- Page 1 INSTRUCTION MANUAL Video Interface and Wireless Connected Car System CADILLAC 2016 PAS TDL2 CHEVROLET/CADILLAC INTERFACE DATA. 2021.05.11 CONTACT W kaptrader.com E kap@kaptrader.com A (05854) A-912 RM Tera-tower2, 201 Songpa-Dearo, Songpa-gu, Seoul, Korea F (+82) 6204 - 0913...
- Page 2 INSTRUCTION MANUAL CAR COMPATIBILITY SHEET BRAND MODEL YEAR ESCALADE 2016~ CADILLAC 2014~...
-
Page 3: Lvds Cable
INSTRUCTION MANUAL COMPONENT Cadillac only Interface Power Cable LVDS Cable RGB NAVI Cable OSD Board ▶ Warning ▶ Warning Please contact your dealer if any component is missing. Please contact your dealer if any component is missing. ... -
Page 4: Hdmi Cable
INSTRUCTION MANUAL COMPONENT KPLAY KPLAY Power Cable HDMI Cable Wifi/Bluetooth Antenna AUX Cable ▶ Warning ▶ Warning Please contact your dealer if any component is missing. Please contact your dealer if any component is missing. ... - Page 5 INSTRUCTION MANUAL INTERFACE SPEC KPLAY INPUT • Wireless APPLE CARPLAY • Wired APPLE CARPLAY • Wired ANDROID AUTO USB storage media • INPUT 1 x DIGITAL RGB IN (HDMI PORT) • • 1 x ANALOG RGB IN (7PIN) • 1 x CVBS FRONT CAM IN 1 x CVBS REAR CAM IN •...
- Page 6 INSTRUCTION MANUAL EXTERNAL DEVICE SPECIFICATIONS DIP SWITCH PROGRAM DIP SWITCH OSD connection POWER/CAN RESISTIVE TOUCH DIGITAL RGB ALNALOG RGB 4PIN Touch FRONT REAR LVDS OUT LVDS IN...
-
Page 7: Dip Switch Setting
INSTRUCTION MANUAL DIP SWITCH SETTING INFORMATION FUNCTION ▲ OFF ▼ ON NAVIGATION Not use AV1 (DVB-T) Not use AV2 (DVD) Not use No function CADILLAC ESCALADE (2016~) CADILLAC CTS (2014~) Car Type... -
Page 8: Connector Pin Assignment
INSTRUCTION MANUAL CONNECTOR PIN ASSIGNMENT PORT INFORMATION Color Signal Assignment Color Signal Assignment Yellow BATTERY Yellow BATTERY POWER Brown REAR DETECT Blue FRONT DETECT /CAN Green LIN IN White LIN OUT Purple Orange REAR VCC FRONT VCC Green MODE Black Black Color Signal Assignment... - Page 9 INSTRUCTION MANUAL EXTERNAL DEVICE SPECIFICATIONS DIP SWITCH DIGITAL POWER MICROPHONE RESISTIVE TOUCH SPEAKER Smartphone 4PIN Touch USB storage WIFI/BLUETOOTH ANTENNA...
- Page 10 INSTRUCTION MANUAL KPLAY CONNECTOR PIN ASSIGNMENT PORT INFORMATION FUNCTION 800x480 Resolution SWITCH 1280x480 Resolution ▶ Warning DIP switch No. 2 has no function POWER Color Signal Assignment Black Color Signal Assignment TOUCH Black Green White...
- Page 11 INSTRUCTION MANUAL KPLAY CONTROL MAIN SCREEN APPLE CARPLAY ANDROID AUTO USB MEDIA SETTINGS Wireless Cable VIDEO Cable MUSIC IMAGE Apple CarPlay – 800 x 480 Android AUTO – 800 x 480 Apple CarPlay – 1280 x 480 Android AUTO –...
- Page 12 INSTRUCTION MANUAL KPLAY CONTROL SETTINGS INFORMATION SELECTION FUNCTION Language Languages You can change the language of the settings screen settings Automatically launch Android AUTO or Apple CarPlay Activation Auto Phone when smartphone is connected Connect (Only for wired Charge only when connecting a smartphone, select icon Disabled connection) to launch Android AUTO or Apple CarPlay...
- Page 13 INSTRUCTION MANUAL KPLAY CONTROL MEDIA CONTROL POWER DIGITAL DIP_S/W ANDROID AUTO APPLE CARPLAY KPLAY Smartphone connection TOUCH Connect AUX to your car and use KPLAY's microphone USB Media INFORMATION Can be used CONTROL NOTICE Wireless connection Use all Apple Apple CarPlay CarPlay Functions Cable...
