ASSEMBLY INSTRUCTIONS
CABINET & MECHANISM
No 2 & No 4 Phillips Head Screwdrivers
Electric Drill (Hammer Drill for Masonry)
Spirit Level
QUEEN
DIY WALL BED
Tools Required For Assembly
No 2 Slot Head Screwdriver
6.5mm Masonry Drill Bit
Adjustable Spanner
Hammer
Pliers
Socket Set
26.02.13
Advertisement
Related Manuals for pardo QUEEN
Summary of Contents for pardo QUEEN
- Page 1 ASSEMBLY INSTRUCTIONS QUEEN DIY WALL BED CABINET & MECHANISM Tools Required For Assembly No 2 & No 4 Phillips Head Screwdrivers No 2 Slot Head Screwdriver Hammer Electric Drill (Hammer Drill for Masonry) 6.5mm Masonry Drill Bit Pliers Socket Set...
- Page 2 Cabinet Components Size (mm) Panel # Panels (Queen) 1655 x 464 1 x Top 1655 x 250 1 x Top Back Rails 2227 x 480 1 x Left Hand End 2227 x 480 1 x Right Hand End 1655 x 150...
- Page 3 Mechanism Components 1. AUTOMATIC FOOT 2. BED FRAME 3. CONNECTING ROD 4. SPRING MECHANISMS DIAGRAM 1 5. WALL MOUNTING BRACKETS 6. CRADLES refer to detail 7. MATTRESS GUARD 8. EXTENSION ARM Hardware 26 x Cams 26 x Cam Bolts 10 x Clip on Hinge 2 x Handles 10 x Green Wall Plugs 10 x Mounting Plates...
- Page 4 Step 1 - Cabinet Assembly NOTE: STEP 1. IS ONLY REQUIRED IF PURCHASING CABINET WITH BED MECHANISM Refer to Diagram 2 * Using hammer, tap cams into 20mm holes in all panels where required. * Screw cam bolts into 5mm holes in all panels where required. DIAGRAM 2 Hammer fix cam in place.
- Page 5 Step 2 - Fixing Cabinet To Wall * Lay cabinet face down with bottom facing the wall. * To ensure the cabinet sits neatly against the wall when upright, it may be necessary to cut a larger recess into bottom of left and right hand end of cabinet to go over skirting. (refer to detail B) IMPORTANT NOTE: Before moving cabinet upright, ensure all cams are tightened securely.
- Page 6 Step 3 - DIY Mechanism Assembly / Instructions Refer to Diagram 4 Attach spring mechanisms (#4) to front and back cradle (#6) using small nuts and bolts provided. Ensure to attach the wall mounted brackets (#5) with the ends turned inwards together with the spring mechanism to the top rear bolt. (See diagram 4) Fix the cradle assembly to the floor using the 75mm screws provided.
- Page 7 Step 4 - Mounting Bi-Fold Doors (i) Ensure Butt of hinge is on inside of doors (ii) Attaching Clip-on Hinges Door Cabinet DIAGRAM 5 (iii) Drawing showing Door adjustment by screw on mounting plate * Attach interfold hinges to door panel edges to form two sets of bi-fold doors. Note: Ensure that butt of hinge is on inside of doors * Insert clip-on hinges into hinge holes on outside edges of door panels.
- Page 8 Carcase Construction 2227mm NOTE: ALL BASED ON 16mm BOARD CONSTRUCTION Side Elevation n.t.s 1655mm Queen Plan n.t.s DIAGRAM 11...
