DOCUMENT NUMBER: 600870-000038
SUBJECT: END OF YEAR CLEANING - ENGAGE® ZONE CONTROL
DATE: SEPTEMBER 1, 2020
This information notice describes the importance of and how to properly clean the Engage® Zone
Control Bin Kit at the end of the season.

Affected Parts

PART NAME
Engage Zone
153510-000121
Control unit

Document References

The content in this information notice and additional maintenance instructions are found in the
Engage® Zone Control Maintenance Manual (600840-000047). This document and all other
Intelligent Ag support documentation is found at
INFORMATION NOTICE
IAS PART
NUMBER
Page 1 of 5
1810 NDSU Research Circle N
www.intelligentag.com/support.
Fargo, ND 58102
www.intelligentag.com
PROBLEM
Improper cleaning
can lead to
excessive motor
corrosion

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Engage Zone Control and is the answer not in the manual?

Questions and answers

Related Manuals for IntelligentAg Engage Zone Control

Summary of Contents for IntelligentAg Engage Zone Control

  • Page 1 1810 NDSU Research Circle N Fargo, ND 58102 www.intelligentag.com INFORMATION NOTICE DOCUMENT NUMBER: 600870-000038 SUBJECT: END OF YEAR CLEANING - ENGAGE® ZONE CONTROL DATE: SEPTEMBER 1, 2020 This information notice describes the importance of and how to properly clean the Engage® Zone Control Bin Kit at the end of the season.
  • Page 2 About Motors within the Engage Zone Control unit (153510-000121) can excessively corrode if allowed to sit in fertilizer residue during long term storage, as shown below. This buildup is shown primarily on the faceplate of the motor assemblies and on the area around the gates within the unit enclosure, as shown below.
  • Page 3 1810 NDSU Research Circle N Fargo, ND 58102 www.intelligentag.com Tools Needed 15 mm socket, ratchet, and extension • 15 mm wrench • Torque wrench • ¼” hex drive (for ground wire screw) • Shop vac (recommended) or compressed air •...
  • Page 4 1810 NDSU Research Circle N Fargo, ND 58102 www.intelligentag.com End-of-Season Maintenance 1. Disassemble the Engage® Zone Control unit by following the instructions in the previous section. 2. Use a shop vac (recommended) or compressed air to remove any residue inside the enclosure and on the end stop (see diagram on page 8 of the Maintenance Manual).
  • Page 5 IMPORTANT: At the beginning of the next season, perform the steps found in the Maintenance Manual before using the system. Contact Questions? Contact Intelligent Ag Product Support Canadian Product Support: 1-306-993-1156 United States Product Support: 1-701-436-1219 Or email us at support@intelligentag.com Page 5 of 5...
