- Page 1 Washing Machine D2 8101 ES User’s Manual D2 8101 E...
- Page 2 Please read this manual first! Dear Customer, We hope that your product which has been manufactured in modern facilities and passed through a strict quality control procedure will give you the best results. Therefore, we advise you to read through this manual carefully before using your product and keep it for future reference.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Your Washing Machine Auxiliary functions ......19 Time display ........19 Overview ..........4 Starting the Program ......20 Specifications ........5 Progress of program ......20 Changing the selections after the 2 Warnings program has started ......21 General Safety ........6 Switching the machine to standby mode First Use ..........6 Intended use ........6 Child-proof lock .........21... -
Page 4: Your Washing Machine
Your Washing Machine Overview 1 - Detergent Drawer 4 - Control Panel 2 - Door 5 - Filter Cap 3 - Top Lid 6 - Height-adjustable feet 4 - EN... -
Page 5: Specifications
Specifications Models D2 8101 E D2 8101 ES Maximum dry laundry capacity (kg) Height (cm) Width (cm) Depth (cm) Net Weight (±4 kg) 220-240 V / 50Hz Electricity (V/Hz.) Total Current (A) 2000-2350 Total Power (W) 1000 1000 Spinning cycle (rpm max.) Specifications of this appliance may change without notice to improve the quality of the product. Figures in this manual are schematic and may not match your product exactly. -
Page 6: Warnings
Warnings Please read the following information. for 3 seconds to cancel the program Otherwise, there may be the risk of set in your machine before calling personal injury or material damage. the authorized service. Moreover, any warranty and reliability commitment will become void. First Use • To prepare your machine for General Safety washing, carry out your first washing • Never place your machine on a process without loading your carpet covered floor. Otherwise,... -
Page 7: Safety Instructions
companies that produce detergents be solved by information in the for your machine. operating manual: • This appliance is not intended for Turn off the machine, unplug it, turn use by persons (including children) off the water tap and contact an with reduced physical, sensory authorized service agent. or mental capabilities, or lack of experience and knowledge, unless If there are children in your they have been given supervision... -
Page 8: Installation
Installation Removing packaging bolts in a safe place to reuse when the washing machine needs to be reinforcement moved again in the future. Tilt the machine to remove the C Never move the appliance without packaging reinforcement. Remove the the transportation safety bolts packaging reinforcement by pulling the properly fixed in place! ribbon. -
Page 9: Connecting To The Water Supply
Connecting to the water supply. Important: • The water supply pressure required to run the machine must be 1-10 bar (0,1 – 1,0 MPa). Attach a pressure-reducing valve if the water pressure is higher. • Models with a single water inlet • Connect the special hoses supplied should not be connected to the with the machine to the water intake hot water tap. -
Page 10: Electrical Connection
• In case the hose is elevated B The appliance must not be operated after laying it on the floor level or unless it is repaired! There is the risk close to the ground (less than of electric shock! 40 cm above the ground), water discharge becomes more difficult Destroying the packaging and the laundry may come out wet. material Therefore, the heights described in Packaging material can be dangerous to... -
Page 11: Initial Preparations For Washing
Initial preparations for washing Sorting the laundry • Empty pockets and remove all foreign objects such as coins, pens • Sort the laundry according to type and paper clips. If possible, turn of fabric, color, and degree of soiling pockets out and brush. and permissible water temperature. • Place small items like infants’ Always follow the advice on the socks and nylon stockings, etc. -
Page 12: Loading Door
Following weights are given as Detergent, softener and other clean- examples. ing agents Add detergent and softener before Laundry type Weight (gr.) starting the washing programme. Bathrobe 1200 Never open the detergent dispenser Napkin drawer while the washing programme is Duvet cover running! When using a programme without Bed Sheet... -
Page 13: Liquid Detergent
Eliminating lime formation Detergent • When required, use only appropriate quantity lime removers developed specifically for prewashing 1/2 measure for washing machines and always for main washing 1 measure follow the instructions on the an additional 1/2 with hard water package. measure Softener Put the softener into the softener compartment of the detergent dispenser. -
Page 14: Selecting A Program And Operating Your Machine
Selecting a Program and Operating Your Machine Control panel Figure 2 7 - Spin Speed Adjustment Button 11 - Auxiliary Function Buttons 8 - Time Delaying Button (+/-) 12 - Program Selection Knob 9 - Temperature Adjustment Button 13 - Display 10 - Start/Pause/Cancel Button 14 - On/Off Button 14 - EN... -
Page 15: Display Symbols
Display symbols appear. Press "Start/Pause/Cancel" button (Figure 2-10) to start the Figure 3 program. Main programs Depending on the type of textile, the following main programs are available: Each of these main programs comprise of a complete washing process, 13.a - Spin Speed Indicator including washing, rinsing and, if 13.b - Temperature Indicator required, spin cycles. -
Page 16: Additional Programs
• Mix 40 put in the main wash compartment as loose knit fabrics (lace) foam too much You can use this program to wash due to its meshed structure. cottons and synthetics together. There • Yünlü (Woollens) is no need to sort them. You can wash your machine-washable • Intensive woolen garments on this program. Wash You can wash your durable and heavily by selecting the proper temperature soiled clothes on this program. -
Page 17: Spin Speed Selection
program appears on the temperature indicator (13b). Economy Symbol To change the temperature, press Shows energy saving programs and the temperature button (Figure temperature selections. 2-9). Temperature decreases in 10° As "Intensive" and "Hygiene" programs increments. are long programs with higher Cold selection is shown with “-” symbol. temperature selections to ensure hygiene, “Economy” Symbol (Figure 3-13g) will not light up. When the “Temperature” button is Spin Speed selection pressed after Cold is selected, the... -
