- Page 1 Pet Hair Eraser B A G L E S S U S E R ’ S G U I D E 3 9 2 0 , 6 7 5 0 S E R I E S Safety Instructions Product View Assembly Operations 6-10...
- Page 2 Your BISSELL vacuum is well made, and we back it with a limited one year warranty. We also stand behind it with a knowledgeable, dedicated Consumer Services department, so, should you ever have a problem, you’ll...
-
Page 3: Important Safety Instructions
Do not unplug by pulling on cord. To unplug, grasp ■ the plug, not the cord. D o not handle vacuum cleaner or plug with ■ wet hands. D o not put any object into openings. Do not use with ■... -
Page 4: Product View
roduct view Handle TurboBrush ® Pet Contour Tool ™ Power Switch Upper Tank Easy Empty ™ Dirt Container Washable Pre-Motor Filter Headlight Foot Window Pet Hair Lifter Wide Cleaning Foot w w w . b i s s e l l . c o m Hose and Cord Clip Dusting Brush/ Upholstery Tool... -
Page 5: Attach Handle To Vacuum
Attach handle to vacuum Locate the handle and cord wrap. Remove the screw packet taped to the handle. 2. Stand the vacuum upright and from the rear of the unit, slide the base of the handle firmly into the grooves at the top of the vacuum body. IMpoRtant – before inserting the screws into the handle, slide the cord wrap into the handle. Ensure that the handle and cord wrap fit firmly to the vacuum body. If there are any gaps, continue to push firmly until the handle and cord wrap are flush. 5. Insert 2 of the screws provided (3 total) into the existing holes, attaching the cord wrap and handle to the body of the vacuum. Tighten securely with a screwdriver. 6. Attach the hose and cord clip by snapping it into the handle of the unit. Secure it by... -
Page 6: Attach Vacuum Hose And Tools
ssembly Attach vacuum hose and tools 1. Line up the tabs on the base of the Twist ‘n Snap hose with the corresponding notches on the hose collar as shown. 2. Turn the Twist ‘n Snap hose to the left to lock the hose into place. 3. Connect the curved hose wand to the hose. Grasping the curved hose wand, slide the end of the curved hose wand onto the hose wand base. Snap the hose into the hose clip. notE: the vacuum will not operate effectively unless the curved hose wand is firmly attached. 4. Slide the extension wand and crevice tool together into the storage clip. 5. Slide the dusting brush/upholstery tool into the storage clip. 6. Attach the Pet Contour Tool by aligning the slots at the bottom with the tabs on the upper tank cap, then snap back into the two posts to secure. -
Page 7: Handle Positions
perations Handle positions press the handle release pedal, located on the lower left side of the vacuum, with your foot to place your vacuum into one of three cleaning positions. Upright – For storage and above floor cleaning with tools. normal cleaning – Press handle release pedal once. Position used for most household floor cleaning tasks. low cleaning – With the vacuum in normal cleaning position, press handle release pedal again. Use for reaching under low furniture such as tables, chairs or beds. -
Page 8: Transporting Cleaner
perations Transporting cleaner 1. To move your cleaner from room to room, put the handle in the upright position, tilt the cleaner back on its rear wheels and push forward. 2. The cleaner can also be moved by using the carry handle. Clean filter indicator The clean filter Indicator tells you when the air flow in your vacuum is reduced due to dirty filters or a clog in the hose. The clean filter indicator will remain green while the unit is running until the airflow is reduced by a clog or dirty filter. At that time, it begins to change to red or black. When it is fully red, the airflow is significantly reduced or clogged by a dirty filter. Follow the steps on page 11 to clean your filters. All filters in the vacuum should be cleaned or replaced when the clean filter indicator turns red. If the indicator turns black, it means you have a clog in your hose. To check and remove the clog, remove the hose from the unit by turning the Twist ‘n Snap hose to the right. Try to visually locate the clog. Once you have done this, use a blunt long object such as a broom handle to loosen and remove the debris. Once this is completed, reassemble the hose to the unit. If the indicator remains red or black with the vacuum running, follow the steps on page 15 to check for and clear clogs. notE: When your vacuum is turned off, the clean filter indicator will go to the red color setting. -
Page 9: Special On-Board Tools
running. -
Page 10: Power Cord Usage
perations Power cord usage 1. To use your vacuum, remove the cord and plug it into an electrical outlet. For your convenience, there are two quick release cord wraps for easy cord removal. There is also a cord clip that is part of the upper cord wrap where you can attach the cord when vacuuming. 2. When you are finished cleaning, turn vacuum cleaner off. 3. Unplug power cord by grasping the polarized plug (NOT the cord) and disconnect from outlet. 4. Loop power cord around cord wraps on rear of vacuum cleaner. Be sure to first return the quick release cord wraps back to their original position before wrapping the cord. 5. Clip molded plug to power cord to secure. aintenance and care to maximize your cleaning performance and extend the life of your vacuum, it is very important that you empty your dirt container and check and clean your filters frequently. - Page 11 aintenance and care Empty dirt container the dirt container needs to be emptied when the dirt reaches the “full” line on the container. Unplug the vacuum from electrical outlet Slide the Lock ‘n Seal Lever to the “Unlock” position. Grasp handle and pull the dirt container straight out to remove from the vacuum. Empty dirt into garbage container. notE: Emptying the dirt container after every use will help prevent over filling and ensure that the vacuum is ready to go the next time you clean.
