CNC PYTHON XPR User Manual page 29

Drill Cylinder [requires upgrade]
Moves the drill block up or down.
Drill On [requires upgrade]
Turns the drill block on/off.
Spindle Forward
Runs the spindle.
Table Clean
Cleans the table with the central dust extraction and the side air nozzles. The side
nozzles require air pressure of at least 0.8 mPa in the main air system. The system
will alert you if there is insufficient air pressure as you press this button.
You can raise air pressure by pulling the gray cap down (exposing an
orange ring) and turning to the right to increase and left to decrease
air pressure. Push the cap back up until the orange ring disappears
to lock in the new pressure.
Do not use air pressure over 0.8 mPA as too much air
pressure may damage the joints of the air lines of your
router.
29
