Summary of Contents for Beko D2 7101E
-
Page 1: Washing Machine
Washing Machine D2 7081 E D2 7082 E D2 7101 E D2 7102 E D2 7102 ES... - Page 2 Dear Customer, We hope that your product which has been manufactured in modern facilities and passed through a strict quality control procedure will give you the best results. Therefore, we advise you to read through this manual carefully before using your product and keep it for future reference.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Your Washing Machine Overview ..... . . 4 Specifications ....5 2 Warnings General Safety. -
Page 4: Your Washing Machine
Overview Figure 1 � � 1 - Detergent Drawer 2 - Door 3 - Top Lid 4 - Control Panel 5 - Filter Cap 6 - Height-adjustable feet � � � �... -
Page 5: Specifications
Specifications Models Maximum dry laundry capacity (kg) Height (cm) Width (cm) Depth (cm) Net Weight (kg) Electricity (V/Hz.) Total Current (A) Total Power (W) Spinning cycle (rpm max.) Specifications of this appliance may change without notice to improve the quality of the product. Figures in this manual are schematic and may not match your product exactly. Values stated on the machine labels or in the documentation accompanying it are obtained in laboratory in accordance with the relevant standards. -
Page 6: Warnings
Warnings Please read the following information. Otherwise, there may be the risk of personal injury or material damage. Moreover, any warranty and reliability commitment will become void. General Safety • Never place your machine on a carpet covered floor. Otherwise, lack of airflow from below of your machine may cause electrical parts to overheat. This may cause problems with your washing machine. • If the power cable or mains plug is damaged you must call Authorized Service for repair. -
Page 7: Safety Instructions
companies that produce detergents for your machine. Safety instructions • This appliance must be connected to an earthed outlet protected by a fuse of suitable capacity. • The supply and draining hoses must always be securely fastened and remain in an undamaged state. • Fit the draining hose to a washbasin or bathtub securely before starting up your machine. -
Page 8: Installation
Installation Removing packaging reinforcement Tilt the machine to remove the packaging reinforcement. Remove the packaging reinforcement by pulling the ribbon. Opening the transportation locks C Transportation safety bolts must be removed before operating the washing machine! Otherwise, the machine will be damaged! 1. Loosen all the bolts with a spanner until they rotate freely (“C”) 2. -
Page 9: Connecting To The Water Supply
Connecting to the water supply. Important: • The water supply pressure required to run the machine must be 1-10 bar (0,1 – 1,0 MPa). Attach a pressure-reducing valve if the water pressure is higher. • Connect the special hoses supplied with the machine to the water intake valves on the machine. The hose bearing the “red” sign (90°C max) is the hot water inlet and the hose bearing the “blue” sign (25°C max) is for the cold water inlet. -
Page 10: Electrical Connection
• In case the hose is elevated after laying it on the floor level or close to the ground (less than 40 cm above the ground), water discharge becomes more difficult and the laundry may come out wet. Therefore, the heights described in the figure should be followed. • To prevent dirty water refilling the machine, and to allow for easy discharge, the end of the hose must not be submerged in the drain water. -
Page 11: Initial Preparations For Washing
Initial preparations for washing Sorting the laundry • Sort the laundry according to type of fabric, color, and degree of soiling and permissible water temperature. Always follow the advice on the garment labels. Washing water Wash with Non machine temperature sensitive, short washable programs. Bleach can be Do not use Dry-cleanable used... -
Page 12: Loading Door
Following weights are given as examples. Laundry type Weight (gr.) Bathrobe 1200 Napkin Duvet cover Bed Sheet Pillowcase Tablecloth Towel Evening gown Underclothing Men’s overalls Men’s shirt Men’s pyjamas Blouse Loading door The door is locked during program operation. The door can be opened after some time following the program end. - Page 13 Detergent quantity for prewashing 1/2 measure for main 1 measure washing an additional with hard water 1/2 measure Softener Put the softener into the softener compartment of the detergent dispenser. • Use the proportions recommended on the packet. • Never exceed the (> max <) level marking; otherwise, the softener will be wasted without being used. • If the softener has lost its fluidity, dilute dense softener with water before placing it in the detergent drawer.
