USER'S GUIDE
87B4, 3920, 6750 SERIES
2
Thank You
2
Product Registration
3
Safety Instructions
4
Product View
5-6
Assembly
6-9
Operations
10-16
Maintenance and Care
17-18
Troubleshooting
18
Replacement Parts
19
Warranty
20
Consumer Services
Earn BISSELL Rewards!
Earn BISSELL Rewards!
R
R
egister your
egister your
product today!
product today!
See details on
See details on
back page
back page
Advertisement
Table of Contents
Related Manuals for Bissell PET HAIR ERASER 3 9 2
Summary of Contents for Bissell PET HAIR ERASER 3 9 2
- Page 1 Safety Instructions Product View Assembly Operations 10-16 Maintenance and Care 17-18 Troubleshooting Replacement Parts Warranty Consumer Services Earn BISSELL Rewards! Earn BISSELL Rewards! egister your egister your product today! product today! See details on See details on back page back page...
- Page 2 Your BISSELL vacuum is well made, and we back it with a limited three year warranty. We also stand behind it with a knowledgeable, dedicated Consumer Services department, so, should you ever have a problem, you’ll receive fast, considerate assistance.
-
Page 3: Important Safety Instructions
MPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should be observed, including the following: REAd ALL InStRuctIonS BEFoRE uSIng youR uPRIgHt VAcuuM. Always connect to a polarized outlet (left slot is wider than right). Unplug from outlet when not in use and before conducting maintenance. -
Page 4: Product View
roduct view Handle ® Pet TurboBrush ™ Pet TurboEraser on select models Pet Contour ® Tool Power Switch Upper Tank ™ Easy Empty Dirt Container Washable Pre-Motor Filter Headlight Foot Window Pet Hair Wide Cleaning Foot Lifter w w w . b i s s e l l . c o m Hose and Cord Clip Power Cord... -
Page 5: Attach Handle To Vacuum
ssembly the only tool you’ll need to assemble your vacuum cleaner is a Phillips screwdriver. Attach handle to vacuum Locate the handle and cord wrap. Remove the screw packet taped to the handle. Stand the vacuum upright and from the rear of the unit, slide the base of the handle firmly into the grooves at the top of the vacuum body. -
Page 6: Power Cord Usage
ssembly Attach vacuum hose and tools 1. Line up the tabs on the base of the Twist ‘n Snap hose with the corresponding notches on the hose collar as shown. 2. Turn the Twist ‘n Snap hose to the left to lock the hose into place. -
Page 7: Power Switch
perations Power switch the Power Switch is located just below the handle on the front of the vacuum. Push the rocker switch “on” (I) to vacuum, and “oFF” (o) when cleaning is complete. Handle positions Press the handle release pedal, located on the lower left side of the vacuum, with your foot to place your vacuum into one of three cleaning positions. -
Page 8: Transporting Cleaner
perations Pet Hair Lifter 1. To vacuum carpeting, while vacuum is in upright position flip down until it clicks into place on the front of the foot. Turn height adjustment knob to pet hair setting. 2. To vacuum non-carpet surfaces flip up. Push the yellow release button just above the feature, and it will flip up and out of the way. -
Page 9: Special On-Board Tools
perations Special on-board tools your vacuum is not only a powerful carpet and rug cleaner, it’s also a versatile above floor vacuum cleaner when you select one of the special tools. 1. Raise the handle to the upright position. 2. Grasp the curved hose wand handle to separate from hose wand base. -
Page 10: Maintenance And Care
aintenance and care to maximize your cleaning performance and extend the life of your vacuum, it is very important that you empty your dirt container and check and clean your filters frequently. Perform the following maintenance steps: Empty the dirt container when the dirt reaches the “Full”... - Page 11 aintenance and care Empty dirt container the dirt container needs to be emptied when the dirt reaches the “Full” line on the container. Unplug the vacuum from electrical outlet. Slide the Lock ‘n Seal Lever to the “Unlock” position. Grasp handle and pull the dirt container straight out to remove from the vacuum.
-
Page 12: Check Rotating Floor Brush And Drive Belt
aintenance and care check rotating floor brush and drive belt you should check your vacuum cleaner’s rotating floor brush and drive belt regularly for wear or damage. you should also clean the brush and brush ends of strings, hair and carpet fibers. this type of debris can wrap around the brush and hamper its ability to effectively clean your carpet. -
Page 13: Replace Drive Belt
It is important that you use only genuine BISSELL replacement belts. generic belts may not meet the exacting specifications required to keep your vacuum operating at its peak performance. -
Page 14: Replace Lightbulb
aintenance and care Replace lightbulb 1. Unplug the vacuum from electrical outlet. 2. Using a flat bladed screwdriver, pry the tab on the left and right side out and pull out to remove the lens. 3. Remove the bulb from the socket by grasping the bulb and pulling gently. - Page 15 aintenance and care clearing clogs Low suction or poor pickup may be due to a clog in the vacuum cleaner. If you notice a change in the sound of the motor, check for clogs. 1. Unplug the vacuum from electrical outlet. 2.
-
Page 16: Troubleshooting
aintenance and care cleaning the upper tank 1. Grasp the inner cyclone and twist to the left or to the unlocked marking, until the locking tabs stop the rotation. Pull down from the upper tank to remove it. 2. Wipe out the inside of the upper tank and the inner cyclone with a damp cloth moist- ened with water or a mild cleaning solu- tion. - Page 17 BISSELL product. Please do not return this product to the store. For any questions or concerns, BISSELL is happy to be of service. contact us directly at 1-800-237-7691. w w w . b i s s e l l . c o m Remedies 1. Adjust powerfoot to correct height...
- Page 18 - BISSELL vacuum you may purchase parts from your retailer, by calling BISSELL consumer Services or by visiting our website. Below is a list of com- mon replacement parts. While not all of these parts may have come with your specific model, they are available for purchase if desired.
-
Page 19: Limited Three Year Warranty
Subject to the *EXCEPTIONS AND EXCLUSIONS identified below, upon receipt of the product BISSELL Homecare, Inc. will repair or replace (with new or remanufactured components or products), at BISSELL’s option, free of charge from the date of purchase by the original purchaser, for three years any defective or malfunctioning part. - Page 20 For information about repairs or replacement parts, or questions about your warranty, call: BISSELL consumer Services Or visit the BISSELL website - www.bissell.com When contacting BISSELL, have model number of cleaner available. Please record your Model Number: ___________________ Please record your Purchase Date: ___________________ notE: Please keep your original sales receipt.
