pardo SINGLE Assembly Instructions Manual

Fold down wall beds
Hide thumbs Also See for SINGLE:

Advertisement

Table of Contents

ASSEMBLY INSTRUCTIONS
FOLD DOWN WALL BEDS
No 2 & No 4 Phillips Head Screwdrivers
Electric Drill (Hammer Drill for Masonry)
Spirit Level
SINGLE
Tools Required For Assembly
No 2 Slot Head Screwdriver
6.5mm Masonry Drill Bit
Adjustable Spanner
Hammer
Pliers
24mm Socket Set
26.02.13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SINGLE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for pardo SINGLE

Summary of Contents for pardo SINGLE

  • Page 1 ASSEMBLY INSTRUCTIONS SINGLE FOLD DOWN WALL BEDS Tools Required For Assembly No 2 & No 4 Phillips Head Screwdrivers No 2 Slot Head Screwdriver Hammer Electric Drill (Hammer Drill for Masonry) 6.5mm Masonry Drill Bit Pliers Spirit Level Adjustable Spanner 24mm Socket Set 26.02.13...

  • Page 2: Table Of Contents

    We recommend top door (12) & bottom doors (11) are cut from one piece as per cutting list. This ensures more accurate door alignment on closing of bed. Panels (Single) Panel # Size (mm) 1 x Top 960 x 464...
  • Page 3 Mechanism Components 2 x Mounting Brackets 2 x Cabinet Angle Brackets 1 x Wall Bed Frame 2 x Bed Straps 2 x Counter Balance Mechanism 4 x Door Fixing Angles Remove long angles by unbolting at crotchet (refer to detail shown of crotchet) Crotchet Bolts / Nuts / Screws - Various Note: Bed Frame shown without slats for clarity...

  • Page 4: Top

    Step 1 - Cabinet Assembly NOTE: STEP 1. IS ONLY REQUIRED IF PURCHASING CABINET WITH BED MECHANISM Refer to Diagram 2 * Using hammer, tap cams into all 20mm holes in all panels. * Screw cam bolts into 5mm holes in all panels where required. Hammer fix cam in place.

  • Page 5: Refer To Pillowcatch Detail

    Step2 - Fixing Cabinet To Wall * Lay cabinet face down with bottom facing the wall. * To ensure the cabinet is flush against the wall when upright, it may be necessary to cut a larger recess into bottom of left and right hand end of cabinet to go over skirting. (refer to detail B) IMPORTANT NOTE: Before moving cabinet upright, ensure all cams are tightened securely.
  • Page 6 Step3 - Wall Bed mechanism Assembly / Installation * Bolt bed frame mounting brackets to left and right ends through predrilled holes using sleeves and bolts provided. (DETAIL C) DETAIL C * Remove the four (4) long angles from the bed by unbolting at crochet. (DETAIL D) * Bolt left and right hand counter balance mechanisms to bed frame.
  • Page 7 DIAGRAM 6 DIAGRAM 7 SCREWING BED FRAME ANGLES TO DOORS GUIDING BED FRAME LEG INTO TOP DOOR SLEEVE Note: Bed Frame should still be vertical in Cabinet Bed Frame Piano Hinge Crotchet Fixing Top Door angles Bottom Door Bottom Door Top Door Leave 3mm gap between doors...
  • Page 8 DIAGRAM 8 ADJUST TENSION COUNTER BALANCE MECHANISMS Lift doors up to within 30 degrees of closing Turn tension handles clockwise to increase tension DIAGRAM 9 DIAGRAM 10 ADJUSTING LEVELLING SCREWS DOOR ADJUSTMENT Move Move brackets brackets Final adjustment of doors may be made by adjusting levelling screws in mounting block whilst bed is open at 30 degrees ADJUST BOTTOM DOOR ONLY...
  • Page 9 DETAIL 01 NOTE: CABINET CONSTRUCTION THIS IS THE RECOMMENDED CABINET CONSTRUCTION METHOD TO ENSURE THE MECHANISM OPERATES CORRECTLY. Piano Hinge VARIATIONS OF CONSTRUCTION SHOULD BE CHECKED WITH PARDO PRIOR TO CHANGES. 115mm Floor Line Side Elevation n.t.s Wall 960 mm Single...
  • Page 10 Single Fold Down Door (outer angle fixing locations) Location given is for the slotted holes on bracket TOP DOOR Step 3 #1 & #4 DIAGRAM 6 BOTTOM DOOR...
