- Page 1 INSTRUCTION MANUAL VIDEO INTERFACE TOYOTA 2018 TD TOYOTA PIONEER H.U DATA. 2020.08.05 CONTACT W kaptrader.com E kap@kaptrader.com A (05854) A-912 RM Tera-tower2, 201 Songpa-Dearo, Songpa-gu, Seoul, Korea F (+82) 6204 - 0913...
- Page 2 INSTRUCTION MANUAL CAR COMPATIBILITY SHEET BRAND MODEL YEAR HEADUNIT CAMRY PRIUS TOYOTA 2018 - 2020 PIONEER COROLLA RAV4...
- Page 3 INSTRUCTION MANUAL COMPONENT PIONEER ONLY 2 JACK by JACK INTERFACE SUB BOARD POWER CABLE LVDS CABLE RGB NAVI CABLE OSD BOARD OPTION 32PIN-50-0.5-P7(Forward) 35PIN-50-0.5-P7(Forward) LVDS FFC CABLE LVDS FFC CABLE UART TX CABLE ▶ Warning ▶ Warning Please contact your dealer if any component is missing. Please contact your dealer if any component is missing.
- Page 4 INSTRUCTION MANUAL INTERFACE SPEC INPUT • 1 x DIGITAL RGB IN (HDMI PORT) • 1 x ANALOG RGB IN (7PIN) • 1 x CVBS FRONT CAM IN • 1 x CVBS REAR CAM IN • 1 x LVDS IN CAMMAND SYSTEM OUTPUT •...
- Page 5 INSTRUCTION MANUAL EXTERNAL DEVICE SPECIFICATIONS PROGRAM DIP SWITCH IMAGE OSD connection Interface error check POWER/CAN RESISTIVE TOUCH DIGITAL RGB ALNALOG RGB 4PIN Touch NAVIGATION IN FRONT(VIDEO) REAR LCD OUT FRONT CAMERA IN REAR CAMERA IN ...
-
Page 6: Dip Switch Setting
INSTRUCTION MANUAL DIP SWITCH SETTING INFORMATION FUNCTION ▲ OFF ▼ ON NAVIGATION Not use AV1 (DVB-T) Not use AV2 (DVD) Not use No function TOYOTA – PIONEER H.U (2018~) CAMRY / RAV4 TOYOTA – PANASONIC H.U (2018~) CAMRY / RAV4 CAR TYPE TOYOTA –... -
Page 7: Connector Pin Assignment
INSTRUCTION MANUAL CONNECTOR PIN ASSIGNMENT PORT INFORMATION Color Signal Assignment Color Signal Assignment POWER Brown REAR DET Blue FRONT DET /CAN Pink REAR VCC FRONT VCC Black Black Color Signal Assignment TOUCH Green Blue White Color Signal Assignment R DATA Green G DATA NAVI... -
Page 8: Button Control
INSTRUCTION MANUAL BUTTON CONTROL Change Mode to Interface Screen HOME / MAP BUTTON PRESS FUNCTION OEM screen to interface screen Long Press Interface screen to the OEM screen HOME Short Press Interface screen to the OEM screen ▶ Screen change sequence : OEM > NAVI > AV1 > AV2 > OEM ▶... - Page 9 INSTRUCTION MANUAL BUTTON CONTROL Change Mode to Interface Screen BACK BUTTON PRESS FUNCTION OEM screen to interface screen Long Press Interface screen to the OEM screen BACK Short Press Interface screen to the OEM screen ▶ Screen change sequence : OEM > NAVI > AV1 > AV2 > OEM ▶...
- Page 10 INSTRUCTION MANUAL BUTTON CONTROL Change Mode to Interface Screen MENU / AUDIO / PHONE / APPS BUTTON PRESS FUNCTION MENU / AUDIO / PHONE / Short press Change mode to OEM screen APPS / INFO PWR·VOL / TUNE·SCROLL SEEK > / < TRACK BUTTON PRESS FUNCTION...
