BOGBALLE M Series Operator's Manual

Centrifugal fertiliser spreader
Hide thumbs
Table of Contents

Advertisement

Quick Links

Operator's Manual
Spreaders
GB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M Series and is the answer not in the manual?

Questions and answers

Related Manuals for BOGBALLE M Series

Summary of Contents for BOGBALLE M Series

  • Page 1 Operator's Manual Spreaders...

  • Page 3: Table Of Contents

    Table of Contents Safety ............................... 6 Safety and protection ..................................6 Legend ......................................7 Liability ..............................8 Liability ......................................8 Check list ..............................9 Check list ......................................9 Before every use: ..................................10 Before first time use: ..................................11 After 5-8 hours use: ..................................11 After every use: .....................................12 Useful hints ....................................13 Quick Guide - M60W, M45W, M35W, L20W with CALIBRATOR or ISOBUS ..............14 1 - Mounting ....................................14...
  • Page 4 Table of Contents Rest-emptying ............................44 M-line ......................................44 Normal and headland spreading ......................45 In general ......................................45 To Border ......................................45 From Border ....................................46 Settings for M60W, M45W, M35W, L20W ............................47 Normal spreading ................................47 Headland spreading ................................47 Settings for M45, M35, L20 ................................49 Normal spreading ................................49 Headland spreading ................................49 Settings for L15 .....................................53...
  • Page 5 Table of Contents Reduced working width ........................80 Principle sketches ..................................80 Mechanical control and Section Control Standard Section Control Dynamic ..............................80 Controls ......................................81 M60W, M45W, M35W, L20W with CALIBRATOR ZURF or ISOBUS M45, M35, L20, L15 with CALIBRATOR ICON ........................81 M45, M35, L20, with CALIBRATOR ZURF..........................82 M45, M35, L20, L15 with mechanical control ........................83 Maintenance and care ..........................

  • Page 6: Safety

    Safety Safety and protection ● Read Operator’s Manual and safety rules before starting. ● Read Operator’s Manual for the PTO shaft. ● Do not leave the tractor cabin without stopping the PTO system of the tractor! ● Turn off tractor engine and all electrical controlling devices during maintenance and other intervention on the spreader ●...

  • Page 7: Legend

    Safety Legend Read Operator’s Manual and safety rules before starting. Never go under a raised spreader. Never go between spreader and tractor when engine is started. Never use the ladder when the spreader is not mounted on a tractor. Safety distance for flying material must be observed. Never go behind the spreader with rotating spreading discs.

  • Page 8: Liability

    You are fully responsible for the setting of the spreader. The spreader must be set according to the fertiliser in use. Be aware that the fertiliser batch tested in the BOGBALLE A/S test facilities may differ from the fertiliser delivered to you even if with the same specifications.

  • Page 9: Check List

    Check list Check list Before every use See page Check that the spreading discs turn easily Check that the PTO shaft has the correct length Check that the agitators turn easily Check that the outlet shutters move easily Check that the spreading vanes are intact and correctly mounted Check that protection tubes of the PTO shaft are intact Check that the security chain of the PTO shaft is fixed Check that the top link and lift arms are intact and secured by lynch pin...

  • Page 10: Before Every Use

    Check list Before every use: ● Check that the spreading discs turn easily when the PTO shaft is not mounted. NOTE: If not - check the transmission. ● Check that the PTO shaft has the correct length, with a correct overlap of the axle ends (min. 100 mm.) for the specific tractor (see figure 1) If the overlap is too big or too small it will result in a serious damage of the complete transmission, including...

  • Page 11: Before First Time Use

    Check list Before first time use: ● Before filling in fertiliser, cover the entire spreader with the metal protective oil delivered with the spreader. This will fill up and seal joints, preventing fertiliser dust getting into gaps (see figure 1) ●...

  • Page 12: After Every Use

    Cleaning After every use: ● Clean the spreader. NOTE: Do not high-pressure clean directly on the seals of the transmission. Water will damage gears and bea- rings and will not be accepted as warranty (see figure 1) ● W-spreaders: Do not high pressure-clean the load cells and the bearings on the chassis. ●...

