BEJUBLAD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BEJUBLAD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IKEA BEJUBLAD

Summary of Contents for IKEA BEJUBLAD

  • Page 1 BEJUBLAD...
  • Page 3 Please refer to the last page of this manual for the full list of IKEA appointed Authorized Service Centre and relative national phone number...

  • Page 4: Table Of Contents

    Energy efficiency of hob Power limitation Rating plate Functions Environmental aspects Cooking Table IKEA GUARANTEE User menu customization Safety information For your own safety and to ensure proper operation of the appliance, please read this manual carefully before installation and operation. Keep these instructions together with the appliance, even if it is sold or transferred to third parties.
  • Page 5 ENGLISH For appliances with a power supply cable, the terminals or section of wire between the cable anchor point and the terminals must be arranged in such a way as to allow the live wires to be pulled out before the earth wire in the event of the cable coming out of its anchor.
  • Page 6 ENGLISH • Children must be supervised to ensure that they do not play with the appliance. • This appliance must not be used by persons (including children) with limited physical, sensory or mental abilities, or by inexperienced or untrained persons, unless carefully supervised and instructed in safe use of the appliance by a person responsible for their safety.
  • Page 7 ENGLISH spoons and pan lids on the surface of the hob, as they might overheat. • do not rely on the pan sensors. WARNING: Unsupervised cooking on a hob using oil CAUTION: The cooking process must be supervised. A short cooking process must be constantly supervised. •...
  • Page 8 ENGLISH those for which it has been designed. • Deep-fryers must be kept under constant supervision • Do not operate the appliance using an external timer or separate remote controlled system. • The appliance must never be installed behind a decorative door, to prevent it from overheating.

  • Page 9: Installation

    ENGLISH Installation Installation process must follow the laws, must be mounted with heat-resistant ordinances, directives and standards (electrical safety rules and regulations, unsuitable material and adhesives may proper recycling in accordance with the result in warping and detachment. regulations, etc.) in force in the country •...

  • Page 10: Electrical Connection

    • If the cables are damaged, replace with removing the junction box cover. original spare parts cables. Contact the • Check that the domestic power supply call center of your IKEA store. characteristics (voltage, maximum power and current) are compatible with those of the Caution! Do not solder any of the appliance.
  • Page 11 ENGLISH Connection diagram product side L1 L2 L3 N1 N2 Insert the shunts between the screws as shown = Black = Brown = Blue = Black = Yellow / Green = Blue = Yellow / Green...

  • Page 12: Product Description

    ENGLISH Product description Single cooking area (210 x 190 mm) 2100W, with Booster 3000W. Single cooking area (210 x 190 mm) 2100W, with Booster 3000W. Single cooking area (200 mm) 2300W, with Booster 3000W. Single cooking area (145 mm) 1400W, with Booster 1850W. Control panel Bridge cooking area (210 x 380 mm) 3000W, with Booster 3700W.

  • Page 13: Control Panel

    ENGLISH Control panel Power level indicator Timer symbol Timer control and cooking time indicator Melting function button Lock function button Pause function button Scroll keypad The cooking areas can be activated by pressing the reference digit . The digit lights up more When a pan is placed on one of the 4 cooking areas, the hob automatically detects its presence and turns on the corresponding digit to put it into use.

  • Page 14: Power Limitation

    ENGLISH Power limitation based on the actual abilities and capacity of the power supply itself. If this is not necessary, the hob can be turned on directly using , otherwise, follow the operations below to access the menu. Connect the hob to the domestic mains power All the digits light up for a few seconds, than they go out only the Press and hold the and digits of the zones show...

  • Page 15: Functions

    ENGLISH Functions This function prevents an accidental operation of the appliance. placed press and hold for 3 seconds one of the 4 digits (not visible) near the dot on the left side. Child lock All the digits display The operations described must be completed within 10 seconds. The operations described must be completed within 10 seconds.
  • Page 16 ENGLISH Timer with alarm for generic use. Press the digit to access the Timer menu and view “ 0 0 0 “. Hours Minutes Timer (generic) Tenths by pressing any of the buttons. Repeat the operations described to modify the countdown value. The digit for the selected area will show Melting or press...