- Page 14 INSTRUCTION MANUAL KPLAY CONTROL iPhone Wireless connection - Connection method In KPLAY on iPhone 1. Activate Wireless Carplay in KPLAY Settings 2. Choose CarPlay-BT in Bluetooth on iPhone Menu (If Wireless Carplay is enabled, you cannot connect by wire) on iPhone on iPhone 3.
- Page 15 INSTRUCTION MANUAL KPLAY CONTROL If your iPhone fails to connect Make sure Siri is active 2. Delete the Bluetooth and CarPlay records as shown below, 3. disable and re-enable WiFi and Bluetooth, then try to connect again. Forget Bluetooth history Forget CarPlay History ▶...
- Page 16 INSTRUCTION MANUAL KPLAY CONTROL If your Android Phone fails to connect Check if your smartphone has ANDROID AUTO application 2. Replace the cable ANDROID AUTO APP Download Changing the cable ▶ Warning Android Auto may not run even if the cable is not broken ...
-
Page 17: Firmware Update
INSTRUCTION MANUAL FIRMWARE UPDATE 1. Add the firmware file provided in root folder Root folder * of the USB firmware files *Root folder : Top-level folder without adding folder 2. Connect USB to the KPLAY board with the update file. The USB media will be scanned automatically Press the Home button on the top right corner of the USB Media screen and select... -
Page 18: Button Control
INSTRUCTION MANUAL BUTTON CONTROL Change Mode to Interface Screen HOME BUTTON OPERATION FUNCTION Long press OEM screen to interface screen HOME Interface screen to the OEM screen Double click ▶ Warning Screen change sequence : OEM > NAVI > AV1 > AV2 > OEM ... - Page 19 INSTRUCTION MANUAL BLUETOOTH CALL CONTROL B/T Call MENU Option NAVI Config B/T Call Option Image Screen Parking INTERFACE INTERFACE SCREEN SCREEN SCREEN Call Ending...
-
Page 20: Touch Control
INSTRUCTION MANUAL TOUCH CONTROL Touch Calibration Select OSD menu> Utility> Calibration. MENU Config NAVI Factory Reset Execute Cancel IR-Ctrl Calibration Execute Cancel Utility Version Interface version Press and hold the display for longer than 10 seconds. On interface Screen (NAVI, AV1, AV2) + Touch according to the shape coordinates ▶... - Page 21 INSTRUCTION MANUAL PARKING CONTROL Parking Line / OPS Display Parking Line Display Parking Line ON Screen Parking Line OFF Screen OPS Display ON Screen OFF Screen ▶ Warning If there is no sensor, OPS cannot be seen even though it is controlled from OSD menu ...
- Page 22 INSTRUCTION MANUAL PARKING CONTROL FrontCam Rcv Option FrontCam-RcvOpt : ON (1 - 30s) MENU Option NAVI Config FronrCam-RcvOpt Displays the front camera screen for the set time Option (1 - 30second) Image Screen Parking REAR FRONT OEM or OEM or Camera Camera Interface...
- Page 23 INSTRUCTION MANUAL INSTALL MANUAL KPLAY Connection – Screen Setting 2 3 4 5 6 7 8 OSD Board Control DIP switch No.1 is OFF PROGRAM ML2016-PAS-TDL2 VIDEO INTERFACE DIGITAL Screen Setting (In Interface OSD MENE) HDMI CABLE POWER DIGITAL DIP_S/W APPLE CARPLAY 800x480...
- Page 24 INSTRUCTION MANUAL INSTALL MANUAL KPLAY Connection – Touch Setting PROGRAM ML2016-PAS-TDL2 VIDEO INTERFACE DIGITAL HDMI CABLE Connected via HDMI cable OSD Board Control UART TOUCH Setting UART Touch Setting (In Interface OSD MENE) Touch Cursor To Calibrate TOUCH CALIBRATION (IN KPLAY) Touch and hold for 10 seconds + Touch Touch and hold anywhere on the screen for 10 seconds...
- Page 25 INSTRUCTION MANUAL INSTALL MANUAL RGB NAVI Connection DIP switch No.1 is OFF IMAGE PROGRAM DIP_S/W ML2016-PAS-TDL2 VIDEO INTERFACE POWER/CAN TOUCH DIGITAL NAVI FRONT REAR LVDS-OUT LVDS-IN Resistive Analog Touch NAVIGATION...
- Page 26 INSTRUCTION MANUAL INSTALL MANUAL DVB-T / DVD REMOTE CONTROL Connection DIP switch No.2, 3 is OFF IMAGE PROGRAM DIP_S/W ML2016-PAS-TDL2 VIDEO INTERFACE POWER/CAN TOUCH DIGITAL NAVI FRONT REAR LVDS-OUT LVDS-IN 6PIN 7PIN DVB-T DVB-T-IR DVD-IR DVB-T (DMB)
- Page 27 INSTRUCTION MANUAL INSTALL MANUAL EXTERNAL REAR CAMERA IMAGE PROGRAM DIP_S/W ML2016-PAS-TDL2 VIDEO INTERFACE POWER/CAN TOUCH DIGITAL NAVI FRONT REAR LVDS-OUT LVDS-IN REAR POWER +12v REAR CAMERA DETECT...