  • Page 13: Useful Hints

    Check list Useful hints ● The speed when driving on public roads must not exceed 30 km/h. The speed during spreading should not exceed 30 km/h. ● Prevent packing the fertiliser by driving long distances on uneven ground with a full hopper. If the fertiliser is packing in the bottom of the hopper, it might damage the agitator of the spreader.

  • Page 14: Quick Guide - M60W, M45W, M35W, L20W With Calibrator Or Isobus

    (see figure 1) For late application see chapter ’Spreader settings/Working height - late application’ page 52 2.2 Find the relevant spread chart on www.bogballe.com or via the BOGBALLE Spread Chart app (see chapter ’Spread Charts’ page 21) 2.3 Make sure that the scale stop is fixed at scale 9 (see figure 2) 2.4 Make sure that Full Automatic Calibration (FAC) is activated...

  • Page 15: Quick Guide - M45, M35, L20, L15 With Calibrator

    Special for L15. Standard working height: 55 cm from upper link to top of the crop For late application see chapter ’Spreader settings/Working height - late application’ page 52 2.2 Find the relevant spread chart on www.bogballe.com or via the BOGBALLE Spread Chart app (see chapter ’Spread Charts’ page 21) 2.3 Make sure that the scale stop is fixed at scale 9...

  • Page 16: Quick Guide - M45, M35, L20, L15 With Mechanical Control

    Special for L15. Standard working height: 55 cm from upper link to top of the crop (see page 52 figure 2) For late application see chapter ’Spreader settings/Working height - late application’ page 52 2.2 Find the relevant spread chart on www.bogballe.com or via the BOGBALLE Spread Chart app (see chapter ’Spread Charts’ page 21) 2.3 Carry out a calibration for quantity setting (see page 22)

  • Page 17: How To Do Headland Spreading

    Quick Guide - M45, M35, L20, L15 with mechanical control 3 - How to do headland spreading 3.1 Check that the spreader is in headland spreading mode (see chapter ’Normal and headland spreading’ page 39) The same vane is used for both normal and headland spreading 3.2 Set the PTO speed according to the spread chart 3.3 Start spreading and make sure you keep a constant speed 4 - How to do normal spreading...

  • Page 18: Principle Sketch

    Principle sketch Top link fixture and spirit level Shutters Setting pointer Connection rod Degree meter Friction clutch Link pins Setting axle Angle transmission Serial no. plate...
  • Page 19 Principle sketch Top link fixture Shutters Setting pointer Connection rod Degree meter Friction clutch Link pins Setting axle Angle transmission Serial no. plate...

  • Page 20: Technical Specifications

    Technical specifications Model Netto weight Hopper volume Hopper width Hopper depth Fill opening Load height M60W plus 4050 L 4.450 284 x 131 4500 L 4.950 284 x 131 4800 L 1.005 5.280 284 x 131 5250 L 1.032 5.770 284 x 131 5550 L 1.044...

  • Page 21: Spread Charts

    Spread charts How to use Spread charts are available on www.bogballe.com or from the Bogballe Spread Chart App (see figure 1) Example PTO: 540 rpm Working width 24 330 Km/h Kg/Ha Kg/Ha Km/H Kg/Min ± ± cm Spreader settings 11,0...

  • Page 22: Calibration And Quantity Setting

    Calibration and quantity setting Basic principle and definition of standard calibration set point value STD All spreaders are equipped with identical standard outlets (STD with flow-rate <300 kg/min) which must always be used for calibration. Depending on model type, the L-line and M-line spreaders additionally can be set to different other flow-outlet positions.
  • Page 23 Calibration and quantity setting M60W, M45W, M35W, M45, M35, L20W, L20 The spreaders are equipped with a hopper bottom that can be turned 360° with different flow-outlets for achieving high/low flow rates. The turnable hopper bottom is positioned underneath each side of the hopper outlet and each position is used for optimizing the precision and accuracy of the quantity applied (M-line example see figure 1) The position of the hopper bottom must be set manually by the operator.