  • Page 17: Cooking Table

    ENGLISH This function is used to recall all the hob function settings in the event of involuntary shut-down or a sudden power cut. Recall , the Function for 6 seconds. Press the button to recover the functions set previously. A beep sounds to This function allows 2 cooking areas to be connected, so that they can be controlled as a single, large cooking area.

  • Page 18: User Menu Customization

    ENGLISH User menu customization Press Press again and hold for 3 seconds. The button Press and hold the and digit of the zone show Holding start pressing the zones digitis in clock direction, starting from the bottom left. The back left hand digit alternately shows and a number from 2 to 7, indicating the type of menu.

  • Page 19: Power Management

    ENGLISH Power Management This product is equipped with electronically controlled Power Management. See the illustration. This function monitors electric loading and limits the maximum power output to 3700 W for each cooking area group (1+2 and 3+4), optimizing the power distribution and preventing the system from overloading.

  • Page 20: Cookware Guidance

    ENGLISH Cookware guidance What pots to use Empty or thin-based pots/pans Only use pots and pans with bottom made Do not use empty or thin-based pots/pans from ferromagnetic material which are on the hob as it will not be able to monitor the temperature or turn off automatically if •...

  • Page 21: Care And Cleaning

    ENGLISH regulate the temperature of the electronic The noise occurs on the cookware and can system. The fan may also continue to run vary depending on the amount of food or liquid and the cooking method (e.g., boiling, detected temperature of the cooktop is still simmering, frying).

  • Page 22: Troubleshooting

    ENGLISH Troubleshooting Error Possible causes of the Description Solution code error Continuous key activation detected. Remove water or cookware from glass ER03 10 sec. Water or cookware placed on and Control panel. Control panel. Let the hob cool down. The internal temperature of ER21 ventillation.
  • Page 23 If there is a fault, try to resolve it by following the troubleshooting guidelines. If the problem cannot be resolved, contact your IKEA store or the After Sales Service. contacts at the end of this user manual. When contacting the After Sales...

  • Page 24: Hob Technical Data

    Total power 7400 Parameter Value Power supply voltage/frequency Weight of the appliance 8,8 Kg Energy efficiency of hob BEJUBLAD 504.673.07 304.678.17 Number of cooking areas Number of Bridge cooking areas 1 - Left Cooking technology Induction Dimension of Bridge cooking area...

  • Page 25: Rating Plate

    EEC Directives. Rating plate Made in Italy Made in Italy © Inter IKEA Systems B.V.1999 © Inter IKEA Systems B.V.1999 504.673.07 304.678.17 Design and Quality Design and Quality...

  • Page 26: Environmental Aspects

    ENGLISH Environmental aspects Disposal of packaging materials Disposal of household appliances Materials with the symbol can be • The symbol on the product or on recycled. Dispose of packing materials in its packaging indicates that the product special recycling collection bins. must not be disposed of with the normal domestic waste.

  • Page 27: Ikea Guarantee

    Product in a commercial environment. pliance and wish to register a service call The exceptions are specified under the or make a claim, please refer to www.ikea. headline “What is not covered under this com.au for your local store after sales cus- tomer service center phone number, online the costs to remedy the fault e.g.
  • Page 28 ENGLISH What will IKEA do to correct the prob- ing a technician’s visit. lem? • Repairs not carried out by our appointed IKEA appointed service provider will exam- service providers and/or an authorized ine the product and decide, at its sole dis- service contractual partner or where non- cretion, if it is covered under this guarantee.
  • Page 29 Australian Consumer Law on the ACCC www.accc.gov.au Area of validity This IKEA guarantee applies only to prod- The IKEA after sales customer service centre ucts purchased and installed in AUSTRALIA . will assist you on the phone with basic...
  • Page 31 Country name in local languages Telephone number Opening times Victoria: (03) 8523 2154 New South Wales: (02) 5020 6641 Australia Queensland: (07) 3380 6800 IKEA Perth: (08) 9201 4532 IKEA Adelaide: (08) 8154 4532 Österreich 13602771461 Mo-Fr: 8 - 20 België / Belgique 26200311...
  • Page 32 23199 © Inter IKEA Systems B.V. 2020 AA-2231726-2...