-
Page 14: Selecting A Program And Operating Your Machine
Selecting a program and operating your machine Control panel Figure 2 7 - Spin Speed Adjustment Button 8 - Time Delaying Button (+/-) 9 - Temperature Adjustment Button 10 - Start/Pause/Cancel Button 11 - Auxiliary Function Buttons 12 - Program Selection Knob 13 - Display 14 - On / Off Button... -
Page 15: Display Symbols
Display symbols Figure 3 13.a - Spin Speed Indicator 13.b – Temperature Indicator 13.c – Spinning Symbol 13.d – Temperature Symbol 13.e – Remaining Time and Delaying Time Indicator 13.f – Program Indicator Symbols (prewash/mainwash/rinsing/softener/ spinning) 13.g – Economy Symbol 13.h – Time Delaying Symbol 13.i – Door Locked Symbol 13.j – Start Symbol 13.k – Pause Symbol 13.l – Auxiliary Function Symbols 13.m – Water cut-off symbol (According to your machine’s model) Turning the machine on Plug in your machine. Turn the tap on completely. Check if the hoses are connected tightly. Place the laundry in the machine. Put in detergent and softener. Press the “On/Off” button (Figure 2-5). -
Page 16: Additional Programs
not be put in the prewash compartment. Less detergent should be put in the main wash compartment as the veil foams too much because of its meshed structure. Woollens You can wash your machine-washable woollen garments at this program. Wash by selecting the proper temperature according to the labels of your clothes. -
Page 17: Spin Speed Selection
Cold selection is shown with “-” symbol. When the “Temperature” button is pressed after coming to the Cold selection, the maximum temperature of the program you have selected will be displayed. To decrease the temperature, press the “Temperature” button again. Normally soiled, white cottons and linens. (Ex.: 90˚C coffee table covers, tablecloths, towels, bed sheets) Normally soiled, fade proof colored linens, cottons or synthetic clothes... -
Page 18: Program Selection And Consumption Table
Program selection and consumption table Programme Cottons Cottons 60** Cottons Super Intensive Babycare Synthetics Synthetics Delicate Woollens Hand wash Mini • Selectable * Automatically selected, not cancellable. ** Energy Label programme (EN 60456) *** Spin speed of Mini 30 program in washing machines with spin speeds more than 1400rpm is maximum 1400 rpm. Water and power consumption and programme duration may differ from the table shown, subject to changes in water pressure, water hardness and temperature, ambient temperature, type and amount of laundry, selection of auxiliary functions, and fluctuations in the supply voltage. -
Page 19: Auxiliary Functions
Auxiliary functions Auxiliary function selection keys • Depending on the program, you can select the desired auxiliary function by pressing the buttons. • Select the required auxiliary functions before starting the program. • Some combinations cannot be selected together. (Ex.: Prewash and Quick Wash. • Symbol of the selected auxiliary function (Figure 3-2l) will light up. Auxiliary function selection If an auxiliary function that should not be selected together with a previously selected function is chosen, the first selected function will be cancelled and... -
Page 20: Starting The Program
Time delay With the “Time delay” function you can delay the program start up to 24 hours. Setting can be made in intervals of 30 minutes. 1. Open the loading door, place the laundry inside and fill with detergent. 2. Set the washing program, temperature, spin speed and, if required, select the auxiliary functions. -
Page 21: Changing The Selections After The Program Has Started
Main wash Main wash symbol will light up to indicate that the main wash cycle has started. Rinse Rinse symbol lights up at the beginning of the rinse step. Softener Softener symbol lights up at the beginning of softener step. Spin Spin symbol will light up at the beginning of the final spin, during “Spin” and “Pump” special programs. -
Page 22: Ending The Program Through Canceling
on the screen whenever any button is pressed while the machine is child- locked. To deactivate the child-proof lock, press the 2nd and 4th auxiliary function buttons for 3 sec. “C:OFF” (Child lock is deactivated) label appears on the screen. Ending the program through canceling “Start/Pause/Cancel” button (Figure 2-8) is pressed for 3 seconds to cancel the program. Start symbol (Figure... -
Page 23: Quick Instructions For Daily Use
Quick instructions for daily use Preparation 1. Turn the tap on completely. Check if the hoses are connected tightly. 2. Place the laundry in the machine. 3. Add detergent and softener. Starting 1. Press the “On/Off” button. 2. Select the program and the temperature. 3. If desired (according to your machine’s model): – select any auxiliary function, – adjust the spin speed, – set the time delay, 4. - Page 24 After the program is finished Program indicator symbols on the screen will remain lit after the program is finished. “End” will appear on the screen. 1. Open the loading door and take out the laundry when the door locked symbol on the display fades out. 2. Press the “On/Off” button. 3. Turn the water tap off. 4. Remove any folds in the rubber seal on the loading door and check for debris.
