Alps Electric SLLQ Series Specifications

Multi Control Devices
Lever and Push Operation Type Switch
SLLQ
Series
Semicircular lever control and a push operation put together in one knob.
Typical Specifications
Items
Rating （max.） / （min.） （ Resistive load）
Output voltage
Lever portion
Operating force
Push portion
Travel （Push operation）
Lever portion
Operating life
Push portion
Product Line
Mounting height Operating angle
（mm） （Lever operation）
4.2
3.5
1V max. at 1mA 5V DC （Resistive load）
Operating force
（Push function）
（N）
15° 2.6%1
20° 2.6%1
Features
Composite operation with a single knob vertical type device.
●
Reflow solderable.
●
Applications
For selecting menus in personal digital assistants, electronic
●
organizers, notebook PCs and mobile phones
For selecting menus in remote controllers
●
For DVD players/recorders, digital still cameras, digital camcorders,
●
flat panel TVs and portable audio divices
Specifications
10mA 5V DC/50BA 3V DC
1%0.5N
2.6%1N
0.4mm
100,000cycles
100,000cycles
Minimum packing
unit （ pcs.）
900
1,400
Refer to P.311 for taping package specifications.
Drawing
Product No.
No.
1
SLLQ110100
2
SLLQ120100
Refer to P.310 for product specifications.
