- Page 1 CI-RL-LR12-TF Rear-view camera-input video-in-motion for Landrover touch-screen navigation systems from model 2012 Only for vehicles WITHOUT factory rear-view camera Version 28.05.2014 CI-RL-LR12-TF...
-
Page 2: Table Of Contents
Contents 1. Prior to installation 1.1. Delivery contents 1.2. Check compatibility of vehicle and accessories 1.3. Setting the Dip-switches of the CAN-Box TV-400/500 1.4. Pin-assignments 2. Connection schema 3. Installation 3.1. Interconnecting CAN-box, harness and factory navigation monitor 3.2. Connection to rear-view camera 4. -
Page 3: Prior To Installation
Changes/updates of the vehicle’s software can cause malfunctions of the interface. We offer free software-updates for our interfaces for one year after purchase. To receive a free update, the interface must be sent in at own cost. Labor cost for and other expenses involved with the software-updates will not be refunded. - Page 4 1.3. Setting the dip switches of the CAN-box TV-400/500 TV-400 Alle vehicles dip 1 ON, dip 2 ON, dip 3 ON Note: Setting dip 1 to ON codes the factory rear-view camera input which is located on the 6pin male connector of the factory monitor. When reverse gear is engaged, the navigation will automatically switch to this input.
- Page 5 Version 28.05.2015 RL-LR12-TF...
-
Page 6: Pin-Assignments
1.4. Pin-assignments Pin-assignment factory monitor connector Cable colour Assignment ●● Orange/grey CAN-HIGH Pin 2 ●● Orange/purple CAN-LOW Pin 1 No liability for vehicle wire colors and pin definition! Possible changes by the vehicle manufacturer. The given information must be verified by the installer. Pin-assignment of the CAN-Box TV-400 (Molex 8pin) Cable colour Pin-No. -
Page 7: Connection Schema
2. Connection schema 3. Installation Switch off ignition and disconnect the vehicle’s battery! If according to factory rules disconnecting the battery has to be avoided, it is usually sufficient to put the vehicle in sleep-mode. In case the sleep-mode does not show success, disconnect the battery with a resistor lead. -
Page 8: Interconnecting Can-Box, Harness And Factory Navigation Monitor
3.1. Interconnecting CAN-Box, harness and factory navigation monitor Connect female 8pin Molex connector of harness TV-LR02 to male 8pin Molex connector of CAN-box TV-400/500. Transfer female 16pin connector of vehicle harness from rear of the factory navigation monitor into male 16pin connector of harness TV-LR02. Plug female 16pin connector of harness TV-LR02 into male 16pin connector on the rear of the factory navigation system. -
Page 9: Activation Of The Video-In-Motion Function
Connect the video RCA of the rear-view camera to the female RCA connector of adapter CAB-TV-AS20. Note: Only compatible with NTSC-cameras. 4. Activation of the video-in-motion function TV-400 The video-in-motion function is activated permanently without disturbing the navigation performance. Note: The loose white and green cable are not required and must be isolated. TV-500 The video-in-motion can be activated and deactivated by Dip 1 or alternatively by the included loose green cable in connection with a switch (not included in delivery). -
Page 10: Specifications
5. Specifications Operation voltage 10.5 – 14.8V Stand-by power drain <2mA Operation power drain ~60mA Power consumption ~0,08W Temperature range -30°C to +80°C Weight Measurements (box only) W x H x D 70 x 20 x 47 mm/ 76 x 27 x 54 mm Legal disclaimer: Mentioned company and trademarks, as well as product names/codes are registered trademarks ®...
