- Page 2 HighTech Sauna Air WKB002 Pressotherapy + Thermotherapy...
- Page 3 • Right and left arm Sauna Air • Blanket and air tubes • Main unit WKB002 Pressotherapy + Thermotherapy Note: This instrument is delivered with a thin adhesive film protecting the touch screen against possible scratches that may occur during transport. This film...
- Page 5 Our WKB002 is a digital instrument with touch screen which combines functions: thermotherapy and pressotherapy. Suit composed of boots, legs, abdomen and arms. It also includes a blanket to store the wires and the suit. HighTech Sauna Air Ideal to improve circulation and to ease fat...
- Page 6 HighTech Sauna Air Connections are on the rear panel. WKB002 Connect as follows, from left to right: Pressotherapy + Thermotherapy • Plug in the power cable (200-240V 50Hz). • Connect the tubes properly to the rear panel. Follow the numerical indications. Thin cables from 1 to 5 are for thermotherapy.
- Page 7 To switch on the device, press the button on the front panel and then click on the Weelko logo on the touch screen to select the desired menu. Choose “Pressotherapy”, for pressotherapy, or “Far infrared”, for thermotherapy.
- Page 8 The number of recommended sessions is 2-3 per week, but it can vary depending on the treatment and the results to achieve. Thus, a prior assessment of the customer is very important. This is a safe, relaxing and pleasant treatment. Hightech WKB002 is also equipped with thermotherapy, which is an excellent combination.
- Page 9 First, choose the treatment to perform: Pressotherapy: to activate pressotherapy. Far infrared: to activate thermotherapy. Mode: as for pressotherapy, it allows to choose one of the four programs: A, B, C, D. Level: to adjust the intensity of the treatment into 3 levels (low, medium and high), tailored to the client’s needs.
- Page 10 4 programs are provided: Mode A fills with air sections from 0 to 9. Section 0 is deflated when section 1 is inflated. Section 1 is deflated when section 2 is inflated and so on from one limb to another, from toes to arms. The filling time per section is 11 seconds and there’s a rest time of 11 seconds, which provides a pleasant feeling of light drainage.
- Page 11 Mode C fills with air sections from 0 to 9. First section 0 is inflated, then section 1, later section 2 and so on through all sections. The air pressure is not lost as in previous modes. There is a rest time of 11 seconds and, at the end, the program starts again from section 0.
- Page 12 Mode of treatment The application of air pressure, which stimulates the venous return, improves blood and lymph circulation. It has a thermal and calming effect on the body. Place the customer in supine position on the treatment table and wrap the suit with the cables around the customer’s body.
- Page 13 Thermotherapy This device is also equipped with thermotherapy, which is the use of heat in therapy. It is indicated to activate blood circulation, to encourage fat metabolism, to relieve muscular pain or stiffness and it is also very relaxing. Body temperature will rise as the temperature of the equipment is increased (maximum operating temperature is 55ºC).
-
Page 14: Application Mode
• Connect the tubes properly to the rear panel. Follow the numerical instructions. Thin cables from 1 to 5 are for thermotherapy and thick cables from 0 to 9 are for pressotherapy. • It is important to place the blanket on a flat surface so that the customer can lay down on •... - Page 15 Indications • Treatments for fluid retention, swelling legs and lymphedema . • Detox treatments (fat and toxins removal). • Heavy legs treatments . • Adjuvant in aesthetic treatments for removing localized fat. • Helps improve blood circulation customers suffering from hypertension and diabetes.
- Page 16 It is generally considered safe for adults of all ages, with few contraindications. However, it is important to consult a medical/aesthetic professional before getting any of these Contraindications treatments. • People with serious heart diseases. • Phlebitis. • Infectious diseases. •...
- Page 17 • Be careful not to wrap the airbag too tight, to Precautions avoid hurting the users when the air is too strong. Always adjust pressure according to your customer’s preferences . • If the suit is broken or aged, please replace it with a new one to avoid accidental skin burns or electric shocks.
- Page 18 Yubitzay Avila Customer Training T. +34 93 824 9020 y.avila@weelko.com S. Yubitzay Avila Weelko Barcelona S. L. Pol. Ind. La Valldan Camí de Garreta, 92 08600 Berga Barcelona – Spain T. +34 93 824 9020 info@weelko.com @weelkobarcelona www.weelko.com...
