Flo Slatwall Installation Instructions Manual page 4

Fix the arm to the slatwall / toolbar
1
USEFUL TIP
Use Allen Key supplied to open
jaws slightly more than the gap
in the slatwall / toolbar
Do not overtighten
Recommended 5 N/m
38mm min*
91mm max*
*Will vary depending on design of slatwall / toolbar
Locate top jaw into the slatwall / toolbar
2
Tighten fixing screw to secure arm
3
IMPORTANT
Support the weight
of the arm whilst
ensure bracket is
flush against extrusion
Check jaws are fully engaged against slatwall / toolbar
4
1.6mm
Min
6.5mm
Max
IMPORTANT
to slatwalls / toolbars
with rounded surfaces
5
USEFUL TIP
Hold arm at an
angle to locate
top jaw into the
slatwall / toolbar
Use screws provided with monitor
Mount monitor to arm
6
To remove monitor
Adjust arm to suit weight of the monitor
7
9kg/19.8lb
DO NOT exceed
maximum load
8
Ensure that portrait / landscape
PUSH
IMPORTANT
it may spring up when unloaded
Heavier
Lighter
monitor
monitor
USEFUL TIP
Adjustment will be easier amd
90˚
approx
DYN-013-004-INST-A OCT2011
Turn adjuster
monitor 'floats'
in all height
90˚
approx
USEFUL TIP
When installing
similar monitors
of arms you can
installed arm. This will give
for the other arms. You can
quickly 'dial in' to the same
fine tune the adjustment to
balance the monitor