-
Page 25: Cleaning And Care
Cleaning and care Detergent drawer Remove any powder residue buildup in the drawer. To do this; 1. Press the dotted point on the siphon in the softener compartment and pull towards you until the compartment is removed from the machine. C If more than a normal amount of water and softener mixture starts to gather in the softener compartment, the siphon must be cleaned. -
Page 26: Draining Any Remaining Water And Cleaning The Pump Filter
• If the filters are very dirty, you can pull them out by means of pliers and clean them. • Take out the filters on the flat ends of the water intake hoses together with the gaskets and clean thoroughly under streaming water. • Replace the gaskets and filters carefully and tighten the hose nuts by hand. Draining any remaining water and cleaning the pump filter Filter system in your machine prevents... - Page 27 from the filter. • Loosen pump filter (anticlockwise) until water starts to flow out of it. Direct the flowing water into the container you have placed in front of the filter. You can use a piece of cloth to absorb any spilled water. • When there is no water left, turn the pump filter until it is completely loose and remove it.
-
Page 28: Troubleshooting
Troubleshooting Problem Cause Machine may have Program switched to self cannot be protection mode due to started or an infrastructure problem selected. (such as line voltage, water pressure, etc.). There may be some water in your machine when you Water in the receive it. This is from the machine. - Page 29 The water being taken Improper position of the in is directly drain hose. discharged. No water can This is not a problem. The be seen in water level is not visible the machine from the outside of the during machine. washing.
- Page 30 In the case of a paused countdown while taking in water: Timer will not countdown until the machine is filled with the correct amount of water. In the case of a paused countdown at the heating step: It continuously Time will not count washes.
- Page 31 - Using insufficient amount of detergent for a long time, - Washing at low Washing temperatures for a long performance is time, poor: - Using insufficient Laundry turns amount of detergent for gray hard waters (soil can stick to the laundry), - Using excessive amount of detergent (detergent can stick to the laundry).
- Page 32 The amount, brand and storage conditions of the detergent used might not be appropriate. Detergent might have been put in the wrong compartment. Machine filter may be It does not clogged. rinse well. Drain hose may be folded. Check the drain hose. Intermediate spins may be skipped.
- Page 33 If you put detergent in the prewash compartment although you have not selected a prewash cycle, the machine can take this detergent during rinsing or softener step. You may have added too much softener. The detergent dispenser might be problematic. Water may be siphoned (pulling the softener into the washer early) during the fill or rinse cycles. There might be problems with the valves.
- Page 34 Machine does work. Nothing is displayed on the screen. The machine did not start after the program was selected and the «Start/Pause/Cancel» button was pressed. The Rinse Symbol amongst the Program Indicator Symbols is flashing. (Subject to the model of your machine, water cut-off symbol may light up too) The plug might not be plugged in the mains outlet.
