ASSEMBLY INSTRUCTIONS
NEW LINE WALL BED
WITH CABINET & WARDROBE
TOOLS REQUIRED FOR ASSEMBLY
No 2 & No 4 Phillips Head Screwdrivers
Electric Drill (Hammer Drill for Masonry Wall)
6.5mm Masonry Drill Bit (For Masonry Wall)
5mm Allen Key
Spirit Level
Adjustable Spanner
Hammer
Pliers
22.06.2018

Advertisement

loading
Need help?

Need help?

Do you have a question about the wall beds Newline and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for pardo wall beds Newline

  • Page 1 ASSEMBLY INSTRUCTIONS NEW LINE WALL BED WITH CABINET & WARDROBE TOOLS REQUIRED FOR ASSEMBLY No 2 & No 4 Phillips Head Screwdrivers 5mm Allen Key Hammer Electric Drill (Hammer Drill for Masonry Wall) Spirit Level Pliers 6.5mm Masonry Drill Bit (For Masonry Wall) Adjustable Spanner 22.06.2018...
  • Page 2 It is the installers responsibility to ensure safe work practices including (but not limited to) checking for and avoiding damage to electrical and plumbing services before fixing cabinets to wall. For assembly and installation services refer to our website at www.pardo.com.au...
  • Page 3 WALL BED CABINET COMPONENTS Hardware Description 8 x 50mm 8 x Feral Socket Bolt Washers 48 x 5mm 3 x 4 Gauge Varianta Screws 5/8 Screws 8 x Clip on 2 x Magnetic Catch Hinge 12 x 28mm 20 x Screw Screws Cover Caps 8 x Mounting...
  • Page 4 STAGE 1 - WALL BED CABINET ASSEMBLY STAGE 1 - WALL BED CABINET ASSEMBLY Right End Using hammer, tap cams into 20mm holes in all panels where required. Back Important: Ensure orientation of cam is Skirting Shelf as per photo above. Back Left End Screw cam bolts into 5mm holes in...
  • Page 5 STAGE 1 - WALL BED CABINET ASSEMBLY (CONTINUED) Join 2-3 & 6-7 and tighten Right End Right End cams. Back Skirting Shelf Back 3 - 5 Join and tighten cams. Ensure is slid into location from shelf Right End side to ensure cam bolts slide into cam fittings.
  • Page 6 STAGE 2 - FIXING WALL BED CABINET TO WALL Wall Skirting Board Left End Cut skirting recess before pushing cabinet against the wall if required NOTE: To ensure the cabinet sits neatly against the wall when upright, it may be necessary to cut a larger recess into the bottom left and right hand end of cabinet to go over skirting.
  • Page 7: Detail View

