- Page 1 207-4825 PNEUMATIC MULTI-FUNCTION TOOL Operator’s Manual SAVE THIS MANUAL You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
- Page 2 IMPORTANT SAFETY INSTRUCTIONS WARNING: Read and understand all instructions. Failure to follow all instructions listed below may result in electricshock, fire and/or serious injury. WARNING: The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions or situations that could occur.
- Page 3 IMPORTANT SAFETY INSTRUCTIONS 13. Disconnect the tool from the air source before making any adjustments, changing accessories, or storing the tool. 14. Maintain the tool with care. Keep a cutting tool sharp and clean. A properly maintained tool with sharp cutting edges reduces the risk of binding and is easier to control.
-
Page 4: Specifications
SPECIFICATIONS SPECIFICATIONS Variable speed: 0-20,000 OPM Oscillation angle: 1.5 [Left/Right] Air pressure: 90 PSI Sanding CFM: 3.5 CFM@40PSI 4.4CFM@90PSI Cutting CFM: 3.5 CFM@40PSI 4.4CFM@90PSI Hose size: 3/8” Air inlet: 1/4” NPT Machine weight: 1.70 Ibs INCLUDES: 1pc pneumatic multi-function tool 21pc accessory kit 3-1/2”... - Page 5 OPERATING PROCEDURES Unpacking Note: This air tool may be shipped with a protective plug covering the air inlet. Remove this plug before set up. Air Supply WARNING: TO PREVENT EXPLOSION Use only clean, dry, regulated, compressed air to power this tool. Do not use oxygencarbon dioxide, combustible gases, or any other bottled gas as a power source for this tool.
- Page 6 OPERATING PROCEDURES OPERATION: Turn the tool off, detach the air supply, safely discharge any residual air pressure in the tool, and release the throttle and/or turn the switch to its off position before assembling or making any adjustments to the tool WORK PIECE AND WORK AREA SET UP 1.
-
Page 7: Maintenance
OPERATING PROCEDURES WARNING: To prevent tooland accessoryfailure, resulting in injury. do not exceed the tool’s maximum air pressure rating of 90 psi. if the tool still does not have sufficient airflow, then a larger tool may be required. 13. To prevent accidents, tum of f the tool by releasing the Trigger Lever (41), detaching the air supply, and safely discharging any residual air pressure in the tool after use. -
Page 8: Troubleshooting
TROUBLE SHOOTING PARTS LIST... -
Page 9: Schematic Drawing
SCHEMATIC DRAWING WARNING Repairs should be made by an authorized repair center. Do not this power tool . Contact at open or disassemble 1-866-915-8626 for questions regarding this power tool. - Page 10 TOOL SHOP® PNEUMATIC MULTI-FUNCTION TOOL WARRANTY 1-YEAR LIMITED WARRANTY: This brand power tool carries a 1-Year Limited Warranty to the TOOL SHOP® original purchaser. If the tool fails within one (1) year from the date of purchase, simply bring this tool with your original sales receipt back to your nearest retail store.
