Instruction Manual
®
Mainstream
and Streamline
ESE03379-ENUS2
Original manual
®
Filter/Strainer
2018-10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mainstream and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alfa Laval Mainstream

Summary of Contents for Alfa Laval Mainstream

  • Page 1 Instruction Manual ® ® Mainstream and Streamline Filter/Strainer ESE03379-ENUS2 2018-10 Original manual...

  • Page 3: Table Of Contents

    6. Troubleshooting ..................6.1. Troubleshooting Guidelines ..............7. Spare Parts Lists ..................7.1. SESR Mainstream Strainers Short & Long ............. 7.2. SEFR Mainstream Filters Short & Long ............7.3. SEBR/SEBW Mainstream Strainers Short & Long ..........7.4. Inline Filters/Strainers FM/SM ..............

  • Page 4: Safety

    1.1 Important Safety Information Safety is very important! DO NOT attempt to modify any Alfa Laval product. To do so could create unsafe conditions and void all warranties. DO NOT place any Tri-Clover product in an application where general product service ratings are exceeded.

  • Page 5: Introduction

    The Streamline filters and strainers are suitable for horizontal or vertical mounting, directly into the pipe work. Both Streamline and Mainstream filters and strainers can use a twin setup. A twin filter or strainer setup consists of two complete units mounted onto a single stand. Directional valves at the inlet and outlet ports allow one unit to operate while the filter media in the other unit is being changed or cleaned.

  • Page 6: Installation

    The Streamline filter/strainer comes completely assembled, and ready to install. The Mainstream filter/strainer must be assembled. When you unpack the Mainstream filter or strainer, remove the special packing inside the unit. For both the Mainstream and Streamline units, check for damage that could have occurred during shipping. Report any damage to the carrier.

  • Page 7: Assembling The Mainstream Stand

    3 Installation 3.3 Assembling the Mainstream Stand 1. Remove the triangular base (A) and three right angle adjustable brackets (B) from the packing. 2. Assemble one bracket bolt combination (B) into each of the three slotted base holes with the washer on the underside of the base and the flat face of the rubber cushion toward the base center.
  • Page 8 3 Installation...

  • Page 9: Operation

    4 Operation 4.1 Recommended cleaning Study the instructions carefully and pay special attention to the warnings! The strainer housing is designed for cleaning in place (CIP). CIP = Cleaning In Place. NOTE: All internal components of the filter/strainers must be removed for cleaning (COP) = Cleaning Out Of Place. Warning: Reverse flow or back flushing through either type filter or strainer can result to damage to the internal components.

  • Page 10: Starting The System

    Important: When installing new non-woven (felt) filter media, recirculate the process fluid through the filter. This will capture loose fibers before they go down stream. Mainstream Ensure that the correct port is used for the inlet. (See figure.) Starting the Filter System Open the vent valve slightly.

  • Page 11: Maintenance

    Note: The cover of new Mainstream filters/strainers have three legs on the cover that rest on the screen ring assembly of the SEF, the support assembly of the SES or the basket of the SEB/ SEBHVW.
  • Page 12 5 Maintenance Always use Alfa Laval genuine spare parts. Mainstream SES 1. Open the air relief valve (04) to relieve all pressure inside the strainer. 2. Remove the clamp (06) and lift off the strainer cover (05). 3. Remove the cover gasket (40) and inspect for damage or wear.

  • Page 13: Mainstream Filter/Strainer - Reassembly

    Always use Alfa Laval genuine spare parts. 5.2 Mainstream Filter/Strainer - Reassembly Note: The cover of new Mainstream filters/strainers have three legs on the cover that rest on the screen ring assembly of the SEF, the support assembly of the SES or the basket of the SEB/ SEBHVW.
  • Page 14 5 Maintenance Always use Alfa Laval genuine spare parts. Mainstream SES 1. Lubricate the o-ring (190) that seals the strainer body (01) with a food grade silicone spray and place on the outside diameter of the strainer ring support assembly (03).
  • Page 15 5 Maintenance Always use Alfa Laval genuine spare parts. Mainstream SEB/SEBHVW 1. Lubricate the o-ring (190) that seals the strainer body (01) with a food grade silicone spray and place it on the outside diameter of the strainer ring assembly (02).

