- Page 1 241-9895 18 GAUGE ELECTRIC METAL SHEAR Operator’s Manual SAVE THIS MANUAL You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING : When using electric tools, machines or equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and personal injury. READ INSTRUCTIONS BEFORE USING THIS TOOL 1. KEEP WORK AREA CLEAN. Cluttered areas invite injuries. 2. -
Page 3: Safety Precautions
IMPORTANT SAFETY INSTRUCTIONS 13. USE THE RIGHT TOOL. Don’t force a small tool or attachment to do the work of a larger industrial tool. Don’t use a tool for a purpose for which it was not intended. 14. DRESS PROPERLY. Don’t wear loose clothing or jewelry; they can be caught in moving parts. -
Page 4: Specifications
SPECIFICATIONS Voltage: 120 volts AC, 60Hz. Current rating: 3.5 amps No load speed: 1800 rpm Max shear thickness: 18Gauge OPERATING PROCEDURES 1. Following all safety requirements already listed, plug the Power Cord (54) into a circuit-breaker protected 120 V~, 60 Hz power outlet. -
Page 5: Maintenance
MAINTENANCE Check the condition of this tool every time before using it. 1. Before each use, plug in the tool, and turn it on to run freely for one minute. A f t e r the toofl has run for one mfinute, turn fit off, and put 3 Power Switch (38) -4 drops of light machine oil in the oil port on the head of the tool. -
Page 6: Replacing Carbon Brushes
MAINTENANCE Replacing Carbon Brushes. Brush Cap (43) After considerable use, your Electric Metal Shear may not run as well as usual. If it starts or runs slowly, makes a grinding noise or will not run at all, the problem may be worn Carbon Brushes. An extra set of Carbon Brushes is included with your tool for replacement as needed. -
Page 7: Parts List
PARTS LIST part description Q’ty part description Q’ty Tool Rest Socket Head Screw m4 X 58 Lower Shear Blade (Fixed) Stator Spring Pin m4 x 30 Ball Bearing 626-2RS Plain Washer m6 Rubber Washer Spring Washer m6 Housing Socket Head Screw m6 x 12 Socket Head Screw m12 x 30 Lock Nut m5 Nameplate... -
Page 8: Schematic Drawing
SCHEMATIC DRAWING...