  • Page 24: Correct Flow-Outlet Setting At High/Low Rates

    Calibration and quantity setting Approximately flow Correct Flow-outlet setting at high/low rates position Outlet closed* position Standard outlet for most common quantities Kg/min < 300 position Maximum outlet for high quantities (only M-line) Kg/min < 450 setting Maximum Plus for extremely high quantities (only M-line) Kg/min <...

  • Page 25: Calibration Procedures/Possibilities M-Line & L-Line

    Calibration and quantity setting Calibration procedures/possibilities M-line & L-line With the outlet in STD position as set point value - the difference in flow for the respective settings on the Flow-out- let position is defined by the following factors: Flow-outlet position Quantity factor for Calibration value position equals...

  • Page 26: Mw-Line, L20W With Calibrator Zurf Or Isobus, Fully Automatic Calibration (Fac)

    Calibration and quantity setting MW-line, L20W with CALIBRATOR ZURF or ISOBUS, fully automatic calibration (FAC) Note: The display illustrations is based on the CALIBRATOR ZURF display. The ISOBUS display and the function- ality is basic identical, but the layout and design might differ slightly. MW-line spreaders and L20W equipped with weighing technique is fully automatically calibrated (FAC) during spreading in the field.

  • Page 27: M-Line, L20W, L20 & Calibrator Zurf / Use Of Calibration Value Std

    Calibration and quantity setting M-line, L20W, L20 & CALIBRATOR ZURF / use of calibration value STD The STD calibration value is entered by pushing the Calibration button and entering the STD value, known (see figure 1) from the actual spread chart or from earlier experience. Entering a STD calibration value via the Calibration button: 2576 Calibration Menu...

  • Page 28: M-Line & Calibrator Zurf / Use Of Calibration Value Std In Max Flow-Outlet Position

    Calibration and quantity setting M-line & CALIBRATOR ZURF / use of calibration value STD in MAX flow-outlet position In case the turnable hopper bottom is positioned in one of the other flow-outlet positions, the calibration value can be compensated by pushing the Calibration button once again - defining the actual hopper bottom position - without entering a new value.

  • Page 29: M-Line & Calibrator Zurf, Use Of Std Calibration Value Via Input

    Calibration and quantity setting M-line & CALIBRATOR ZURF, use of STD calibration value via INPUT Example of setting and entering the STD calibration value transferred to the Flow-outlet in MAX–position via INPUT (see figure 1) INPUT Active Field No. A-2 2576 Calib.

  • Page 30: M-Line, L20W, L20 & Calibrator Zurf, Micro Granular / Small Seeds With Fixed Scale

    Calibration and quantity setting M-line, L20W, L20 & CALIBRATOR ZURF, micro granular / small seeds with fixed scale The position of the hopper bottom can also be defined via MENU and Scale definition. This gives further access to define MIC – position for spreading micro granular and small seeds, which automatically leads to “Fixed Scale” setting.

  • Page 31: M-Line Manual Calibration On Spreader Mc

    Calibration and quantity setting M-line manual calibration on spreader MC This procedure is more time consuming compared to entering the calibration value defined at the spread chart or tested by the S-indicator. The manual calibration is completed by: ● Filling in minimum 200 Kg of fertiliser into a clean and dry the hopper ●...
  • Page 32 Calibration and quantity setting M-line manual calibration on spreader Push the Calibration button – and choose Manual Calib MC. Calibration Menu Manual Calib Calib. Quantity STD Value Field 24,0 Field 24,0 Field 24,0 30 s 24,40 Kg/Ha Kg/Ha Kg/Ha Full Auto Calib FAC Set Calib.

  • Page 33: M-Line, L20W, L20 & Calibrator Zurf, Quick Setting Via Spread Chart Value

    Calibration and quantity setting M-line, L20W, L20 & CALIBRATOR ZURF, quick setting via spread chart value Push the Calibration button – and choose Spread chart. Please see page 21 defining setting according to the spread chart. The STD Calibration value is defined as “K”. INPUT Active Field No.

