4. Plug all connections of the motor controller harness back into their respective connections.
Refer to the motor controller harness connections diagram at the end of the maintenance
manual.
NOTE: Ensure that that harness is routed toward the back of the enclosure.
5. Place the lid back on the enclosure, and latch the lid.
6. Plug the bin harness into the Engage® Zone Control unit enclosure.
7. Cycle the gates open and closed through the tractor's virtual terminal.
Contact
Questions? Contact Intelligent Ag product support:
Canadian Product Support: 1-306-993-1156
United States Product Support: 1-701-436-1219
Or, email us at
support@intelligentag.com
Page 6 of 8
1810 NDSU Research Circle N
Fargo, ND 58102
www.intelligentag.com
