Summary of Contents for Autotek Super Sport AT-Series
- Page 1 EVOLUTION OF POWER SUPER SPORT AT-SERIES AMPLIFIERS AT1000 / AT1500 / AT1200 / AT2000.1 / AT3000.1...
-
Page 2: Table Of Contents
AT-SERIES AMPLIFIERS Autotek is proud to introduce the finest high end car audio products available and would like to thank you for your continued support. The Super Sport AT-Series amplifiers have been designed to a very high level of performance, with features unavailable in any other products. -
Page 3: General Installation Procedures
System Design The success of any car stereo system relies on several factors, such as the system design, execution of the installation, and system setup. Please remember that any system is only as good as its weakest link. Please remember that higher power systems are not necessarily useful purely for high sound pressure levels, but also to establish a headroom capability, to reproduce musical peaks cleanly without distortion. -
Page 4: Amplifier Feature Descriptions
LINE OUTPUT: The line output passes through signal from the line inputs which allows you to daisy chain multiple amplifiers from one signal. All Autotek amplifiers feature a comprehensive diagnostic system, with speaker lead short circuit, and amplifier DC faults indicated by the red “PROTECT” LED. -
Page 5: At1000 / At1500 / 2-Channel Amplifier Applications
This amplifier will not do 1-Ohm stereo or 2/1-Ohm mono operation. STEREO LINE INPUT FULL RANGE MONO This application illustrates the basic mono bridging method for all Autotek 2 channel amplifiers. Interconnect cable checklist: A MONO signal source is required, such as would be available from the mono... - Page 6 AT1000 / AT1500 2-CHANNEL AMPLIFIER APPLICATIONS Stereo high pass with mono low-pass in a 2 way active, or bi-amplified system In this application we will use a 2 channel amplifier for the high frequencies, and a second one for the low frequencies, or mono sub bass. Please consult the speaker specifications to determine maximum amplifier power requirements.
-
Page 7: At1200 / 4-Channel Amplifier Applications
2 or 3 CHANNEL FULL RANGE SYSTEM Here we show how to use the 4 channel amplifiers as full range 2 or 3 channel units by taking advantage of the mono bridging capability of all Autotek amplifiers. The following example shows how to create a 3 channel system by mono bridging channel pair 3 / 4. -
Page 8: At2000.1 / At3000.1 / 1-Channel Amplifier Applications
AT2000.1 / AT3000.1 / MONO AMPLIFIER APPLICATIONS Basic application These sub bass amplifiers can be used in any of the bi-amplification systems described in this manual, replacing the 2 channel amplifiers as per the illustrations. Interconnect cable checklist: Connect the inputs to a suitable source, e.g. a head unit with good quality RCA cables. -
Page 10: Setting Up Systems After Installation For Best Performance
SETTING UP SYSTEMS AFTER INSTALLATION FOR BEST PERFORMANCE AT1000 / AT1500 / AT1200 General: At this point you are ready to get more specific on the settings for your amplifier. High Pass: -When in Hi Pass operation, this setting acts as a low frequency cut off for your system reproduction. The point that you set it at cuts off any frequencies from reproduction beyond this point. -
Page 11: Troubleshooting And Diagnostics
The key to finding the problem in a misbehaving sound system is to isolate parts of that system in a logical fashion to track down the fault. Description of the PROTECT system built into all Autotek amplifiers The diagnostic system will shut down the amplifier, until reset by turning the head unit off, and back on. This state of affairs will be indicated by the front panel PROTECT LED lighting up under the following conditions: 1 - A sort circuit on the loudspeaker leads. -
Page 12: Product Warranty
AT-SERIES Maxxsonics Limited Warranty As the manufacturer of Maxxsonics, Autotek, Crunch, MB Quart and Hifonics car audio products Maxxsonics USA Inc. Warrants to the original consumer purchaser the amplifier to be free from defects in material and workmanship for one (1) Year from date of purchase. - Page 13 PART#S608...
