6(59,&( 0$18$/
0311 A OI
Entrance Station
(Integrated type)
OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 0311 A OI and is the answer not in the manual?

Questions and answers

Related Manuals for Aiphone 0311 A OI

Summary of Contents for Aiphone 0311 A OI

  • Page 1 GT SYSTEM Apartment Intercom System Entrance Station (Unit Type)/Entrance Station (Integrated Type)/ 6(59,&( 0$18$/ Security Guard Station Entrance Station (Unit type) Security guard station 0311 A OI Entrance Station (Integrated type) OPERATION MANUAL...

  • Page 2: General Precautions

    5. Do not put anything on or cover the unit with cloth, etc. Fire or unit trouble could result. 6. For power supply, use Aiphone power supply model or model specified for use with system. If non-specified product is used, fire or malfunction could result.

  • Page 3: Table Of Contents

    1 NAMES Entrance Station (Unit type) ...4 Entrance Station (Integrated type) ...5 Security guard station ...5 2 OPERATIONS (ENTRANCE STATION) Calling residential stations ...6 Calling security guard stations ...8 Door release ...8 3 OPERATIONS (SECURITY GUARD STATION) Calling from an entrance station ...9 Door release ...9 Light control ...9 Calling from a residential station ...10...

  • Page 4: Names

    NAMES Entrance Station (Unit type) Camera module GT-VA Camera Illuminator LED Speech module GT-DA-L (guidance-enabled type) GT-DA Speaker In Use LED (orange) Door call-in indicator (GT-DA-L only) Door release indicator (GT-DA-L only) Talk indicator (GT-DA-L only) Microphone Combination examples for entrance stations Audio only, Direct Select type Audio/video, Direct Select type (8 stations)

  • Page 5: Entrance Station (Integrated Type)

    Entrance Station (Integrated type) Camera Speaker Display 10 key (0 to 9, VIGIK (GT-DMV only/available in France) Security guard station Handset Display Cancel button (or set and return) Back search button (or move cursor to the left) Speaker 10 key (0 to 9, , #) GT-DMV (Guidance-enabled + VIGIK-linked type) GT-DM (Guidance-enabled type)

  • Page 6: Operations (Entrance Station)

    OPERATIONS (ENTRANCE STATION) Calling residential stations ● Calling with the switch module Press the call button for the residence that you want to call. The door call-in indicator will light up and you will hear a call tone. Audio guidance will be heard depending on the settings. GT-SW GT-DA-L ●...
  • Page 7 (3) Display by using letters to search 1 In the standby mode, press [ ] on the 10 key. GT-NS-V/GT-NS GT-DMV/GT-DM WELCOME WELCOME 2 When "ENTER A LETTER" displays, use the 10 key to enter letters. ENTER A LETTER ENTER A LETTER :CALL 3 The room number and name for the resident whose initial corresponds to the entered letter will display.

  • Page 8: Calling Security Guard Stations

    5 When the other person answers, communication starts and the talk indicator lights up. Audio guidance will be heard depending on the settings. GT-NS-V/GT-NS GT-DMV/GT-DM IN COMMUNICATION IN COMMUNICATION ROOM NO. 101 SMITH :CANCEL 6 When the door is released, the door release indicator lights up. Audio guidance will be heard depending on the settings.

  • Page 9: Operations (Security Guard Station)

    OPERATIONS (SECURITY GUARD STATION) Calling from an entrance station When the call is from an entrance station, the call tone will ring for approximately 10 seconds and the entrance station number will be displayed. Lift the handset to respond. Door release Press the door release button while in communication with the en- trance station.

  • Page 10: Calling From A Residential Station

    Calling from a residential station When a call is received from a residential station, a call tone will sound for approxi- mately 10 seconds and the room number and resident name will be displayed. Lift the handset to respond. Calling from the doorbell button When the doorbell button is pressed, a call tone will sound while the button is being pressed.

  • Page 11: Calling Residential Stations

    Calling residential stations Lift the handset, display the name and press the Making a call by name scrolling Use the buttons to search names by scrolling. AIPHONE SMITH SMITH NOTES: 1. Pressing the button for approximately 2 seconds will dis- play the resident names in succession.

  • Page 12: Calling Another Security Guard Station

    Making a call by security guard station name scrolling Use the buttons to search security guard station names by scroll- ing. AIPHONE SECURITY GUARD A SECURITY GUARD A Making a call by entering the security guard station number Enter the security guard station number with the 10 key.

  • Page 13: Missed Call

    Missed call If a security guard station fails to respond to a call from a residential station, "MISSED CALLS" is displayed on the display. Press the button to display the room number and name of the residential station that made the call. MISSED CALLS When the room number and name is displayed, lift the handset and press the...

