Summary of Contents for Cooke QuikClean
- Page 1 QuikClean Owners Guide In-floor cleaning and circulation system...
-
Page 2: Table Of Contents
QuikClean debris removal upgrade items General pool maintenance Pool filter, pump and skimmer baskets Cleaning the Leaf-Vac™ canister Troubleshooting guide Mandatory first steps Common symptoms, probable causes and solutions Helpful tips Warranty Warranty coverage Replacement parts QuikClean Wave low profile water actuated valve assembly... -
Page 3: Welcome
Basic steps explaining the operation of a QuikClean system: Figure 1 on Page 2 shows how the QuikClean system operates. The QuikClean Wave water valve (a) directs water to a zone of two or more QuikClean pop-up cleaning heads (b). - Page 4 QuikClean system pool schematic FIGURE 1 Page 2...
-
Page 5: Operating Instructions
If you have a two-pump layout, the QuikClean system pump will need to operate at the same time as the pool filtration system. This ensures debris is removed by the drain/s and skimmer/s at the same time. -
Page 6: Low Profile 6-Port Water-Actuated Valve
Low profile 6-port water-actuated valve The rotation speed of the 6-port water actuated valve is determined by the position of the tinted lid when it is placed on the water valve. For maximum cleaning efficiency, we recommend that the cycle time for each zone be adjusted to run approximately 30-45 seconds (operation of a single zone in isolation only). -
Page 7: Removing The Low Profile Water Actuated Valve Lid
2. To restart the valve, return the lever to its original horizontal position. PAUSE FIGURE 5 Removing the low profile water actuated valve lid (See Figure 5 & 6) It’s easy … Really! No tools needed! You can disassemble the low-profile, water-actuated valve without the use of tools. -
Page 8: Quikclean Debris Removal Upgrade Items
QuikClean debris removal upgrade items In addition to the standard QuikClean components, your system may feature a Leaf-Vac™ debris canister and/or QuikSkim® venturi-powered skimmer. The Leaf-Vac™ debris canister is conveniently located in your pool equipment area. Soaked leaves, sand, insects and other small debris are drawn through the QuikClean drain/s and collected in debris basket inside the Leaf-Vac™... -
Page 9: Cleaning The Leaf-Vac™ Canister
– in your pool equipment area are set to the correct position as per the settings when your pool was commissioned. 4. Ensure adequate return water is directed to the QuikClean water actuated valve. 5. Turn on the pump. -
Page 10: Common Symptoms, Probable Causes And Solutions
Observe your QuikClean system and note what it is doing. If you don’t feel it is operating correctly, please refer to Figure 9 for helpful suggestions on how to return your system to peak operating efficiency and effectiveness. -
Page 11: Helpful Tips
Swimming pools located in high debris areas will require longer operating times. 4. Video support material is available via the link below to help you correct any specific problems relating to your QuikClean system: https://quikclean.com.au/service-support Warranty... -
Page 12: Warranty Coverage
• Your QuikClean system must have been installed by a QuikClean Accredited Installer as per the QuikClean Project Plan. • All warranty items are to be exchanged part-for-part. You must return faulty part/s to Cooke Industries for assessment and replacement. -
Page 13: Quikclean Wave Low Profile Water Actuated Valve Assembly
QuikClean Wave low profile water actuated valve assembly Item Description Band clamp Clamp handle Low profile pause kit Low profile lid assembly Impeller Shims (x2) Centre shaft Gear retainer clips Gears Gear plate assembly 50mm T-clips (x6) Anti-friction washers (x2) - Page 14 Intelligent pool systems. 1300 652 076 cookeindustries.com.au Revision 16/08/19...