  • Page 34: M45, M35, L20 & Calibrator Zurf By Use Of S-Indicator Value

    Calibration and quantity setting M45, M35, L20 & CALIBRATOR ZURF by use of S-indicator value The S-indicator is an easy and uncomplicated way to determine the STD Calibration value. Please follow the instruction supplied with the S-indicator. Note: The fertiliser´s condition can vary each delivery. It is advised to carry out a new calibration for each deliv- ery/batch.
  • Page 35 Calibration and quantity setting Push the Calibration button – and choose S-indicator: INPUT Active Field No. A-2 Calibration Menu S-indicator Value Flow-outlet pos. Field no. 2, folder A Quantity Kg/Ha --- Value Field 24,0 Field 24,0 Field 24,0 Field 24,0 Quantity realized Kg/Ha 3,678...

  • Page 36: M45, M35, L20, L15 & Calibrator Icon By Use Of S-Indicator Value

    Calibration and quantity setting M45, M35, L20, L15 & CALIBRATOR ICON by use of S-indicator value The S-indicator is an easy and uncomplicated way to determine the STD Calibration value. Please follow the instruction supplied with the S-indicator. Note: The fertiliser´s condition can vary each delivery. It is advised to carry out a new calibration for each deliv- ery/batch.
  • Page 37 Calibration and quantity setting The S-indicator value corresponds to the various Flow-outlet settings as follows: Flow-outlet position Quantity factor for S-indicator value position equals S-indicator value position equals S-indicator value setting equals S-indicator value position equals S-indicator value position equals FIX-scale setting Only possible on M-line / L15: Optional equipment by use of reduction inserts...

  • Page 38: M45, M35 & Calibrator Zurf/Icon Setting According To Flow-Outlet Position

    Calibration and quantity setting M45, M35 & CALIBRATOR ZURF/ICON setting according to flow-outlet position The M-line spreader is identical with the MW-line spreader – except for the weighing system and the Full Automatic Calibration. All other features on the M-line are identical with the MW-line and calibrating the M-line refers to MW instructions on the previous pages.
  • Page 39 Calibration and quantity setting S-indicator value The S-indicator is an easy and uncomplicated way to determine the STD Calibration value. Please follow the instruction that comes with the S-indicator. Please note that the fertiliser´s condition can vary each delivery. It is advised to carry out a new calibration for each delivery/batch.

  • Page 40: L20, L15 & Calibrator Zurf/ Icon Setting According To Flow-Outlet Position

    Calibration and quantity setting L20, L15 & CALIBRATOR ZURF/ ICON setting according to flow-outlet position Equipped with CALIBRATOR ICON the spreader is operated according to the instruction book of the CALIBRATOR ICON. To make use of the optional equipment for achieving MIN flow rates, the STD calibration value must manually be compensated and recalculated as the Flow-outlet affects the Calibration value, defined by the following factors: Flow-outlet position Quantity factor for Calibration value...
  • Page 41 Calibration and quantity setting S-indicator value L15 and L20 with CALIBRATOR ZURF/ICON The S-indicator is an easy and uncomplicated way to determine the STD Calibration value. Please follow the instruction that comes with the S-indicator. Please note that the fertiliser´s condition can vary each delivery. It is advised to carry out a new calibration for each delivery/batch.

  • Page 42: M45, M35, L20, L15 Calibration With S-Indicator In Combination With Hydraulic Control

    Calibration and quantity setting M45, M35, L20, L15 calibration with S-Indicator in combination with hydraulic control Please notice that the fertiliser’s condition can vary from each delivery. It is advised to carry out a new calibration for each delivery/batch. It is recommended to carry out three consecutive S-indicator tests and middle the sum with the number of tests into an average value.
  • Page 43 Calibration and quantity setting M45, M35 Flow-outlet position Measured kg Calculation factor [XXX] position S-indicator value position S-indicator value position S-indicator value position S-indicator value position Fix Scale according to spread chart L20, L15 Flow-outlet position Measured kg Calculation factor [XXX] position S-indicator value position*...

