INSTRUCTIONS
Thank you for purchasing our new SIP Scootershop Vespa Speedometer for Vespa PK50-125/S/SS/Automatica.
Before use, please read the instruction thoroughly and keep it for future reference.
NOTICE
1. The SIP LCD meter runs on AC/DC 12V.
2. For installation, please follow the steps described in this manual.
3. To avoid short circuit, please don't pull the wire when installing. Don't break or modify the cable head.
4. Stick to the manual and do not disassemble or change any other parts.

SIGNS AND SYMBOLS:

The info text behind the mark provides you with detailed information.
NOTE!
ACH T
Please follow the instruction to avoid damages caused by wrong installation.
Please follow the instruction to avoid damages to yourself and others.
WARNING!
Please follow the instruction to avoid damages to the vehicle.
CAUTION!
1.1
ACCESSOIRES
Meter
Temperature sensor
extension wire
Cylinder head
temperature sensor
NOTE!
Please contact your dealer if the items in your package do not correspond with the ones listed above.
T
22-23
Powerbox
(1x)
M14 Cylinder head
(1x)
temperature sensor
(1x)
Main wire
(1x)
Extension wire
Nut for
(5x)
adapter
temperature sensor
Extension button
(0,3m)
(1x)
Reserive indicator
(2m)
(1x)
extension wire (2m)
(1x)
Binder
(1x)
(1x)
(3x)
