TrueNet
Active Hardware
Specifications
MECHANICAL
Panel Rack Mounting:
Panel Dimensions:
Weight:
INtERfACEs
UP/DOWN LINKs:
100Base tX:
serial:
Control Pad:
Patch Panel Connections:
LED INDICAtORs (WHERE UsED)
PWR:
CPU:
DOWN LINKYELLOW:
DOWN LINKGREEN:
100Base tx – Rx:
100Base tx – tx:
100Base tx LINK:
ENvIRONMENtAL & sAfEtY
Operating temperature range:
Operating humidity range:
safety:
EMC:
Power:
O r d e r i n g I n f o r m a t i o n
Description
Intelligent Patching Scanner
Intelligent Patching Master 4 Ports
Intelligent Patching Master Expander
Intelligent Patching Expander
Intelligent Patching Indicator Controller
Intelligent Patching Control Pad
Intelligent Patching Mini Scanner
Intelligent Patching Network Scanner
Intelligent Patching Rack Indicator
Intelligent Patching Scanner Attachment Cord Copper UTP
Intelligent Patching Scanner Attachment Cord Fiber
*Replace XX with: 1.5 m = 51, 2.5 m = 52, 6 m = 06, 12 m = 12
w w w . a d c . c o m
Intelligent Patching
®
(Excludes 6527 1 736-00)
1U 19" (IEC 60297)
44 mm x 483 mm x 160 mm deep
2.0Kg (4.4lbs)
Standard RS-485, Full – duplex connector shielded RJ-45 socket
Data rate up to 115.2 Kbps
RJ-45 socket, Ethernet IEEE 802.3, 100 100Base Tx/10Base T,
100/10 Mbps industry standard for connection to local area network.
RS-232 Connector 9-pin D-type male
Data rate up to 115.2 Kbps
Protocol UART, Start bit 1, Stop bit 1, Nonparity
Connector RJ-45 socket, 8 pins
Connectors 6 or 12 headers, 26-pin, 100mm spacing
On when scanner is powered
Blinking to indicate master heartbeat
On during transmission of each of the DOWN LINK ports
On during reception of each of the DOWN LINK ports
On during reception from local area network
On during transmission to local area network
On when link is active
0° C - +50° C
≤ 90% RH non-condensing
UL 60950, EN 60950
EN 55022, FCC part 15 Class A, EN 55024
100 – 240 VAC, 47 – 63 Hz, 30 W maximum
+ 1 - 9 5 2 - 9 3 8 - 8 0 8 0
Catalog Number*
6527 1 730-00
6527 1 733-00
6527 1 732-00
6527 1 734-00
6527 1 735-00
6527 1 736-00
6527 1 739-00
6527 1 741-00
6527 1 737-00
6527 1 750-XX
6527 1 751-XX