  • Page 44: Rest-Emptying

    Rest-emptying M-line + L20(W) Remaining fertiliser in the hopper must be unloaded / drained, by opening the shutters following the procedure below: ● Remove the Calibration-plate at spreading discs (see figure 1) ● Position the SC Dynamic in position for calibrating and emtying the hopper (Only M-line spreaders without SC Dynamic actuators) (see figure 2) ●...

  • Page 45: Normal And Headland Spreading

    Normal and headland spreading In general The rotation direction of the spreading discs determines the mode of spreading. For normal spreading the discs must turn towards each other (in-centre) , for headland spreading the discs turn away from each other (see figure 1) (off-centre) (see figure 2)

  • Page 46: From Border

    Normal and headland spreading From Border The From Border spreading system is developed for working widths from 12 – 28 metres. In case working widths larger than 28 metres are required – the To Border spreading system must be used. On working widths 12 - 21 metres it is necessary to lower the PTO speed when spreading in the 2 tramline (see figure 1)

  • Page 47: Settings For M60W, M45W, M35W, L20W

    Normal and headland spreading Settings for M60W, M45W, M35W, L20W Change the rotation direction of the discs to switch between normal and headland spreading. Normal spreading Headland spreading NOTE: STOP the PTO when switching. For detailed instructions see the CALIBRATOR manual or the ISOBUS controller manual. Normal spreading Electrical remote shift CALIBRATOR: Set to Normal.

  • Page 48: Settings For M45, M35, L20

    Normal and headland spreading Settings for M60W, M45W, M35W, L20W Manual shift (L20W only - electrical shift is an option) On the back of the spreader - Set the handle in outer position (see figure 1) From border spreading (Option) Electrical remote shift CALIBRATOR: Set to From Border.

  • Page 49: Normal Spreading

    Normal and headland spreading Settings for M45, M35, L20 Change the rotation direction of the discs to switch between normal and headland spreading. Headland spreading Normal spreading NOTE: STOP the PTO when switching. Normal spreading Electrical remote shift CALIBRATOR: Set to Normal. The headland symbol must not be visible in the display (see figure 1).
  • Page 50 Normal and headland spreading Settings for M45, M35, L20 From border spreading (Option) Electrical remote shift Set to From Border. Headland symbol must be visible in the display (see figure 1) For detailed instructions see the CALIBRATOR manual. Cable remote shift Move the handle towards the cable (see figure 2) Manual shift...
  • Page 51 Normal and headland spreading Settings for M45, M35, L20 To/From border spreading with cable remote Cable remote shift Normal spreading ● Move both handles away from the cables (see figure 1) To Border spreading Move right handle away from the cable and move left handle towards the cable (see figure 2) From Border spreading Move both handles towards the cables...
  • Page 52 Normal and headland spreading Settings for M45, M35, L20 To/From border spreading with manual shift Manual shift On the back of the spreader To Border spreading Move left handle in inner position, right handle in outer position (see figure 1) Normal spreading Move both handles in inner position (see figure 1)

  • Page 53: Settings For L15

    Normal and headland spreading Settings for L15 Change the rotation direction of the discs to switch between normal and headland spreading. Headland spreading Normal spreading NOTE: STOP the PTO when switching. Normal spreading Cable remote shift Move the handle away from the cable (see figure 1) Manual shift Set the handle in inner position...
  • Page 54 Normal and headland spreading Settings for L15 From border spreading Cable remote shift Move the handle towards the cable (see figure 1) Manual shift Close the right side of the spreader by removing the thumbscrew and sliding the shutter (see figure 2) Set the handle in outer position (see figure 3) Figure 1...
  • Page 55 Normal and headland spreading Settings L15 To/From border spreading with cable remote Cable remote shift Normal spreading Move both handles away from the cables (see figure 1) To Border spreading Move right handle away from the cables move left handle towards the cables (see figure 2) From Border spreading Move both handles towards the cables...

  • Page 56: Spreader Settings

    Spreader settings PTO speed Check the spread chart for the recommended PTO speed (see figure 1) For Normal spreading the PTO speed is normally set to 540 rpm (see figure 2) This will differ in some cases, as the strength of the fertiliser grain affects the optimal PTO speed. For Headland spreading, the PTO speed recommended in the spread chart, is the minimum category (EOS).