Page 18: Program And Consumption Table
Program and consumption table Auxiliary functions Programme (°C) Pamuklu 2.70 1600 • • • • • • 90-Cold Pamuklu 60** 1.36 1600 • • • • • • 90-Cold Pamuklu 0.75 1600 • • • • • • 90-Cold Yorgan 0.60 1000 60-40 Bebek... -
Page 19: Auxiliary Functions
• Hızlı Yıkama (Quick Wash) With this function (11b), the wash time is Auxiliary functions shortened. "F2” symbol lights up on the Auxiliary Function Selection Buttons display. • Use this function for smaller amounts or slightly soiled laundries. • Rinse Plus When this function (11c) is selected, washing and rinsing is performed with plenty of water. "F3” symbol lights up on the display. • İlave Su (Plus water) ��� ���... -
Page 20: Starting The Program
Time delay will fade. The Start symbol (Figure With the “Time delay” function you can 3-13j) will light up. delay the program start up to 24 hours. 4. The “:” in the middle of the displayed Setting can be made in intervals of 30 time delay will start to flash. minutes. 1. Open the loading door, place the Canceling the time delay laundry inside and fill detergent If you want to cancel the time delay drawer. -
Page 21: Changing The Selections After The Program Has Started
Pre-wash When "prewash" auxiliary function is selected, prewash symbol will light up to indicate the beginning of prewash step. Main wash Main wash symbol will light up to indicate that the main wash cycle has Selecting or canceling an auxiliary started. function in pause mode Rinse Auxiliary functions can be cancelled or Rinse symbol lights up at the beginning selected in accordance with the step the... -
Page 22: Ending The Program Through Canceling
If you wish to spin when the machine is in this mode: Adjust the spin speed. Press “Start/ Pause/Cancel” button (Figure 2-10). The program continues, pumps out the water and spins. The Standby Symbol (Figure 3-13k) fades out and Start The same symbol will also be displayed Symbol (Figure 3-13j) lights up. whenever any button is pressed while If you want to discharge the water only the machine is child-locked. -
Page 23: Quick Instructions For Daily Use
Quick instructions for daily use Preparation adding more laundry during a future 1. Turn the tap on completely. Check step only if the water level is low that the hose is connected tightly. enough to open the loading door or 2. Place the laundry in the machine. - Page 24 on the screen. 1. Open the loading door and take out the laundry when the door locked symbol on the display fades out. 2. Press the “On/Off” button. 3. Turn the water tap off. 4. Remove any folds in the rubber seal on the loading door and check for debris.
-
Page 25: Cleaning And Care
Cleaning and care Detergent drawer machine can cause rust stains. In such cases: Remove any powder residue buildup in Clean the drum with a stainless steel the drawer. To do this; cleaning agent. Never use steel wool 1. Press the dotted point on the or wire wool. siphon in the softener compartment and pull towards you until the Outer cabinet and control compartment is removed from the... -
Page 26: Draining Any Remaining Water And Cleaning The Pump Filter
clean them. • Take out the filters on the flat ends of the water intake hoses together with the gaskets and clean thoroughly under streaming water. • Replace the gaskets and filters carefully and tighten the hose nuts by hand. If it is composed of one piece, hold it Draining any remaining water from both sides and open it by pulling and cleaning the pump filter out. - Page 27 then resume the draining process. • After draining process is completed, replace the plug into the end of the hose and fit the hose back into its place. If your product is not supplied with an emergency drain hose, do the following as shown in the figure below: • Place a large container in front of the filter to receive water flowing from the filter.
-
Page 28: Solution Suggestions For Problems
Solution suggestions for problems Cause Explanation / Suggestion Programme cannot be started or selected. Machine may have switched to Bring your machine to factory settings by turning self protection mode due to an the programme selection knob. (see, Ending the infrastructure problem (such as line programme through Cancelling) voltage, water pressure, etc.). Water in the machine. There may be some water in your machine when you receive it. This is It is not harmful to your machine. - Page 29 The door is jammed. - Water level might be above the lower level of the door. - Machine might be heating up the water or it may be at the spinning - Run either the “Pump” or “Spin” programme. cycle. - Wait until the process is over. - Due to an electrical mechanism, - Wait until the process is over.
- Page 30 It continuously washes. Remaining time does not count down. - The machine will wait until there is sufficient In the case of a paused countdown amount of water to avoid poor washing results due while taking in water: to lack of water. Then the timer will start to count - Timer will not countdown until the down.
- Page 31 - Washing performance is poor: Oily stains appear on laundry. - Washing performance is poor: Bad odour - Such odours and bacteria layers are formed on the drum as a result of continuous washing at lower temperatures and/or in short programmes. - Oily accumulations on the drum may - Leave the detergent dispenser drawer as well have stuck to the laundry. as the loading door of the machine ajar after each - Oily accumulations on the drum may washing.
- Page 32 Clothes do not smell like the softener. - If the water hardness is higher, using insufficient amount of detergent can cause the laundry to become stiff in time. Use appropriate amount of detergent according to the water hardness. - Insufficient amount of detergent used. - If detergent is put in the prewash compartment - The detergent was placed into the although prewash cycle is not selected, machine...
- Page 33 The plug might not be plugged in the mains Check the plug. outlet. Fuse may have blown. Check the fuse. Machine does work. Nothing is displayed on Electricity may be cut Check the supply power. the screen. off. The “On/Off” button might have not been Press this button.
