- Page 1 INSTRUCTION MANUAL Wireless Carplay & Wired Android Auto JEEP 2014 KPLAY JEEP KPLAY DATA. 2021.05.17 CONTACT W kaptrader.com E kap@kaptrader.com A (05854) A-912 RM Tera-tower2, 201 Songpa-Dearo, Songpa-gu, Seoul, Korea F (+82) 6204 - 0913...
- Page 2 INSTRUCTION MANUAL CAR COMPATIBILITY SHEET BRAND MODEL YEAR Cherokee 2014~2017 JEEP Grand Cherokee 2014~2017 CHRYSLER 300C 2016~2017 DODGE 2014~2017...
- Page 3 INSTRUCTION MANUAL COMPONENT BOARD SUB BOARD POWER CABLE FPC CABLE LVDS CABLE WIFI/BT ANTENNA ▶ Warning ▶ Warning Please contact your dealer if any component is missing. Please contact your dealer if any component is missing. ...
- Page 4 INSTRUCTION MANUAL INTERFACE SPEC KPLAY INPUT • Wireless APPLE CARPLAY • Wired APPLE CARPLAY • Wired ANDROID AUTO • USB storage media INPUT • 1 x LVDS IN COMMAND SYSTEM OUTPUT • 1 x LVDS OUT OPERATION TOUCH • VIRTUAL ANALOG TOUCH (4PIN) POWER •...
- Page 5 INSTRUCTION MANUAL EXTERNAL DEVICE SPECIFICATIONS PROGRAM DIP SWICH POWER/CAN LVDS OUT USB USB Smartphone USB storage TOUCH ANTENNA X 2 4PIN Touch...
-
Page 6: Dip Switch Setting
INSTRUCTION MANUAL DIP SWITCH SETTING INFORMATION FUNCTION ▲ OFF ▼ ON No function REAR TYPE External REAR DETECT Wire BACK BUTTON Do not use (MODE CHANGE) No function JEEP - Grand Cherokee (WK) (2016) CHRYSLER - 300C JEEP - Cherokee (KL) CAR TYPE DODGE - RAM (2014) DODGE - RAM (2015) -
Page 7: Connector Pin Assignment
INSTRUCTION MANUAL CONNECTOR PIN ASSIGNMENT PORT INFORMATION Color Signal Assignment Color Signal Assignment Yellow BATTERY Yellow BATTERY POWER Green CAN LOW Orange CAN HIGH /CAN Blue CAN LOW CAN HIGH REAR VCC Brown REAR DETECT Green MODE Black Black PORT INFORMATION Color Signal Assignment... - Page 8 INSTRUCTION MANUAL KPLAY CONTROL MAIN SCREEN APPLE CARPLAY ANDROID AUTO USB MEDIA SETTINGS Wireless Cable VIDEO Cable MUSIC IMAGE Apple CarPlay – 800 x 480 Android AUTO – 800 x 480 Apple CarPlay – 1280 x 480 Android AUTO –...
-
Page 9: Screen View
INSTRUCTION MANUAL SCREEN VIEW KPLAY Settings INFORMATION SELECTION FUNCTION Language Languages You can change the language of the settings screen settings Automatically launch Android AUTO or Apple CarPlay Activation Auto Phone when smartphone is connected Connect (Only for wired Charge only when connecting a smartphone, select icon connection) Disabled to launch Android AUTO or Apple CarPlay... - Page 10 INSTRUCTION MANUAL KPLAY CONTROL MEDIA CONTROL POWER DIGITAL DIP_S/W ANDROID AUTO APPLE CARPLAY KPLAY Smartphone connection TOUCH Connect AUX to your car and use KPLAY's microphone USB Media INFORMATION Can be used CONTROL NOTICE Wireless connection Use all Apple Apple CarPlay CarPlay Functions Cable...
