CNC JD Series Operation Instruction Manual

Motor integrated protector

Advertisement

Quick Links

Before installing and using this product,
please read this instruction carefully
and pay more attention to safety.
JD-5,JD-6
JD Series Motor Integrated Protector
OPERATION INSTRUCTION
Standard: IEC 60947-4-1

Advertisement

loading
Need help?

Need help?

Do you have a question about the JD Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CNC JD Series

  • Page 1 JD-5,JD-6 JD Series Motor Integrated Protector OPERATION INSTRUCTION Standard: IEC 60947-4-1 Before installing and using this product, please read this instruction carefully and pay more attention to safety.
  • Page 2 JD series motor integrated protector, suitable for power supply circuit with AC 50/60Hz, voltage 380V and below.JD series and AC contactor and other switching circuit to form motor control circuit. When the main circuit of the motor is out of phase,...
  • Page 3 3.Operating conditions ●Altitude ≤2000m ●Ambient temperature Range: 5°C~ +40℃, with daily average ≤ +35℃ ●Pollution Level: Level 3 ●Inclination between installation plane and vertical plane shall ≤±5° ●In the media without explosive risk, and no gases that may be corrosive to metal and damage insulation in the media together with at places where much conducting dust being in existence...
  • Page 5 5.Wiring diagram 5.1 Please read the instruction carefully and connect the cables correctly according to the wiring diagram; 5.2 JD-5,JD-5B: Terminal 1、2 is power input, 3、4 is the normally closed contact; JD-6: Terminal 4、5 is power input, 2、3 is the normally closed contact,1、3 is the normally open contact.
  • Page 6 Wiring diagram for control power supply @ AC380V voltage JD-5, JD-5B, BHQ-S-J, BHQ-S-C(2~100A) Power Suppy A B C KM KM JD-5(B) JD-5(B) JD-6, BHQ-S-C(60~250A, 160~400A) Power Suppy A B C KM KM JD-6 JD-6...
  • Page 7 Wiring diagram for control power supply @ AC220V voltage JD-5, JD-5B, BHQ-S-J, BHQ-S-C(2~100A) JD-6, BHQ-S-C(60~250A, 160~400A)
  • Page 8 6.Overall and mounting dimensions(mm) Φ12 2-Φ5.5 JD-5 Motor Integrated Protector overload phase loss Bolt grade Rated current 113±0.20 JD-5(B), BHQ-S-J, BHQ-S-C (2~100A) Φ 4-Φ5 JD-6 Motor Integrated Protector overload phase loss Bolt grade Rated current ± . JD-6, BHQ-S-C(60~250A, 160~400A)
  • Page 9: Precautions For Operation

    7. Precautions for Operation 7.1 When debugging the current knob, the change of rated working voltage should be less than ±5% 7.2 For JD-5 and JD-5B, motors whose line current is less than 6A (JD-6, line current is less than 63A), the three- phase power line should be looped through the white wire hole of the protector for several turns in the same direction, and the small no-load line current of the motor...
  • Page 10: Common Faults And Troubleshooting Methods

    8. Common faults and troubleshooting methods 8.1 In case the motor stops during operation, carefully check whether there is a phase failure or overload, and check whether the temperature of the motor rises ver y high first. If there is a temperature rise, the motor may stop due to overload.
  • Page 11: Unpack And Check

    9. Transportation and storage Product storage and transportation process can not be affected by rain and snow, and extrusion, should be placed in the air circulation, relative humidity (25℃±5℃) does not exceed 90%. The lower temperature is -25℃ , and the upper temperature is +55℃. 10.
  • Page 12 JD-5,JD-6...