    MECHANISM COMPONENTS DETAIL VIEW Parts Description Hardware Description Automatic Foot Bed Frame Connecting Rod Spring Mechanism Wall Mounting Brackets Cradles Additional 50mm Mattress Guard socket screws Extension Arm found in Wall Bed hardware set 4 x 8 gauge 5/8 screws Items not required in this install method 8 x 35mm 12 x 40mm screw...
  • Page 8 STAGE 3 - DIY MECHANISM ASSEMBLY / INSTRUCTIONS Bed Frame Wall Mounting Bracket (Not required for this install configuration) Spring mechanism bracket Spring Mechanism Connecting Rod Washer Back Cradle Extension Arm Split pin Front Cradle MECHANISM DIAGRAM Refer to above Mechanism Diagram for following instructions Attach Front/Back Cradle Left End...
  • Page 9 STAGE 4 - FIXING SIDE PANELS & DOORS Attach Clip-on Hinges Ensure butt hinge knuckle faces towards internal cupboard Drawing showing Door adjustment by screw on mounting plate Cabinet Door HINGE DIAGRAM Refer to above Hinge Diagram for following instructions Attach butt hinges to door panel to inside face to form two sets of bi-fold doors using the 5mm varianta screws provided in the Wall Bed Cabinet Hardware set (refer to drawing A above).
  • Page 10 WALL BED CARCASS DIMENSIONS - SINGLE Wall 1054 1086 Plan NTS 1086 Side Elevation NTS Front Elevation NTS Note. All based on 16mm board construction 22.06.2018...
  • Page 11 WALL BED CARCASS DIMENSIONS - DOUBLE Wall 1554 1586 Plan NTS 1586 Side Elevation NTS Front Elevation NTS Note. All based on 16mm board construction 22.06.2018...
  • Page 12 WALL BED CARCASS DIMENSIONS - QUEEN Wall 1644 1676 Plan NTS 1677 Side Elevation NTS Front Elevation NTS Note. All based on 16mm board construction 22.06.2018...
  • Page 13 RIGHT WARDROBE COMPONENTS Note. Right hand Wardrobe shown above. Hardware Description Parts Description Size (mm) ? x Cam Bolts 4 x Mounting 1 x Top 437 x 471 32 x Cam 32 x Cam Bolts Plate 1x Back 437 x 2093 1 x Left End 487 x 2227 1 x Right End...
  • Page 14 STAGE 5 - RIGHT HAND WARDROBE ASSEMBLY NOTE: STAGE 5 ONLY REQUIRED IF PURCHASING CABINET WITH RIGHT WARDROBE Left End Runner Sets Fixed Centre Shelf Skirting Base Back Hanger Rail & Connector Set Right End NOTE: Panel noted in light blue indicates panel Door found in Wall Bed Cabinet box (refer to page 2)
  • Page 15 STAGE 5 - RIGHT HAND WARDROBE ASSEMBLY (CONTINUED) Join 24, 29 & 31 Back Right End Ensure are slid into location from direction indicated to ensure cam bolts and fixings drop into place (dotted blue line Fixed Centre Shelf indicates slide in direction from front of unit Base and then pushed down into location, solid Back...
  • Page 16 STAGE 5 - RIGHT HAND WARDROBE ASSEMBLY (CONTINUED) Using Varianta screws attach hinge mounting plates to pre-drilled holes. You Right End may choose to lay the (refer to page Door 11) beside to find correct hole to Right End fix hinge mounting plate to. Right End hinge mounting plates Right End...
  • Page 17 LEFT WARDROBE COMPONENTS Note. Right hand Wardrobe shown above. Hardware Description Parts Description Size (mm) ? x Cam Bolts 4 x Mounting 1 x Top 437 x 471 32 x Cam 32 x Cam Bolts Plate 1x Back 437 x 2093 1 x Left End 487 x 2227 1 x Right End...
  • Page 18 STAGE 5 - LEFT HAND WARDROBE ASSEMBLY NOTE: STAGE 5 ONLY REQUIRED IF PURCHASING CABINET WITH LEFT WARDROBE Right End Runner Sets Skirting Base Back Fixed Centre Shelf Hanger Rail & Connector Set Left End Door Side Panel NOTE: Panel noted in light blue indicates panel found in Wall Bed Cabinet box (refer to page 2)
  • Page 19 STAGE 5 - LEFT HAND WARDROBE ASSEMBLY (CONTINUED) Join 24, 29 & 31 Back Left End Ensure are slid into location from direction indicated to ensure cam bolts and fixings drop into place (dotted blue line indicates slide in direction from front of unit Fixed Centre Shelf and then pushed down into location, solid Back...
  • Page 20 STAGE 5 - LEFT HAND WARDROBE ASSEMBLY (CONTINUED) Using Varianta screws attach hinge mounting plates to pre-drilled holes. You Left End may choose to lay the (refer to page Door 11) beside to find correct hole to Left End fix hinge mounting plate to. Left End hinge mounting plates Left End...
  • Page 21 STAGE 6 - FIXING DOOR Attach Clip-on Hinges HINGE DIAGRAM Note: Above image shows Right Hand Wardrobe Insert clip-on hinges into hinge holes on outside edges of door panels. Attach doors to cabinet by clipping hinges onto mounting plates on cabinet end panels. Adjust doors if necessary by screw adjustment where hinge meets hinge plate.
  • Page 22 LEFT / RIGHT WARDROBE DIMENSIONS Left Cabinet Right Cabinet Plan NTS Plan NTS Side Elevation NTS Left Cabinet Right Cabinet Front Elevation NTS Front Elevation NTS Note. All based on 16mm board construction 22.06.2018...
