Page 2 VAA30001-R.3636.A CONTENTS SPECIFICATIONS ･･･････････････････････････････････････････････････････････････････Ｍ１－Ｍ２ DISASSEMBLING WARNING ･･･････････････････････････････････････････････････････････････････････････Ｄ１ Rear cover ･･････････････････････････････････････････････････････････････････････Ｄ２－Ｄ３ Discharge Main condenser････････････････････････････････････････････････････････････････Ｄ４ Front cover ････････････････････････････････････････････････････････････････････････････Ｄ５ Battery cover / Battery terminal････････････････････････････････････････････････････････････Ｄ６ Battery holder / Battery terminal / Control release ･････････････････････････････････････････････Ｄ６ LCD ･････････････････････････････････････････････････････････････････････････････････Ｄ７ Holder monitor･････････････････････････････････････････････････････････････････････････...
Page 3 VAA30001-R.3636.A Battery cover ････････････････････････････････････････････････････････････････････････Ａ１６ Control release / Battery holder ･･････････････････････････････････････････････････Ａ１６－Ａ１７ Front cover ･･････････････････････････････････････････････････････････････････････････Ａ１８ Rear cover ･･････････････････････････････････････････････････････････････････････････Ａ１９ ADJUSTMENT ･････････････････････････････････････････････････････････････････Ａ２０－Ａ２７ DISCRIPTION OF CIRCUIT･･･････････････････････････････････････････････････････････Ｅ１－Ｅ８ ELECTRICITY OVERALL WIRING ････････････････････････････････････････････････････････････････････Ｅ９ OVERALL BLOCK DIAGRAM ････････････････････････････････････････････････････････････････Ｅ１０ ASIC BLOCK DIAGRAM ･･･････････････････････････････････････････････････････････････Ｅ１１ CCD BLOCK DIAGRAM ･･･････････････････････････････････････････････････････････････...
Page 4: Specifications
VAA30001-R.3636.A SPECIFICATIONS Type E4100 digital camera Effective pixels 4.0 mega-pixels 1/2.5-inch high-density CCD; total pixels: 4.23 mega-pixels Image size (pixels) 2288×1712, 2048×1536, 1600×1200, 1024×768 and 640×480 Lens 3×Zoom Nikkor f = 5.8 to 17.4mm (38 ~ 105mm by conversion with 35mm-format) F2.8 ~ F4.9 Digital zoom Max.
Page 5 DC input terminal, AV output terminal which is also used as USB terminal Power sources Two rechargeable Nikon EN-MH1 NiMH batteries, One CR-V3 lithium battery, Two LR6 (AA) alkaline batteries, . Two ZR6 (AA) nickel manganese batteries, Two FR6/L91 (AA) lithium batteries, EH-62B AC adapter...
Page 6 VAA30001-R.3636.A Disassembly �� ・Lead-free solder is used for this product. ・For soldering work, the special solder and soldering iron are required. ・Do NOT mix up lead-free solder with traditional solder. ・Use the special soldering iron respectively for lead-free solder and lead solder. They cannot be used in common.
Page 7 VAA30001-R.3636.A Rear cover ・Open the cover ( ① ). ・Take out 2 screws ( ② : M1.7 × 5). ・Take out 2 screws ( ③ : M1.7 × 4.5). ・Take out 2 screws ( ④ : M1.7 × 4). ・ Open the SD card cover side of the rear cover and unhook it as pushing its top by your finger.
Page 8 VAA30001-R.3636.A Push. Push. Push. Rear cover SD card cover (Fig 1) FPC ⑤ (Fig 2) - D3･ E4100 -...
Page 9 VAA30001-R.3636.A Discharge Main condenser �� 2KΩ/5W - D4･ E4100 -...
Page 10 VAA30001-R.3636.A Front cover ・Remove the lead wire (black: ① ) and lead wire (red: ② ). ・Remove the FPC ( ③ ). ・Take out 3 screws ( ④ : M1.7 × 4). ・Remove the front cover by pulling it forwards. ・The stand (tripod: ⑤...
Page 11 VAA30001-R.3636.A Battery cover / Battery terminal ・ Take out 2 screws ( ① : M1.7 × 2.5), and remove the battery terminal ( ② ). ・ The battery cap ( ③ ), battery terminal ( ④ ) and battery knob ( ⑤ ) come off. ・...