- Page 11 INSTRUCTION MANUAL KPLAY CONTROL iPhone Wireless connection - Connection method In KPLAY on iPhone 1. Activate Wireless Carplay in KPLAY Settings 2. Choose CarPlay-BT in Bluetooth on iPhone Menu (If Wireless Carplay is enabled, you cannot connect by wire) on iPhone on iPhone 3.
- Page 12 INSTRUCTION MANUAL KPLAY CONTROL If your iPhone fails to connect Make sure Siri is active 2. Delete the Bluetooth and CarPlay records as shown below, 3. disable and re-enable WiFi and Bluetooth, then try to connect again. Forget Bluetooth history Forget CarPlay History ▶...
- Page 13 INSTRUCTION MANUAL KPLAY CONTROL If your Android Phone fails to connect Check if your smartphone has ANDROID AUTO application 2. Replace the cable ANDROID AUTO APP Download Changing the cable ▶ Warning Android Auto may not run even if the cable is not broken ...
- Page 14 INSTRUCTION MANUAL CONTROL Returning from the carplay screen to the home screen APPLE CARPLAY ANDROID AUTO ▶ Warning Select the icon on the home screen to operate it, and select the CARPLAY icon or ANDROID AUTO icon again to move to the car play screen...
-
Page 15: Firmware Update
INSTRUCTION MANUAL FIRMWARE UPDATE 1. Add the firmware file provided in root folder Root folder * of the USB firmware files *Root folder : Top-level folder without adding folder 2. Connect USB to the KPLAY board with the update file. The USB media will be scanned automatically Press the Home button on the top right corner of the USB Media screen and select... -
Page 16: Button Control
INSTRUCTION MANUAL BUTTON CONTROL Change Mode to Interface Screen RIGHT SWITCH BUTTON PRESS FUNCTION OEM screen to interface screen Long press STEERING WHEEL Interface screen to the OEM screen RIGHT SWITCH ▶ Screen change sequence : OEM > NAVI > OEM... - Page 17 INSTRUCTION MANUAL BUTTON CONTROL Change Mode to Interface Screen BACK BUTTON PRESS FUNCTION OEM screen to interface screen Short press Interface screen to the OEM screen BACK ▶ Screen change sequence : OEM > NAVI > OEM ▶ Warning To use the back button, DIP-SW 5 must be turned ON(▼) ...
- Page 18 INSTRUCTION MANUAL BUTTON CONTROL Voice Control Button BUTTON PRESS FUNCTION HANG UP Press (In CarPlay Mode) SIRI...
- Page 19 INSTRUCTION MANUAL INSTALL MANUAL KPLAY CONNECTION – SCREEN SETTING LVDS CABLE APPLE CARPLAY LVDS POWER iPhone Wireless connection ANDROID CJ2014-CIP-CP AUTO APPLE CARPLAY Smartphone Cable Connection TOUCH Wifi/Bluetooth Antenna x 2 USB Media Microphone...
- Page 20 INSTRUCTION MANUAL INSTALL MANUAL KPLAY CONNECTION – TOUCH SETTING Touch and hold for 10 seconds Touch Cursor To Calibrate + Touch TOUCH Touch and hold anywhere on the screen for 10 seconds CALIBRATION Touch in the center of the "+" icon (IN KPLAY) ...
- Page 21 INSTRUCTION MANUAL INSTALL MANUAL CONNECTION Removing Front Cover 7mm bolt removal Bolt removal Bolt removal Removing the Back Cover OEM BOARD Removal...
- Page 22 INSTRUCTION MANUAL INSTALL MANUAL CONNECTION OEM FPC CABLE Removal Removing the Back Cover Install the supplied FPC CABLE OEM FPC CABLE Installation Assembly Fix the SUB BOARD to the body...
- Page 23 INSTRUCTION MANUAL INSTALL MANUAL CONNECTION FPC Cable LVDS Cable Connecting FPC Cable and LVDS Cable to SUB BOARD...