-
Page 11: Touch Control
INSTRUCTION MANUAL TOUCH CONTROL Touch Calibration Select OSD menu ▶ Utility ▶ Calibration. MENU Config NAVI Factory Reset Execute Cancel IR-Ctrl Calibration Execute Cancel Utility Version Interface version Press and hold the display for longer than 10 seconds. On interface Screen (NAVI, AV1, AV2) + Touch according to the shape coordinates... - Page 12 INSTRUCTION MANUAL PARKING CONTROL Parking Line / OPS Display Parking Line Display Parking Line ON Screen Parking Line OFF Screen Horizontal / Vertical MENU Parking REAR Config OPS Display Option Line Display Image Warnings Lang English Screen Horizontal Parking Vertical •...
- Page 13 INSTRUCTION MANUAL PARKING CONTROL FrontCam Rcv Option FrontCam-RcvOpt : ON (1 - 30s) MENU Option NAVI Config FronrCam-RcvOpt Displays the front camera screen for the set time Option (1 - 30second) Image Screen Parking REAR FRONT OEM or OEM or Camera Camera Interface...
- Page 14 INSTRUCTION MANUAL INSTALL MANUAL KPLAY CONNECTION – SCREEN SETTING 2 3 4 5 6 7 8 OSD Board Control DIP switch No.1 is OFF PROGRAM TYT 2018 TD VIDEO INTERFACE DIGITAL Screen Setting (In Interface OSD MENE) HDMI CABLE POWER DIGITAL DIP_S/W APPLE...
- Page 15 INSTRUCTION MANUAL INSTALL MANUAL KPLAY CONNECTION – TOUCH SETTING PROGRAM TYT 2018 TD VIDEO INTERFACE DIGITAL HDMI CABLE Connected via HDMI cable OSD Board Control UART TOUCH Setting UART Touch Setting (In Interface OSD MENE) Touch Cursor To Calibrate TOUCH CALIBRATION (IN KPLAY) Touch 15 times anywhere...
- Page 16 INSTRUCTION MANUAL INSTALL MANUAL ROIK NAVIGATION CONNECTION 2 3 4 5 6 7 8 DIP switch No.2, 3 is OFF IMAGE DIP_S/W PROGRAM TYT 2018 TD VIDEO INTERFACE POWER TOUCH DIGITAL NAVI FRONT REAR LCD-OUT HDMI CABLE ROIK-10 Power Cable (3pin) ANDROID NAVIGATION MODE SW...
- Page 17 INSTRUCTION MANUAL INSTALL MANUAL ROIK NAVIGATION CONNECTION After completing the cable connection, OSD and device setting must be completed. Interface Settings (Control with OSD board) MENU Config NAVI Config NAVI-RGB Option DVB-T (DMB) DIGITAL Image Screen Reset • Config ▶ NAVI RGB ▶ Parking DIGITAL Screen output settings...
- Page 18 INSTRUCTION MANUAL INSTALL MANUAL DVB-T / DVD REMOTE CONTROL CONNECTION 2 3 4 5 6 7 8 DIP switch No.2, 3 is OFF IMAGE DIP_S/W PROGRAM TYT 2018 TD VIDEO INTERFACE POWER TOUCH DIGITAL NAVI FRONT REAR LCD-OUT 6PIN 7PIN DVB-T DVB-T-IR DVD-IR...
- Page 19 INSTRUCTION MANUAL INSTALL MANUAL EXTERNAL FRONT / REAR CAMERA IMAGE DIP_S/W PROGRAM TYT 2018 TD VIDEO INTERFACE POWER TOUCH DIGITAL NAVI FRONT REAR LCD-OUT FRONT POWER CVBS VIDEO FRONT CAMERA DETECT CVBS VIDEO REAR POWER REAR CAMERA Detect ▶ Warning selection WIRE ...
- Page 20 INSTRUCTION MANUAL INSTALL MANUAL LVDS FPC Cable Connection ▲ Remove the bolts ▲ OEM FPC cable removal If you do not assemble the above cables Air conditioning does not work Fold the FFC cable and secure it with the sub board ▲...