Page 12 VAA30001-R.3636.A ・Remove the FPC ( ① ). ・Remove the lead wires (white: ② and red: ③ ). (Fig. 1) ・Remove the LCD. Holder monitor ・Take out 2 screws ( ④ : M1.7 × 4). ・Take out the screw ( ⑤ : M1.7 × 2.5). ・The holder monitor comes off.
Page 13 VAA30001-R.3636.A CP1-PCB / TB1-PCB / CCD ・ Take out the screw ( ① : M1.7 × 3). ・ Remove the FPC ( ② ). ・ Take out 2 screws ( ③ : M1.7 × 6). ・ The lens assembly comes off. ・...
Page 14 VAA30001-R.3636.A Note : All of the FFD adjustment tools are not prepared yet. The lens-barrel can be disassembled and assembled. However, each of the 1st, 2nd and 3rd lens group units (lens) cannot be replaced with a new one. Finder unit ①...
Page 15 VAA30001-R.3636.A Separate Zoom motor unit. ・Unsolder the FPC unit. ・Take out the screw ( ① : M1.4 × 2.5). ・Remove the photo interrupter FPC. ・Take out the screw ( ② : M1.4 × 4.2). ③ ・Take out the 2 screws ( ③ : M1.4 × 3.5). ・The zoom motor unit comes off.
Page 16 VAA30001-R.3636.A Hook ③ ① ② ⑥ ⑤ ⑦ ④ - D11 ･ E4100 -...
Page 17 VAA30001-R.3636.A Separate Lens-barrel ① ② ② ・Remove the solder of the shutter FPC and take out the screw ( ①：M1.4 × 2). ・Take out 3 screws ( ②：M1.4 × 3.5). ・Remove the shutter FPC from the CCD base. ・Detach the lens barrel by moving it slowly in the direction indicated by the arrow. The finder gear A and B come off at the same time.
Page 18: Side View
VAA30001-R.3636.A Shutter Turning tube ・Rotate the turning tube in the direction indicated by the arrow, to extend the lens-barrel to the maximum. Barrier joint plate ② ① Ａ Barrier joint plate ＡＡ【Side view】・Remove the barrier joint plate by pulling it in the direction of A. - D13 ･...
Page 19 VAA30001-R.3636.A ・Rotate the turning tube to the full up position, to reduce the lens-barrel size. ・Remove the shutter unit by lifting it in the direction of the arrow. ① 2nd lens frame Shutter ・Take out 2 screws ( ①：M1.4 × 3.5) to separate the 2nd lens frame from the shutter. - D14 ･...
Page 20 VAA30001-R.3636.A Straight tube (1st lens frame) / key tube Note : The 1st lens group unit (frame) cannot be replaced with a new one. Straight tube (1st lens frame) Turning tube unit Hook Lens-barrel cover Key tube Hook Turning tube ・Remove the turning tube unit from the lens-barrel cover.
Page 21 VAA30001-R.3636.A 3rd lens unit / Zoom motor unit Note : The 3rd lens group unit (frame) cannot be replaced with a new one. 3rd lens spring Focus motor 3rd lens unit Turning stopper ・Remove the 3rd lens spring. ・Turn the focus motor shaft counterclockwise with a flathead screw driver, and remove the 3rd lens unit and turning stopper.
Page 22 VAA30001-R.3636.A Assembly Barrier unit Barrier ring Straight tube (1st lens frame) Spring Barrier Name plate ・Attach the barrier ring to the straight tube (1st lens frame), and hook the spring. ・Attach the barrier by turning it slightly in the direction indicated by the arrow. ・Attach the name plate.
Page 23 VAA30001-R.3636.A Straight tube (1st lens frame) / key tube Turning tube Section B Light-shielding ring Key tube Section A ・Align Section A with Section B and push in the key tube by turning counterclockwise. ・Turn the key tube clockwise until it contacts with the stopper. ・Align Section D of the 1st lens frame with Section C of the turning tube and assemble them.
Page 24 VAA30001-R.3636.A Shutter ① 2nd lens frame Shutter ・Assemble the shutter and 2nd lens frame with 2 screws ( ①：M1.4 × 3.5). Shutter unit Lens-barrel cover ・Assemble the shutter unit into the turning tube by following the above direction of the arrow. - A3･...
Page 25 VAA30001-R.3636.A Barrier joint plate ・Rotate the turning tube in the direction indicated by the arrow, to extend the lens-barrel to the maximum. 【Side view】・Attach the barrier joint plate by pressing slightly in the direction of A arrow. - A4･ E4100 -...
