Summary of Contents for Migatronic FOCUS MIG 300
- Page 1 FOCUS MIG 300/400 Brugsanvisning Instruction manual Betriebsanleitung Manuel d'instruction Bruksanvisning Käyttöohje Gebruikershandleiding Manuale d'istruzione Kezelési útmutató Instrukcja obsługi Valid from 2012 week 04 50111824 F...
- Page 2 EC DECLARATION OF CONFORMITY MIGATRONIC A/S Aggersundvej 33 9690 Fjerritslev Denmark hereby declare that our machine as stated below Type: FOCUS MIG As of Week 18 2011 conforms to directives 2006/95/EC and 2004/108/EC. European Standards: EN/IEC60974-1 EN/IEC60974-2 EN/IEC60974-5 EN/IEC60974-10 (Class A) Issued in Fjerritslev 2 May 2011.
- Page 3 ENGLISH WARNING Arc welding and cutting can be dangerous to the user, people working nearby, and the surroundings if the equipment is handled or used incorrectly. Therefore, the equipment must only be used under the strict observance of all relevant safety instructions.
-
Page 4: Product Programme
The power source is switched on with the mains switch (2). Mains connection FOCUS MIG Boost The FOCUS MIG 300 Boost can be connected to a single-phase mains supply from 200-240V and three- phase mains supply from 200-440V. The machine... - Page 5 The torch adjustment is passive without Dialog torch. Lift instructions The FOCUS MIG 300 trolley can only be lifted manually by lifting it in the handle. Lifting hooks can be used at FOCUS MIG 400 trolley for lift with a crane.
-
Page 6: Classic Control Panel
Arc voltage If necessary, the arc length can be adjusted by trimming the voltage. The measured voltage is shown during welding. -key pad Press the and adjust from 13 to 32V (FOCUS MIG 300) 13 to 37V (FOCUS MIG 400) - Page 7 Setting of secondary parameters MIG Press the control knob until the requested parameter is displayed. To return to normal display the key pad for arc voltage or wire feed speed is to be pressed briefly. Arc adjust: Arc-adjust (electronic choke) makes it possible to adjust the speed of reaction to short-circuits.
- Page 8 SOFTWARE It is necessary to read software inside the new control Software reading FOCUS MIG 300 unit by means of a SD card, if the control unit has • Insert the SD-card in the slide in the right side of been exchanged.
- Page 9 1. Insert the SD card again. 2. Replace the SD card. The welding program package is 3. Contact MIGATRONIC Service. locked for another control unit with another serial number/ bar Software on the SD card is code.
-
Page 10: Technical Data
TECHNICAL DATA Power source: FOCUS MIG 300 FOCUS MIG 300 Boost FOCUS MIG 400 Mains voltage 3x400V 3x230/400V 3x400V (50Hz-60Hz) ±15% Mains voltage 1x230V (50Hz-60Hz) ±15% Minimum 4.0MVA short-circuit power Ssc Fuse Mains current, effective 7.6A 10.5A 17.4A Mains current, max. -
Page 11: Maintenance
(See article number in the spare parts list). All forms of transport in connection with a warranty claim fall outside the scope of Migatronic’s warranty and will take place for buyer’s own account and risk. We refer to Migatronic’s warranty conditions at...