  • Page 57: Tilt Angle

    Spreader settings Tilt angle Check the spread chart for the recommended tilt angle (see figure 1) 1. Mount the spreader horizontally. 2. Set the degree meter to the tilt angle given by the spread chart (see figure 2) 3. Tilt the spreader by adjusting the top link of the tractor. It is recommended that the hopper is half full when doing so .

  • Page 58: Working Height - Standard

    Spreader settings Working height - standard Distance from the centre of the upper link pins to the top of the crop: M60W, M45W, M35W, L20W, M45, M35 and L20: 75 cm (see figure 1) L15: 55 cm (see figure 2) Working height - late application Move the link pins of the spreader to the lowest position to lift the spreader as much as possible.

  • Page 59: Working Height - Trails

    Spreader settings Working height - trails If the spreader is mounted on M-Trail or other carriages – the distance from the ground to the upper link is increased from 75 cm, typically up to 100 cm to 140 cm. Find the correct compensation to the tilt angle in the chart below: H: 100 - 140 cm (see figure 1) Working width...

  • Page 60: Quantity Setting

    Spreader settings Quantity setting The quantity (Kg/Ha) is set by the scale pointer of the spreader (see figure 1) The setting system is equipped with a scale, a scale stop and a scale pointer. The scale runs from 0 to 9 in 0,25 steps.

  • Page 61: By Use Of Spread Chart Only

    Spreader settings Quantity setting By use of spread chart only It is possible to find the scale setting in a spread chart for the specific fertiliser. Use our website or app to find the correct spread chart (see figure 1) NOTE: The spread chart is only a guideline, as the quantity applied depends on the driving speed and the tramline distance, but also of the quality of the fertiliser in question.

  • Page 62: Working Width Setting

    Spreader settings Working width setting Each vane is marked with an R (right) or an L (left). Make sure to mount the two vanes with R on the right side of the spreader and the two vanes with L on the left side of the spreader.

  • Page 63: Spreading Vanes

    Spreader settings Spreading vanes The spreading vane is a key part of the spreader. Both sides of the vane are used for spreading. The front side is used for normal spreading (see figure 1) When changing the direction of the discs the back side is used for headland spreading (see figure 2) Headland spreading is done with the back side of the spreading vane and with the rotation of the spreading discs away from each other.
  • Page 64 Spreader settings Spreading vanes Below is shown guideline working width/vane type for the main fertiliser types in the market. Any deviation will ap- pear on the spread chart in question. Vane types / marks Models Type / mark Working width (M) M60W, M45W, M35W, L20W, M45, M35, L20 M60W, M45W, M35W, L20W, M45, M35, L20 M60W, M45W, M35W, L20W, M45, M35, L20...
  • Page 65 Spreader settings Spreading vanes Left side Right side Normal Headland Headland Normal Left side Right side Normal Headland Headland Normal Left side Right side Normal Headland Headland Normal Left side Right side Normal Headland Headland Normal...

  • Page 66: Regulation System

    Regulation system Connection rods The regulation system consists of a scale pointer connected to the outlet shutters through 4 connection rods. The scale pointer must be positioned on scale number 0 when the shutters are closed (see figure 1-A) The shutters are closed with an approx. 0,5 mm. opening (see figure 2) If this is not the case, the scale pointer can be adjusted on the connection rod (see figure 1-B)

  • Page 67: Practical Tests

    (see figure 2) 3. Read off the grouping of the grains in percentage in (see figure 3) 4. Enter the result in the online fertiliser analysis by choosing Spread Charts on www.bogballe.com and follow the instructions. (see figure 4) Figure 1...

  • Page 68: F-Indicator - Grain Strength

    4. Repeat the procedure with min. 9 more grains. 5. Calculate the average strength of the 10 grains 6. Enter the result in the online fertiliser analysis by choosing Spread Charts on www.bogballe.com and follow the instructions. (see figure 4)
  • Page 69 Practical tests Test with trays A tray test can be done if there are doubts about the quality and spreading ability of the fertiliser. If carried out correctly, the tray test can help determine the spreadability of the fertiliser and help ensure a correct working width and an optimum overlap.