Page 26 VAA30001-R.3636.A 3rd lens unit 3rd lens spring Focus motor 3rd lens unit Turning stopper ・While turning the focus motor shaft clockwise with a flathead screwdriver, assemble the 3rd lens unit and the turning stopper into the CCD base. ・Turn the focus motor shaft further until the 3rd lens unit slightly touches the bottom, then give it about one turn counterclockwise.
Page 27 VAA30001-R.3636.A Assemble Lens-barrel / CCD base ・Attach the gear A to the CCD base. ・Attach the finder gear B to the CCD base. ・Pass the shutter FPC through the hole of the CCD base, and assemble the lens-barrel. ・Set the finder gear C and insert the gear shaft. ・Apply the cemedine 575 on the tip of the gear shaft from the rear surface of the CCD base.
Page 28 VAA30001-R.3636.A ① ① ・Tighten the 3 screws ( ① : M1.4 × 3.5). Solder it. ② Shutter FPC. Fit the shutter FPC to the boss. ・Tighten the screw ( ② : M1.4 × 2). ・Fit the shutter FPC into the boss of the CCD base and apply the cemedine 575. ・Solder the shutter FPC.
Page 29 VAA30001-R.3636.A Assemble Zoom motor unit. ・Attach the motor to the cover ( ① ). Note : Let the character-stamped surface of the motor face in a correct direction before attaching. (Fig. 1) ・Tighten the 2 screws ( ② : M1.4 × 1.8). ・Insert the shaft ③...
Page 30 VAA30001-R.3636.A ⑪ ・Tighten the screw ( ⑫ : M1.4 × 2.5). ⑫ - A9･ E4100 -...
Page 31 VAA30001-R.3636.A Install Zoom motor unit. ① ③ Photo interrupter Zoom motor unit ・Attach the zoom motor unit to the CCD base with the lens barrel at the W-end. ・Tighten the screw ( ① : M1.4 × 4.2). ・Tighten the 2 screws ( ② : M1.4 × 3.5). ・Set the photo interrupter and tighten the screw ( ③...
Page 32 VAA30001-R.3636.A Finder unit ① Finder unit Lens-barrel ・Set the finder unit to W-end manually. ・Enter the protrusion of the finder unit into the hole of the lens-barrel as shown by ( ○ ), and assemble them by pushing in the direction of the arrow. ・Tighten 2 screws ( ①：M1.4 ×...
Page 33 VAA30001-R.3636.A CCD / TB1-PCB / CP1-PCB ・Arrange the shield tape ( ① ), spacer ( ② ), and lens mount ( ③ ). Assemble the CCD ( ④ ) and solder the CP1-PCB. ・Solder the lead wires (gray: ⑤ and white: ⑥ ). ・Assemble the spacer ( ⑦...
Page 34 VAA30001-R.3636.A Holder flash ・Solder the lead wires (red: ① , gray: ② , and white: ③ ). (Fig. 1) ・Place the lead wires in position as shown below. Attach the holder flash and tighten the screw ( ④ :M1.7 × 4). (Fig.
Page 35 VAA30001-R.3636.A ② ① ③ ② ① ③ (Fig 1) (Fig 2) (Fig 3) (Fig 4) - A14 ･ E4100 -...
Page 36 VAA30001-R.3636.A Arrange LCD wires ⑭ ⑬ (Fig 5) - A15 ･ E4100 -...
Page 37 VAA30001-R.3636.A Battery cover ・Mount the battery cover knob ( ① ), battery terminal ( ② ), battery cap ( ③ ) and battery terminal ( ④ ) on the battery cover, and tighten 2 screws ( ⑤ : M1.7 × 2.5). ・Attach the battery cover and front cover with the battery cover shaft ( ⑥...
Page 38 VAA30001-R.3636.A ⑩ ⑫ (Fig 1) (Fig 2) - A17 ･ E4100 -...
Page 39 VAA30001-R.3636.A Front cover ・Attach the front cover on the body by following the below direction. ・Attach the stand (tripod: ① ). ・Connect the FPC ( ② ). ・Solder the lead wires (black: ③ and red: ④ ). ・Tighten 3 screws ( ⑤ :M1.7 × 4). ・Attach the shaft strap ( ⑥...
Page 40 VAA30001-R.3636.A Rear cover ・Connect the FPC ( ① ). rear cover ・Attach the rear cover. ・Tighten 3 screws ( ② :M1.7 × 4). ・Tighten 2 screws ( ③ :M1.7 × 4.5). ・Tighten 2 screws ( ④ :M1.7 × 5). ① ②...