  • Page 16: Streamline Basket Filter/Strainer - Disassembly

    5 Maintenance Always use Alfa Laval genuine spare parts. 5.3 Streamline Basket Filter/Strainer - Disassembly WARNING Make certain that the strainer system is not under pressure and that the system is drained of all liquids before removing any Streamline strainer from pipe work.

  • Page 17: Steamline Basket Filter/Strainer - Reassembly

    5 Maintenance Always use Alfa Laval genuine spare parts. 5.4 Steamline Basket Filter/Strainer - Reassembly Model SM/FM 1. Ensure that the filter media is in place on the back up tube (09). Refer to Changing the Filter Media, later in this manual.

  • Page 18: Changing The Filter Media

    7. Reinstall the o-ring, cam lock assembly (if necessary), and retainer ring, and lock bag in place. (See the Mainstream Filter/Strainer - Reassembly section for details.) 8. Install the screen ring assembly into the housing.

  • Page 19: Streamline Models Fm/Sm And Fms/Sms

    5 Maintenance Always use Alfa Laval genuine spare parts. 5.6 Streamline Models FM/SM and FMS/SMS Important: When installing a filter sock or overscreen, save the original packaging. This will help you identify your filter media type when reordering. 1. Relieve all pressure inside the system and make certain the filtration system is drained of all liquid.

  • Page 20: Troubleshooting

    6 Troubleshooting 6.1 Troubleshooting Guidelines The Troubleshooting section chart below applies to problems which may arise during filter or strainer operation. Contact Alfa Laval if assistance is required. Remedy Problem Probable Cause SM: Split in overscreen along length Pump pulsation is causing the screen...

  • Page 21: Spare Parts Lists

    7 Spare Parts Lists Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.1 SESR Mainstream Strainers Short & Long...
  • Page 22 7 Spare Parts Lists Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Strainer body Screen Strainer ring support Relief valve Gasket ...

  • Page 23: Sefr Mainstream Filters Short & Long

    7 Spare Parts Lists Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.2 SEFR Mainstream Filters Short & Long...
  • Page 24 7 Spare Parts Lists Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Filter body Screen ring assembly Retainer Ring Cam pin...

  • Page 25: Sebr/Sebw Mainstream Strainers Short & Long

    7 Spare Parts Lists Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.3 SEBR/SEBW Mainstream Strainers Short & Long...
  • Page 26 7 Spare Parts Lists Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Strainer body Screen ring assembly Relief valve ...

  • Page 27: Inline Filters/Strainers Fm/Sm

    7 Spare Parts Lists Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.4 Inline Filters/Strainers FM/SM...
  • Page 28 7 Spare Parts Lists Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Outlet assembly Distributor cap Spring Back up tube...

  • Page 29: Side Inlet Filters/Strainers Fsm/Sms

    7 Spare Parts Lists Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. 7.5 Side Inlet Filters/Strainers FSM/SMS...
  • Page 30 7 Spare Parts Lists Always use Alfa Laval genuine spare parts. The warranty of Alfa Laval products is dependent on the use of Alfa Laval genuine spare parts. Parts list Pos. Denomination Body assembly Distributor cap Spring Back up tube Clamp ...
  • Page 32 © Alfa Laval Corporate AB This document and its contents is owned by Alfa Laval Corporate AB and protected by laws governing intellectual property and thereto related rights. It is the responsibility of the user of this document to comply with all applicable intellectual property laws. Without limiting any rights related to this document, no part of this document may be copied, reproduced or transmitted in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), or for any purpose, without the expressed permission of Alfa Laval Corporate AB.