  • Page 70: Normal Spreading

    Practical test Normal spreading 1. Place the 7 test trays in an even line across the tramlines (see figure 1) 2. The distance between the trays are dependent on the working width. 3. Find the correct distance in the below table. WORKING WIDTH (metres) TRAY DISTANCE (metres) 15-16...

  • Page 71: Headland Spreading

    Practical test Headland spreading To border The test will determine the quantity spread at the border compared to the quantity spread in-field. By border spreading it is possible to change the working width ± 1 m by each ± 50 rpm. 1.

  • Page 72: Optimize Spreading

    Optimize spreading Normal spreading Working width 24 metres Amount 250 kg/ha Example of how the tilt angle can optimize the spread pattern. Optimum spread pattern Tilt angle: +2 Test tray collection Spread pattern including overlap Coefficient of variation: 4,1%* Metres Metres Metres A triangular shaped curve ensures...

  • Page 73: Headland Spreading En13739-1

    Optimize spreading Headland spreading EN13739-1 To Border Headland spreading can be divided into three categories: Minimum: The amount of fertiliser outside field border is 3 ‰ or less of the total kg/ha on 100 metres. Environ- mentally optimised spreading (EOS) according to EN13739-1. Medium: The amount of fertiliser at the border is between 25 -70 % of the kg/ha of fertiliser in the normal spread area.
  • Page 74 Optimize spreading Headland spreading Working width 24 metres To Border Amount 200 kg/ha Example of how the PTO speed can change the spread pattern in the border area. Minimum category (EOS) PTO speed: 375 rpm Spread pattern with minimum fertiliser over the border Relative amount outside border/ha = 0,05% Metres Medium category...

  • Page 75: Start And Stop Points At Headlands

    Headland management Start and stop points at headlands The start and stop points at headlands depend on the working width and how the spreader is controlled. To achieve the optimum overlap follow the below recommendations. Be aware that the distances to and from the tramline are the same whether spreading To or From Border (see figure 1+2) NOTE: Below recommendations are given by 8 km/h.

  • Page 76: Spreading On Non Rectangular Fields

    Spreading on non rectangular fields Principle sketches Mechanical control After spreading the headland, do normal spreading in the tramlines. Opening and closing of the spreader is made as shown on the sketches. Section Control Standard When spreading, the quantity/working width is changed for each opened or closed section. 8 7 6 5 4 3 2 1 8 7 6 5 4 3 2 1 8 7 6 5 4 3 2 1...

  • Page 77: Controls

    Spreading on non rectangular fields Controls M60W, M45W, M35W, L20W with CALIBRATOR ZURF or ISOBUS Manual Section Control Standard ● After spreading the headland, do normal spreading in the tramlines. ● When entering the wedge, press either of the wedge buttons and press minus to decrease the working width in steps (see figure 1) ●...

  • Page 78: M45, M35, L20, L15 With Calibrator Icon

    Spreading on non rectangular fields Controls M45, M35, L20, L15 with CALIBRATOR ICON Manual Section Control Standard ● After spreading the headland, do normal spreading in the tramlines. ● When entering the wedge press minus to decrease the quantity/working width in steps. ●...

  • Page 79: M45, M35 With Calibrator Zurf

    Spreading on non rectangular fields Controls M45, M35 with CALIBRATOR ZURF Manual Section Control Dynamic (only M-line) ● After spreading the headland, do normal spreading in the tramlines. ● When entering the wedge, press the wedge button which complies to the side where the wedge is (see figure 1) ●...

  • Page 80: Reduced Working Width

    Reduced working width Principle sketches Mechanical control and Section Control Standard When spreading the quantity/working width is adapted to the remaining part of the field (see page 77) 8 7 6 5 4 3 2 1 Working width Remaining part of the field Section Control Dynamic When spreading the spread pattern is adapted to the remaining part of the field (see page 75 or 76)

  • Page 81: Controls

    Reduced working width Controls M60W, M45W, M35W, L20W with CALIBRATOR ZURF or ISOBUS Manual Section Control Standard Reduce the working width by pressing either of the wedge buttons and press minus to decrease the working width to the reduced spread width (see figure 1) Manual Section Control Dynamic (only M-line) Reduce the working width by pressing the wedge button, which complies to the side where the remaining part of...