Page 41 VAA30001-R.3636.A ADJUSTMENT 1. Equipment IBM compatible PC/AT • AC adapter EH-62B • USB cable ( UC-E6) 　　 2. Servicing tools Pattern box • • Color meter • Luminance meter • Siemens star chart • Calibration software (J65066) 　　 •Adjustment collimator (J63090) or Adjustment firmware 　　...
Page 42: Installing Usb Driver
VAA30001-R.3636.A 5. Installing USB driver If the USB driver is necessary, install Nikon View via CD-ROM packed with the camera. 6. Pattern box Before using the pattern box, turn its power on to carry out "Aging" approx. 30 minutes: the color temperature should be 3100 ±...
Page 43: Connecting The Camera To The Computer
VAA30001-R.3636.A 8. Connecting the camera to the computer 1) Insert the camera connector of USB cable in the notch of the camera’s USB port. 2) Connect the cable to the USB port on PC. To USB port USBポートへ USB Cable USBケーブル...
Page 44 VAA30001-R.3636.A 10. Lens adjustment ※ For the lens adjustment, choose either the infinity adjustment with the collimator or the 1.5-m adjustment with the adjustment firmware. (However, in case of 1.5-m adjustment, the focus may not be sharp at infinity.) 10-1. Infinity adjustment [Preparations] •...
Page 45 VAA30001-R.3636.A 10-2. 1.5-m Adjustment 　※ Before performing the 1.5-m adjustment in this machine, write the adjustment firmware on the camera. After adjustment, be sure to write the product firmware. Procedure for setting Adjustment firmware 1) Save the adjustment firmware and the product firmware in any folder. 2) Start up "DscCa1Di140"...
Page 46 VAA30001-R.3636.A 11. AWB adjustment [Preparations] 　• Pattern Box(Color temperature: 3100±20K, Luminance: 900±20cd/m [Conditions] • Set the pattern box and camera (lens front) at "0cm" distance between them. Note) Do not allow outside light to enter in. [How to] • Double-click on "DscCa1Di140". •...
Page 47 VAA30001-R.3636.A 12. CCD white dot defect compensation [Conditions] • With the lens shutter being closed, read the defect of CCD pixels. Then, make the correction data and rewrite the data by the following procedure. Correct the upper level of defective 1300 pixels from the brightest number of CCD pixels.. [How to] •...
Page 48: Usb Storage Information Registration
• Double-click on the "DscCa1Di140". • Click on the "Get" button in the USB storage window and check the USB storage data. VID: NIKON PID: NIKON DSC E4100 Serial: Rev. : 1.00 • Check the “Serial” in the above USB storage data. If the displayed value is different from the serial number printed on the base of the camera, enter the number on the base of the camera, and click the "Set"...
Page 49 VAA30001-R.3636.A �� ø�� ø�� ø�� ø�� ...
Page 50 VAA30001-R.3636.A �� ...
Page 51 VAA30001-R.3636.A �� ...
Page 52 VAA30001-R.3636.A �� - E4･ E4100 -...
Page 53 VAA30001-R.3636.A �� ...
Page 54 VAA30001-R.3636.A �� ...
Page 55 VAA30001-R.3636.A �� ...
Page 56 VAA30001-R.3636.A �� ...
Page 57: Lcd Panel
VAA30001-R.3636.A 総合結線図 OVERALL WIRING LCD PANEL WHITE JW504 LED_A JW601 LED_A JW505 LED_C JW602 LED_C GRAY CN110 & USB_VDD JW501 BAT+ (RED) USB D(-) VIDEO BATTERY USB D(+) JW502 BAT-(BLACK) ZAV_JACK AUDIO_OUT VIDEO_OUT (DMA) W1400 XAN (RED) FLASH (CAA) W1600 TRG (GRAY) REFLECTOR W1500 XKT(BLACK) (SYA)
Page 58: Overall Block Diagram
VAA30001-R.3636.A 総合ブロック図 OVERALL BLOCK DIAGRAM CCD BLOCK LENS BLOCK IC903 IC902 IC901 IIN1,2 4M Pixel CDS/AGC/AD-C LENS IC951 SIN1,2 H. Driver V. Driver FIN(1:4) LENS DRIVER IC106 D-FF CN301 IC121 MRST FD(0:7) RELEASE UNIT FLASH(NAND) ZTEST 128Mbit PLLEN D(0:15) FLASH(NOR) 16Mbit A(1:20) CN302...