- Page 28 INSTRUCTION MANUAL INSTALL MANUAL EXTERNAL FRONT CAMERA IMAGE PROGRAM DIP_S/W ML2016-PAS-TDL2 VIDEO INTERFACE POWER/CAN TOUCH DIGITAL NAVI FRONT REAR LVDS-OUT LVDS-IN FRONT POWER FRONT CAMERA DETECT...
- Page 29 INSTRUCTION MANUAL INSTALL MANUAL INSTALLATION IMAGE PROGRAM DIP_S/W ML2016-PAS-TDL2 VIDEO INTERFACE POWER/CAN TOUCH DIGITAL NAVI FRONT REAR LVDS-OUT LVDS-IN OEM POWER CABLE OEM LVDS CABLE...
- Page 30 INSTRUCTION MANUAL INSTALL MANUAL INSTALLATION...
-
Page 31: Osd Control
INSTRUCTION MANUAL OSD CONTROL Basic information MENU Option NAVI Config RearCam-Type ExtDevice Option RearCam-Power Auto Image RearCam-Det GEAR Screen AV Mode Parking FrontCam-Type ExtDevide OSD(On Screen Display) Menu MENU Mode State Interface Status First Menu Second Menu Third Menu OSD(On Screen Display) Board Control •... -
Page 32: Config Menu
INSTRUCTION MANUAL OSD CONTROL Config Menu First Menu Second Menu Third Menu Description DIGITAL Config NAVI-RGB ： Setting the Connected NAVI Model ： Default DVB-T(DMB) ： Setting the Connected DVB-T Model ： Default ： Setting the Connected DVD Model ： Execute Reset Reset to default value of Config menu... -
Page 33: Option Menu
INSTRUCTION MANUAL OSD CONTROL Option Menu First Menu Second Menu Third Menu Description Option FINE Set up manufacturer of woodworking device for UART Touch use NAVI COM Disable feature Original Camera RearCam-Type ExtDevice Equipped with external camera + 12V continuous supply RearCam-Power AUTO + 12V supply only in Rear camera mode... -
Page 34: Image Menu
INSTRUCTION MANUAL OSD CONTROL Image Menu First Menu Second Menu Third Menu Description Brightness Adjust the value of brightness Image Contrast Adjust the value of contrast [AV / REAR / FRONT / DVD / DVBT MENU] Saturation Adjust the value of Saturation [AV / REAR / FRONT / DVD / DVBT MENU] Adjust the value of Hue [AV / REAR / FRONT / DVD / DVBT MENU]... -
Page 35: Screen Menu
INSTRUCTION MANUAL OSD CONTROL Screen Menu First Menu Second Menu Third Menu Description Horizontal Output screen horizontal movement Screen Vertical Output screen vertical movement Scale X Up Reduce / increase output screen width Scale X Down Scale Y Up Reduce / Increase Output Screen Height Scale Y Down Reset Screen menu all reset... - Page 36 INSTRUCTION MANUAL OSD CONTROL Parking Menu First Menu Second Menu Third Menu Description Show OPS Parking OPS Display Do not show OPS Warnings Lang Set warning text language Horizontal Moving a parking line horizontally Vertical Moving a parking line vertically Transparency Parking line transparency Reset...
- Page 37 INSTRUCTION MANUAL OSD CONTROL OSD Menu First Menu Second Menu Third Menu Description Horizontal value OSD Menu Horizontal Shift value Vertical OSD menu vertical Shift value Display Time OSD Menu Display Time (in seconds) value Transparency OSD menu transparency Language OSD menu display language Reset Execute...
- Page 38 INSTRUCTION MANUAL OSD CONTROL IR-Ctrl Menu First Menu Second Menu Third Menu Description IR-Ctrl DVB-T(DMB) Learn Cancel Learn Cancel In order to work with the IR learning function, a separate IR cable is required. 1. In DVB-T / DVD menu, select User in Sys (OSD list) or User (learned contents). 2.
-
Page 39: Utility Menu
INSTRUCTION MANUAL OSD CONTROL Utility Menu First Menu Second Menu Third Menu Description Factory Reset Execute Initialize all settings Utility Calibration Execute Run Calibration mode FDSYOOKRX-180209 Version (Check for future upgrades) Hardware Special Software Software Software Motor Model PIP Model National Version Version... - Page 40 A-912 Rm Tera-tower2, 201 Songpa-daero, Songpa-gu, Seoul, Korea F. (+82) 6204-0913 E. kap@kaptrader.com...