  • Page 14: Emergency Call

    3-11 Emergency call When an emergency alarm switch is locked (or when a wire discon- nection occurs), an alarm sounds at the security guard station and "EMERGENCY" and the room number are displayed alternately. Press the button to stop the alarm. Lift the handset, check the name on the display and press the to communicate with the residential station.

  • Page 15: Setting List

    Setting list Setting list The following settings are possible at an entrance station or security guard station. • The program menu varies according to the unit. × = These items are set when a unit is installed. When making changes, consult with an qualified installer. ○...

  • Page 16: Changing Settings (Entrance Station)

    CHANGING SETTINGS (ENTRANCE STATION) Setting method When changing settings, use the GT-NS-V/GT-NS or GT-DMV/GT-DM program mode. ● Program Mode In the standby mode, enter the 4-digit ID code after entering [#] and [ ] on the 10 key. (Initial setting: 1111) GT-NS-V/GT-NS GT-DMV/GT-DM WELCOME...

  • Page 17: Display Language Selection

    Display language selection ● Start the program mode with the GT-NS-V/GT-NS or GT-DMV/GT-DM and select "SELECT LANGUAGE". Select English, French, German, Spanish, Dutch, or Italian. GT-NS-V/GT-NS GT-DMV/GT-DM SELECT LANGUAGE MENU SELECT LANGUAGE SELECT LANGUAGE ENGLISH Guidance language selection ● Start the program mode with the GT-DMV/GT-DM and select "GUIDE LANGUAGE". Select English, French, German, Spanish, Dutch, Italian or no guidance.

  • Page 18: Changing The Id Code

    Changing the ID code Start the program mode and select "CHANGE ID CODE". GT-NS-V/GT-NS GT-DMV/GT-DM CHANGE ID CODE MENU SELECT LANGUAGE GUIDE LANGUAGE CHANGE ID CODE :ENTER The current ID code is displayed. Enter the new 4-digit ID code after entering [ ] on the 10 key. CHANGE ID CODE CHANGE ID CODE ENTER ID CODE...

  • Page 19: Changing Resident Information

    Changing resident information Up to 500 resident information entries can be registered. ● Programming with the GT-NS-V/GT-NS or GT-DMV/GT-DM Start the program mode and select "RESIDENT INFO.". GT-NS-V/GT-NS GT-DMV/GT-DM RESIDENT INFO. MENU ACCESS CODE RESIDENT INFO. SET TIMER :ENTER Enter the room number that is to be newly registered or have data changed using [0] to [9] on the 10 key, and then press the can have up to 6 digits.

  • Page 20: Setting Messages And The Standby Screen

    Setting messages and the standby screen ● GT-DMV/GT-DM: Start the program mode and select "STANDBY SCREEN". Select from the following in the standby screen display. • Greeting message • Operation message • Original picture GT-DMV/GT-DM MENU STANDBY SCREEN BRIGHTNESS SORT SETTING :ENTER STANDBY SCREEN GREETING...

  • Page 21: Adjusting Screen Brightness

    Adjusting screen brightness Screen brightness can only be adjusted with the GT-DMV/GT-DM. ● Start the program mode and select "BRIGHTNESS". Set a digit from 0 to 9. 0 = Dark 9 = Bright. GT-DMV/GT-DM MENU STANDBY SCREEN BRIGHTNESS SORT SETTING :ENTER BRIGHTNESS DARK 0----9 BRIGHT...

  • Page 22: Changing Settings (Security Guard Station)

    ● Program Mode In the standby mode, enter the 4-digit ID code after entering [#] and [ ] on the 10 key. (Initial setting: 1111) AIPHONE The "RE-ENTER ID CODE" is displayed. Re-enter [ ] and the 4-digit ID code.

  • Page 23: Changing Resident Information

    Changing resident information Up to 500 resident information entries can be registered. ● Programming with the GT-MK Start the program mode and select "RESIDENT INFO". RESIDENT INFO. Enter the room number that is to be newly registered or have data changed using [0] to [9] on the 10 key, and then press the numbers can have up to 6 digits.

  • Page 24: Technical Precautions

    TECHNICAL PRECAUTIONS TECHNICAL PRECAUTIONS • Operating temperature: Entrance station: Security guard station: 0 °C to +40 °C (+32 °F to +104 °F) • Mounting location: Do not install the entrance station in a place where there would be a bright light behind a visitor (or where there would be a bright background) or in a place where the camera lens would be directly exposed to sunlight or a bright light.
  • Page 25 Aiphone warrants that its products have no material or workmanship defects under normal use conditions for two years after delivery to the end user. Aiphone will perform repair or replacement free of charge if the product is defective and the warranty applies to the defect. Aiphone reserves unto itself the sole right to make the final decision whether there is a defect in materials and/or workmanship and whether or not the product is under warranty.
