BEJUBLAD
AU

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BEJUBLAD and is the answer not in the manual?

Questions and answers

Related Manuals for IKEA BEJUBLAD

Summary of Contents for IKEA BEJUBLAD

  • Page 1 BEJUBLAD...
  • Page 3 ENGLISH...

  • Page 4: Table Of Contents

    List of functions Recommended use and tips Description of display Electrical connection Daily use Electrical connection for Australia Cooking tables Environmental concerns Cleaning and maintenance IKEA GUARANTEE Safety Information Your safety and that of others perform all unpacking and are very important. installation operations. This manual and the appliance - The appliance must be itself provide important safety...
  • Page 5 ENGLISH pole circuit breaker with a if they have been given contact separation (at least 3 supervision or instruction mm) in all poles that provide concerning use of the full disconnection under appliance in a safe way and overvoltage category III and understand hazards involved.
  • Page 6 ENGLISH aperture above the control children away from the oven panel. Do not obstruct the during the pyrolysis cycle. vent apertures. (only for ovens with Pyrolisis - Use oven gloves to remove function). pans and accessories, taking - During and after the care not to touch the heating Pyrolytic cleaning, every pets elements.

  • Page 7: Product Description

    ENGLISH Product description Control panel Bottom heating element (not visible) Cooling fan (hidden) Oven door Upper heating element/Grill Lateral Grids Rear oven lamp Oven fan The cooling fan may continue running even after the oven is switched off. During the pyro-clean cycle the fan runs faster than during normal cooking functions.
  • Page 8 ENGLISH Inserting wire shelves and other Remove the blue film as shown in the accessories in the oven image 1. Insert the wire shelf horizontally, with the raised part “A” upwards (Fig. 1). How you align the tray with the telescopic runners. Place the drip tray on the telescopic runners fixing it between the rear and front fastener. Fig. 1 2. Other accessories, such as the drip tray and baking tray, are inserted in the same way as the wire shelf (Fig.

  • Page 9: Control Panel

    ENGLISH Control panel Function selector knob Selection/Confirmation button Browse knob Note: the control knobs are retractable. Press the knobs in the middle and they pop List of functions Turn the “Functions” knob to any position and the oven switches on: the display shows the functions or the associated submenus.

  • Page 10: Description Of Display

    ENGLISH Description of display Display of heating elements activated Internal oven temperature during the various cooking functions Pyrolisis function (not available on this Time management symbols: timer, model) cooking time, end of cooking time, time Browning Information regarding selected functions Special functions: defrosting, keep Automatic BREAD/PIZZA function warm, rising selected...
  • Page 11 ENGLISH Oven functions table The oven has 4 cooking levels. Count up from the lower level. Function Description of function To stop cooking and switch off the oven. FORCED AIR To cook a variety of food requiring the same cooking temperature on two shelves at the same time (e.g: fish, vegetables, cakes).
  • Page 12 ENGLISH Function Description of function SPECIAL FUNCTIONS To speed up defrosting of food. Place food on the middle shelf. Leave food in its packaging in order to prevent it from drying out on the outside. DEFROST For keeping just-cooked food hot and crisp (e.g: meat, fried food or flans).

  • Page 13: Daily Use

    ENGLISH Daily use Selecting cooking functions When the set temperature is reached, the corresponding value (e.g. 200°) and an acoustic signal will sound. At the end of preheating, the oven automatically selects the conventional function At this point food can be placed in the 1.
  • Page 14 ENGLISH 1. Turn the “Functions” knob till the display shows “ DEFROST” along with this function’s corresponding symbol. 2. Turn the “Browse” knob to scroll the To delay the end of cooking time, and thus list of functions: DEFROST, KEEP WARM, also the cooking start time, proceed as RISING, ECO FORCED AIR.
  • Page 15 ENGLISH to start cooking. button 4. During a cooking function, if the Eco Pizza Mode is activated, the cavity lamp will be switched off after 1 minute of cooking and reactivated for each user interaction. 2 4 5 Acoustic signal 1. Turn the Functions knob to symbol To activate or deactivate the acoustic signal, the display shows “BREAD”.