- Page 12 carpet.
- Page 13 3. Place new drive belt over motor pulley and loop other end over rotating floor brush in the space between the bristles. notE: It is important that you use only genuine bISSEll replacement belts. Generic belts may not meet the exacting specifications required to keep your vacuum operating at its peak performance. the use of unbranded belts could lead to early failure of the vacuum and could void your warranty.
-
Page 14: Replace Lightbulb
aintenance and care Replace lightbulb Unplug the vacuum from electrical outlet. Using a flat bladed screwdriver, pry the tab on the left and right side out and pull out to remove the lens. 3. Remove the bulb from the socket by grasping the bulb and pulling gently. Install the new bulb by pushing it gently into the socket until the bulb snaps into place. 4. Reposition the lens and snap it back into place. Maintaining Pet TurboBrush ® the pet turbobrush should be checked regularly for clogs or debris wrapping around the brush. 1. Unplug the vacuum from electrical outlet. 2. If a clog is present or debris is visible, unscrew the two screws on the back of the TurboBrush to remove the faceplate and clear any obstructions. -
Page 15: Clearing Clogs
Clearing clogs low suction or poor pickup may be due to a clog in the vacuum cleaner. If you notice a change in the sound of the motor, check for clogs. 1. Unplug the vacuum from electrical outlet. 2. Empty dirt container. 3. Check upper tank for build up or clogs. - Page 16 aintenance and care cleaning the upper tank Grasp the inner cyclone and twist to the left or to the unlocked marking, until the locking tabs stop the rotation. Pull down from the upper tank to remove it. Wipe out the inside of the upper tank and the inner cyclone with a damp cloth moistened with water or a mild cleaning solution. If you desire to thoroughly clean the louvers located in the upper portion of the inner cyclone, hold the bottom of the cyclone and gently pull straight up on the louvers. The inner cyclone and louvers may be washed using a mild detergent. Be sure it is completely dry before reassembling or damage to your unit may result. Once cleaning is completed, reassemble the louvers over the inner cyclone by sliding it straight down on the top of the inner cyclone. Be sure to line up the tabs when reassembling for proper installation. To replace the inner cyclone, slide it into the upper housing. Be sure to line up the inner cyclone by having the marking (Front) positioned toward the front of the unit. Push the inner cyclone in and rotate it to the right or locked marking until the locking tabs stop the rotation. w w w . b i s s e l l . c o m 8 0 0 .
-
Page 17: Troubleshooting
Vacuum cleaner won’t run possible causes 1. Power cord not plugged in 2. Blown fuse/tripped breaker in home 3. Damaged power cord Vacuum cleaner and tools won’t pick up dirt possible causes 1. Incorrect height adjustment 2. Hose not attached to suction opening 3. Twist 'n Snap hose not securely attached 4. Crack or hole in hose 5. Broken or worn drive belt 6. Rotating floor brush bristles worn 7. Rotating floor brush jammed 8. Clog in vacuum 9. Dirt container full 10. Dirt container not installed properly... -
Page 18: Please Do Not Return This Product To The Store
ISSELL Consumer Services For information about repairs or replacement parts, or questions about your warranty, call: Or visit the BISSELL website - www.bissell.com... - Page 19 - BISSELL vacuum you may purchase parts from your retailer, by calling bISSEll consumer Services or by visiting our website. below is a list of common replacement parts. While not all of these parts may have come with your specific model, they are available for purchase if desired.
-
Page 20: Limited One-Year Warranty
This warranty gives you specific legal rights, and you may also have other rights which may vary from state to state. If you need additional instruction regarding this warranty or have questions regarding what it may cover, please contact BISSELL Consumer Services by E-mail, telephone, or regular mail as described below. limited one year Warranty Subject to the *EXcEptIonS anD EXclUSIonS identified below, upon receipt of the product BISSELL Homecare, Inc.