  • Page 82: M45, M35, L20, With Calibrator Zurf

    Reduced working width Controls M45, M35, L20, with CALIBRATOR ZURF Manual Section Control Standard Reduce the working width by pressing either of the wedge buttons and press minus to decrease the working width to the reduced spread width (see figure 1) Manual Section Control Dynamic (only M-line) Reduce the working width by pressing the wedge button which complies to the side where the remaining part of the field is...

  • Page 83: M45, M35, L20, L15 With Mechanical Control

    Reduced working width Controls M45, M35, L20, L15 with mechanical control Reduce the working width by calculating a new flow factor using the S-indicator (see figure 1) Insert the quantity, the remaining width of the field, the speed and the weighted grams. Example Calculating new FlowFactor - remaining part of the field = 8 metres Figure 1...

  • Page 84: Maintenance And Care

    Maintenance and care Lubrication The components below must be lubricated according to below instruction. Position Component Instruction Cross joint and lock of the PTO Use grease Adjustment axle (cross axle w/ 4 bearings) Use oil Setting handle (axle w/ 2 bearings) Use oil Connection rods (rods between axle and shutters) Use oil...

  • Page 85: Normal Maintenance

    Maintenance and care Normal maintenance ● Cover the entire spreader with protection oil before using it first time. Remember always to cover the entire sprea- der in corrosion protective oil. It is not sufficient only to wash the spreader, as dry fertiliser will absorb water and escalate a corrosion.

  • Page 86: Corrosion

    Corrosion Remember always to grease the entire spreader in a corrosion protective oil. It is not sufficient just to wash the spreader, as dried-in fertiliser dust will absorb water and escalate corrosion. Mineral fertiliser is extremely corrosive and often with a high content of nitrogen and sulphur, which combined with water generate sulphuric acid.

  • Page 87: Safety - Axle Load

    Safety - Axle load Axle load Axle load distribution Mounting of front or rear three-point linkage implements, shall not result in exceeding the maxi- mum permissible weight, the permissible axle loads and the tyre load carrying capacities of the tractor. The front axle of the tractor must always be loaded with at least 20% of the unloaded weight of the tractor.
  • Page 88 Safety - Axle load Axle load Spreader model M60W M45W M35W L20W Determination of the total weight, the axle loads, the tyre load carrying capacity and the necessary minimum bal- lasting. R Rear mounted Implement and front/rear combinations. Calculation of minimum ballasting at the front I Fmin Front mounted implement Calculation of the minimum ballasting at the rear I...
  • Page 89 Safety - Axle load Axle load Type the calculated data and the given data from the tractor manual into the table. Tyre load carrying capacity Table Real value according Permissible value ac- Double permissible to calculation cording to instruction tyre load carrying handbook capacity (two tyres) Minimum ballasting...
  • Page 90 Safety - Axle load Axle load Tyre load carrying capacity Table Real value according Permissible value ac- Double permissible to calculation cording to instruction tyre load carrying handbook capacity (two tyres) Minimum ballasting front/rear Total Weight 12166 kg 13000 kg ≤...

  • Page 91: Ec-Declaration Of Conformity

    EC-Declaration of conformity Manufacturer: BOGBALLE A/S Bogballe DK-7171 Uldum Phone +45 7589 3266 Fax +45 7589 3766 Declares that machine: Centrifugal fertiliser spreader: M60W / M45W / M45 / M35W / M35 / L20W / L20 / L15 Is made in conformity with: Directive of 17th May 2006 conc.

  • Page 92: Notes

    Notes...
  • Page 93 Notes...
  • Page 94 Notes...
  • Page 96 FIND MORE INFORMATION ON www.bogballe.com...

This manual is also suitable for:

Mw seriesM60w plusM45w plusM35w plusM35w baseM45 plus ... Show all