Page 59 VAA30001-R.3636.A ASIC ブロック図 ASIC BLOCK DIAGRAM SDRAM IC101 ASIC SDRAM DIGITAL CONTROLLER BLOCK CLAMP SIGNAL SRAM PROCESSOR SRAM JPEG AF,AE,AWB CONTROLLER UART COMPOSITE VIDEO NTSC/PAL SRAM ENCODER CONNECTOR DIGITAL 6bit DATA SD CARD AUDIO DRIVER IC301 36MHz MICRO DRIVER BUS I/F CLKGEN PROCESSOR 98MHz...
Page 60: Ccd Block Diagram
VAA30001-R.3636.A CCD ブロック図 CCD BLOCK DIAGRAM V1,V2,V3A,V3B,V4,V5A,V5B,V6 SUBC VDD3 24, 37, 6 34, 35 - E12 ･ E4100 -...
Page 61: Lens Drive Block Diagram
VAA30001-R.3636.A レンズ駆動ブロック図 LENS DRIVE BLOCK DIAGRAM SW REG. UNREG IC955 BOOST4.35V L9551 UNIT LENS D9551 CN951 C9554 12, 15 Q9509 VDD3 ZPLUSE1 PICTRL (IC301 23pin) ZPLUSE2 ZPULSE1 (IC301 16pin) Q9502 ZPULSE2 (IC301 59pin) ZOOM_PI ZRESET (IC301 58pin) Q9501 FOCUS_PI FPIOUT (IC101 231pin) IC951 LB8649W...
Page 62: Power Block Diagram
VAA30001-R.3636.A POWER ブロック図 POWER BLOCK DIAGRAM CNT2 CNT3 CNT6 ON/OFF - E14 ･ E4100 -...
Page 63: System Block Diagram
VAA30001-R.3636.A SYSTEM ブロック図 SYSTEM BLOCK DIAGRAM IC304 RESET IC UNREG Boost4.35V BOOST4.35V TO DMA (MAIN) ALWAYS3.2V 6 32 IC302 BLON BL_ON BATTERY P ON BACKUP P ON PA ON Q3002 RESET PA_ON CHG ON VMONIT BAT OFF VMONIT LCD ON LCD ON BATTERY SELF LED...
Page 64 VAA30001-R.3636.A PWA 回路図 ( ストロボ回路図 ) PWA CIRCUIT DIAGRAM (STROBE CIRCUIT DIAGRAM) FLASH REFLECTOR 1AV4L17B0200G T5401 P1-67400/SX795-JNK OM/ORDD44Z OM/ORLIV006HZ D5403 D5402 W1400 290V RR264M-400 F1P8 �� T5402 OM/ORDD30HVZ 3225 1AV4L17B0160N H=1.7 H=1.9 C5410 W1600 GRAY 0.047;350H R5414 1608 1K;1/16J...
Page 65 VAA30001-R.3636.A FUSE ARRANGEMENT (CP1 PCB) Fuse Function Phenomenon when it has Rating blown out singly Used to protect the unit when The power of the camera is 　F5001 ２．０A　３２V the DC/DC converter circuit not turned on. malfunctions. 　F5002 Used to protect the unit when The power of the camera is ２．...
Page 66 VAA30001-R.3636.A The contents of inspection standards and tools for E4100 [1] Inspection standards ..........................R1 to R7 [2] Tools ................................. T1 to T3 - E4100 -...
Page 67 VAA30001-R.3636.A ［２］工具一覧表　　Tool List ※：新規工具 ※：New tool 名　　称備　考工具番号 Name Remarks Tool No. パターンボックス　LV-1450DC 共通 (E4300, E3500, J63080 Pattern Box LV-1450DC E3100, E2100, E5400, E3700, E3200, E2200, E8700, E4100) Common(E4300, E3500, E3100, E2100, E5400, E3700, E3200, E2200, E8700, E4100) 交換用ハロゲンランプ...
Page 68 VAA30001-R.3636.A ※：新規工具 ※：New tool 工具番号名　　称備　考 Tool No. Name Remarks J65066 共通 (E995,E775,E885 キャリブレーションソフト ※ Calibration Software E5000, E2500, E4500 E5700, E4300, E3500 E3100, E2100, E5400 E3700, E3200, E2200 E8700, E4100) Common(E995,E775,E885 E5000, E2500, E4500 E5700, E4300, E3500 E3100, E2100, E5400 E3700, E3200, E2200 E8700, E4100) J63090...
Page 69 VAA30001-R.3636.A - T3･ E4100 -...
