T3200
TransPlate Harness
www.DiveRite.com
Product Description
The TransPlate Harness is designed specifically for use
with hard back-plates, such as stainless steel or
aluminum. The TransPlate Harness utilizes many of the
features and functions of the TransPac harness,
including the padded adjustable shoulder straps that
provide maximum comfort and adjustability and the
shoulder strap quick-release buckles, which allow for
quick donning and removal of the harness system. The
TransPlate is available in four different sizes and is
easily adjustable to allow for the perfect fit.
The
harness's shoulder straps and waist belt install on any
hard back-plate. The TransPlate also comes complete
with shoulder and waist D-rings and a stainless steel
waist buckle.
Features and Functions
The TransPlate Harness has many features that perform specific functions. Each
feature is detailed below with its position on the TransPlate and its function.
User Product Data Sheet
Ver 1.1
T3200 - TransPlate Harness
1 / 9
Advertisement
Related Manuals for Dive Rite TransPlate Harness
Summary of Contents for Dive Rite TransPlate Harness
- Page 1 D-rings and a stainless steel waist buckle. Features and Functions The TransPlate Harness has many features that perform specific functions. Each feature is detailed below with its position on the TransPlate and its function. User Product Data Sheet Ver 1.1...
- Page 2 Two-inch (50 mm) waist strap D-rings: One D-ring on each side of the waist strap is adjustable to any position on the waist strap. Attaching the TransPlate Harness to a Hard Back-Plate The TransPlate easily attaches to any hard back-plate, such as stainless steel or aluminum.
- Page 3 Attach a second stainless steel weight-stop on each shoulder-strap. Position the weight-stops so they sit on the front of the shoulder straps, just above the bottom loop on the shoulder pad. User Product Data Sheet Ver 1.1 T3200 - TransPlate Harness 3 / 9...
- Page 4 Weave the webbing strap back through the outer slot on the back-plate and through the SS loop until the protective sleeve slides through the slot. Ver 1.1 User Product Data Sheet 4 / 9 T3200 - TransPlate Harness...
- Page 5 Repeat these steps for the left side waist-strap. Attach the buckle to the left side waist-strap. Adjusting the TransPlate Harness A snug, secure fit is extremely important, which is a chief feature of the TransPlate. Adjusting the TransPlate to fit properly is essential.
- Page 6 To adjust the TransPlate Harness: Loosen the shoulder and cross-chest straps. Put on the TransPlate and fasten the waist strap so that it is comfortable. To start, slide the shoulder-strap base plates (on the waist-strap) so that they are approximately four inches from the back-plate. You may have to move them farther forward depending on your size.
-
Page 7: Care And Maintenance
Chemicals, strong detergents, and cleaning solutions can damage the TransPlate and shorten its life. • Have the TransPlate inspected yearly by your local, authorized Dive Rite dealer • Avoid excessive pool use. Excessive use in chlorinated water can lead to premature discoloration and shorten the products life. - Page 8 You must read and understand this owner’s manual and all other warnings that accompany the product. If you do not understand some part of this manual, contact Dive Rite or your local authorized Dive Rite dealer. • Misuse of the...
-
Page 9: Warranty Information
Proof of original ownership is provided by your purchase receipt and should be retained for your records. If you intend to receive your service directly from Dive Rite, you must first obtain a Return Merchandise Authorization (RMA) number by calling Dive Rite at 386- 752-1087.
