silicone oil for FRONT Use 400cps silicone oil for REAR .www. corally.com/Chemicals/Silicone-Oils/ FILL MOVE WAIT TIGHTEN...
- Page 10 FRONT DRIVE TRAIN - EXPLODED VIEW...
- Page 11 REAR DRIVE TRAIN - EXPLODED VIEW...
-
Page 12: Chassis - Exploded View
CHASSIS - EXPLODED VIEW... -
Page 13: Spare Parts
SPARE PARTS SEE SPARE PARTS AT www.corally.com C-00180-004 C-00180-005 C-00180-008 C-00180-009 Battery - ESC Tray - Composite Wing Mount - Adjustable - Hub - Rear - Composite - 1 pc Steering Block - Pillow Ball Cup - 1 pc Composite - 1 Set... - Page 14 SPARE PARTS C-00180-091 C-00180-098 C-00180-109 C-00180-117 C-00180-122 Spur Gear 46T - Steel - 1 pc Diff Case - FR-RE - Composite Caster Clips Set - 1 to 4.5mm Pivot Ball Adjusting Nut - Alu- Pin 2.5x17mm - Steel - 10 pcs - 1 pc - 1 Set minium - 4 pcs...
- Page 15 SPARE PARTS C-00180-183 C-00180-184 C-00180-188 C-00180-189 C-00180-190 Diff. Gasket - 4 pcs Gear Diff. Pin - Steel - 2 pcs O-Ring - Silicone - 4x8mm - Shock Bladders - Silicone - Shock Washer - 2.5x6x0.5mm - 5 pcs 4 pcs Steel - 10 pcs C-00180-191 C-00180-192...
- Page 16 C-3001-30-06 M3x6 C-3002-40-10 M4X10 C-3003-30-12 M3x12 C-3004-40-04 M4x4 C-31001-40 C-3001-30-08 M3x8 C-3002-40-12 M4x12 C-3003-30-16 M3x16 C-3001-30-10 M3x10 C-3002-40-14 M4x14 C-3003-40-12 M4x12 C-3001-30-12 M3x12 C-3002-40-16 M4x16 C-3001-30-14 M3x14 C-3002-40-18 M4x18 C-3001-30-16 M3x16 C-3001-30-20 M3x20 C-3001-30-25 M3x25 C-3001-30-30 M3x30 C-3001-40-08 M4x8 www.corally.com...
-
Page 17: Option Parts
OPTION PARTS C-00180-046 C-00180-139 C-00180-140 C-00180-141 C-00180-142 Eccentric Bushings Set - Suspension Arm Mount PRO - Suspension Arm Mount PRO - Suspension Arm Mount PRO - Suspension Arm Mount PRO - Composite - 1 Set FR-FR - Aluminum 7075 - 1 pc FR-RE - Aluminum 7075 - 1 pc RE-FR - Aluminum 7075 - 1 pc RE-RE - Aluminum 7075 - 1 pc... - Page 18 OPTION PARTS C-00180-291 C-00180-315 C-00180-361 C-00180-365 C-00180-292 Shock Spring - Hard - Front Steering Block Arms - Graphite Universal Joint Drive Shaft - Universal Joint Drive Shaft - Steering Top Plate - Aluminium - 2 pcs 2.5mm - 2 pcs Buggy - Front - 1 pc Buggy - Rear - 1 pc 3mm - 1 pc...
-
Page 19: Declaration Of Conformity
NOTE DECLARATION OF CONFORMITY EU-Konformitätserklärung/ Déclaration de Conformité UE (in accordance with ISO/IEC 17050-1) / (in Übereinstimmung mit ISO/IEC 17050-1) / (Conformément à la norme ISO/IEC 17050-1) Description : 1/8 PYTHON BUGGY 4WD - RTR Item Number: C-00181 This declaration is issued under the sole responsibility of the manufacturer. Die alleinige Verantwortung für die Ausstellung dieser Erklärung trägt der Hersteller. - Page 20 WWW.CORALLY.COM Team Corally is a registered trademark licensed to JSP Group Intl bvba Geelseweg 80 B-2250 OLEN Belgium • • • Tel: +32 14 25 92 94 info@corally.com •...