- Page 21 INSTRUCTION MANUAL INSTALL MANUAL LVDS FPC Cable Connection ▲ On the supplied SUB board OEM FPC cable ▲ With the marked hole Insert the LVDS connection cable ▲ Provided on the supplied SUB board LVDS cable connection...
- Page 22 INSTRUCTION MANUAL INSTALL MANUAL RAV4 PIONEER H.U INSTALLATION PIONEER HEADUNIT...
- Page 23 INSTRUCTION MANUAL INSTALL MANUAL RAV4 PIONEER H.U INSTALLATION How to connect the LVDS cable How to connect the LVDS cable...
- Page 24 INSTRUCTION MANUAL INSTALL MANUAL RAV4 PIONEER H.U INSTALLATION Connect firmly Taping It is possible to assemble by removing bolts from this part.
-
Page 25: Osd Control
INSTRUCTION MANUAL OSD CONTROL Basic information MENU Option NAVI Config RearCam-Type ExtDevice Option RearCam-Power Auto Image RearCam-Det GEAR Screen AV Mode Parking FrontCam-Type ExtDevide OSD(On Screen Display) Menu MENU Mode State Interface Status First Menu Second Menu Third Menu OSD(On Screen Display) Board Control •... -
Page 26: Config Menu
INSTRUCTION MANUAL OSD CONTROL Config Menu First Menu Second Menu Third Menu Description DIGITAL Config NAVI-RGB ： Setting the Connected NAVI Model ： Default DVB-T(DMB) ： Setting the Connected DVB-T Model ： Default Setting the Connected DVD Model ： ： Execute Reset Reset to default value of Config menu... -
Page 27: Option Menu
INSTRUCTION MANUAL OSD CONTROL Option Menu First Menu Second Menu Third Menu Description Original Camera RearCam-Type Option ExtDevice Equipped with external camera + 12V continuous supply RearCam-Power AUTO + 12V supply only in Rear camera mode + 12V off Detected by CAN RearCam-Det WIRE Detected by Rear-Det Wire... -
Page 28: Image Menu
INSTRUCTION MANUAL OSD CONTROL Image Menu First Menu Second Menu Third Menu Description Brightness Adjust the value of brightness Image Contrast Adjust the value of contrast [AV / REAR / FRONT / DVD / DVBT MENU] Saturation Adjust the value of Saturation [AV / REAR / FRONT / DVD / DVBT MENU] Adjust the value of Hue [AV / REAR / FRONT / DVD / DVBT MENU]... -
Page 29: Screen Menu
INSTRUCTION MANUAL OSD CONTROL Screen Menu First Menu Second Menu Third Menu Description Horizontal Output screen horizontal movement Screen Vertical Output screen vertical movement Scale X Up Reduce / increase output screen width Scale X Down Scale Y Up Reduce / Increase Output Screen Height Scale Y Down Reset Screen menu all reset... - Page 30 INSTRUCTION MANUAL OSD CONTROL Parking Menu First Menu Second Menu Third Menu Description Show parking line Parking Line Display Do not show parking lines Warnings Lang Set warning text language Horizontal Moving a parking line horizontally Vertical Moving a parking line vertically Transparency Parking line transparency Reset...
- Page 31 INSTRUCTION MANUAL OSD CONTROL OSD Menu First Menu Second Menu Third Menu Description Horizontal value OSD Menu Horizontal Shift value Vertical OSD menu vertical Shift value Display Time OSD Menu Display Time (in seconds) value Transparency OSD menu transparency Language OSD menu display language Reset Execute...
-
Page 32: Utility Menu
INSTRUCTION MANUAL OSD CONTROL Utility Menu First Menu Second Menu Third Menu Description Factory Reset Execute Initialize all settings Utility Calibration Execute Run Calibration mode FDSYOOKRX-180209 Version (Check for future upgrades) Hardware Special Software Software Software Motor Model PIP Model National Version Version... - Page 33 A-912 Rm Tera-tower2, 201 Songpa-daero, Songpa-gu, Seoul, Korea F. (+82) 6204-0913 E. kap@kaptrader.com...