  • Page 16: Cooking Tables

    ENGLISH Cooking tables Type of food Function Preheating Level Temperature Cooking Accessories (from the (°C) time bottom) (min) Leavened 160-180 30-90 Cake tin on wire cakes shelf 160-180 30-90 Shelf 3: cake tin on wire shelf Shelf 1: cake tin on wire shelf Filled pies –...
  • Page 17 ENGLISH Type of food Function Preheating Level Temperature Cooking Accessories (from the (°C) time bottom) (min) Bread/pizza/ 190-250 15-50 Drip tray/ focaccia baking tray 190-250 25-50 Shelf 3: baking tray Shelf 1: drip tray Bread 180-220 30-50 Drip-tray / baking tray or rack Pizza 220-250 15-30...
  • Page 18 ENGLISH Type of food Function Preheating Level Temperature Cooking Accessories (from the (°C) time bottom) (min) Turkey / Goose 190-200 80-130 Drip tray or 3 Kg oven tray on wire shelf Baked fish / en 180-200 40-60 Drip tray or papillote (fillet, oven tray on whole) wire shelf Stuffed...
  • Page 19 ENGLISH Type of food Function Preheating Level Temperature Cooking Accessories (from the (°C) time bottom) (min) Roast Beef rare – 2 (medium) 35-50 Oven tray on 1 Kg wire shelf (turn food two thirds of the way through cooking if necessary) Leg of lamb / –...
  • Page 20 ENGLISH Type of food Function Preheating Level Temperature Cooking Accessories (from the (°C) time bottom) (min) Fish & 30-50* Shelf 3: oven Vegetables tray on wire shelf Shelf 1: drip tray or oven tray on wire shelf Stuffed roasts – 80-120* Drip tray or oven tray on wire shelf Meat pieces...

  • Page 21: Cleaning And Maintenance

    ENGLISH Cleaning and maintenance CLEANING Accessories • Soak the accessories in water with WARNING! washing up detergent immediately after Never use steam cleaning equipment. use, handling them with oven gloves if Only clean the oven when it is cool to still hot. the touch.
  • Page 22 The lamp used in the appliance is specifically designed for electrical appliances and it is not suitable for household room illumination (Commission Regulation (EC) No 244/2009). Lamps are available from IKEA Authorized Service Centre. To replace the rear lamp 1. Disconnect the oven from the power supply.

  • Page 23: What To Do If

    • your full address; If after the above checks the fault still occurs, • your telephone number. contact IKEA Authorized Service Centre. Always specify: If any repairs are required, please contact • a brief description of the fault; IKEA Authorized Service Centre (to •...

  • Page 24: Technical Data

    ENGLISH Technical data According to EU 66/2014. Type of product: Built-in Electrical Oven Model identification: BEJUBLAD 10322043 Number of cavities Heat source Electrical Number of functions Usable volume. Measured with any side grids and catalytic panels removed l 65 Area of the largest baking sheet cm...

  • Page 25: Installation

    ENGLISH Technical data The technical informations are situated in the rating plate inside the appliance. Installation After unpacking the oven, make sure that Do not remove the rating plate situated it has not been damaged during transport on the right side of the door frame. and that the oven door closes properly.
  • Page 26 ENGLISH Door lock device To open the door with the door lock device see Fig 1. Fig. 1 The door safety device can be removed by following the sequence of images (see Fig. 2). Fig. 2...

  • Page 27: Recommended Use And Tips

    ENGLISH Recommended use and tips How to read the cooking table - If using non-stick cake tins, do not butter the The table indicates the best function to use edges as the cake may not rise evenly around for any given food, to be cooked on one or the edges.

  • Page 28: Electrical Connection

    1,5 mm ) must be carried out by a qualified the mains voltage. The rating plate is on electrician. Contact IKEA Authorized Service the front edge of the oven (visible when the Centre. door is open).

  • Page 29: Environmental Concerns

    ENGLISH Environmental concerns Disposal of packing material Energy saving tips The packing material is 100% recyclable Only pre-heat the oven if specified in and is marked with the recycle the cooking table or your recipe. symbol ( ). The various parts of the Use dark lacquered or enamelled packing must therefore be disposed of baking moulds as they absorb heat far responsibly and in full compliance with...

  • Page 30: Ikea Guarantee

    Which appliances are not covered by the by faulty construction or material faults IKEA five (5) years guarantee? from the date of purchase from IKEA. This The range of appliances named LAGAN . guarantee applies to domestic use only. The products have been designed and tested for...
  • Page 31 Transportation damages. If a customer supply voltage via connection to Supply transports the product to his home or Authority mains or alternative supply another address, IKEA is not liable for systems. any damage that may occur during • Consumable parts including batteries transport.
  • Page 32 You are also entitled to have the goods Please refer to the IKEA catalogue or www. repaired or replaced if the goods fail to be ikea.com.au or to below phone numbers of acceptable quality and the failure does and select your local store .
  • Page 36 400010808449 © Inter IKEA Systems B.V. 2015 19069 AA-1755500-1...
