For Users
The unit should be cleaned when it gets dirty-roughly
once every three months as a general rule. Also, make
sure to clean and perform a test run before starting full
operation for the summer and winter seasons.
CAUTION
During cleaning or maintenance, do not climb
on an unstable stand.
Injury may result if you tumble down.
Always switch power off before cleaning the
unit.
Never hang from the unit or push downward on
it forcefully. It could result serious accident.
Wear gloves to avoid injuring your fingers.
If the unit is mounted in a high place (about 5
m), contact the dealer.
Disassembling the Unit
1. Remove the guard stopper screw and the washer.
Then slide the guard as shown in the figure and
remove it from the hook.
2. Remove the fan nut (M5 counterclockwise
threading) and pull off the fan.
Note
- Note that the fan fits onto the shaft in a specific
orientation.
Nut *
Screw
(M5 counterclockwise)
Guard
Fan
Washer
Washer
Hook
Unit
* The tightening torque of the nut is 1.1 N・m.
Maintenance and lifetime Specifications
Fan motors are service parts. It is
Model
necessary that the regular check
and the regular replacement or the
replacement when it is broken. In
AH-1006S1-E
addition, expenses for parts and
replacement work is charged to
customers.
AH-1509S1-E
After-Sales Service
Consult with your dealer about the AH-2009S1-E
after-sales services provided for
this unit.
AH-3012S1-E
* The noise values were measured at 1.5 m inclined at 45° from the center
of the air outlet.
Manufactured by: MITSUBISHI ELECTRIC CORPORATION
TOKYO BLDG. 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO, 100-8310 JAPAN.
Cleaning the Unit
Use a cloth dipped in neutral detergent to wipe dirt
away from the main unit, guards, and fans. Then
wipe with a dry cloth to remove any remaining
detergent.
Note
- Do not use solvents such as the following to clean
the unit:
Paint thinner, alcohol, benzine, gasoline, kerosene,
aerosol sprays, alkaline solvents or chemicals
in chemically treated cleaning clothes. (Surface
deterioration or discoloration could result.)
Reassembly and Inspection after Cleaning
After cleaning, reverse the disassembly steps to
reassemble the unit.
Inspect the following items as you reassemble the
unit.
1. The fan fits onto the shaft in a specific orientation.
Be sure not to install it upside-down.
2. Have the main unit, screws, washers, fans, nuts,
and guards all been mounted securely?
3. Switch power on and check that the unit operates
properly.
Unit
Air Rating
Fan Airflow Rate Noise
Power Source Velocity Current
Speed (m /h) (dB)
3
(m/s) (A)
High 7.5-8.0 740-790 42-43 0.15-0.16
220-240 V~ 50 Hz
Low 6.0-6.6 600-650 37-39 0.13-0.14
High 7.1 700 41 0.18
220 V~ 60 Hz
Low 5.2 520 33 0.15
High 7.6-8.1 1260-1340 44.5-46 0.25-0.26
220-240 V~ 50 Hz
Low 5.5-6.6 910-1100 38-41 0.22-0.24
High 7.4 1220 44 0.31
220 V~ 60 Hz
Low 4.9 820 35 0.24
High 8.7-8.9 1450-1470 47-47.5 0.41-0.49
220-240 V~ 50 Hz
Low 7.2-7.5 1200-1250 43.5-45.5 0.34-0.35
High 9.9 1640 50 0.47
220 V~ 60 Hz
Low 6.4 1060 40 0.36
High 7.8-7.9 1740-1760 47.5-48.5 0.45-0.53
220-240 V~ 50 Hz
Low 6.6-7.2 1460-1600 46-47 0.38-0.40
High 8.8 1950 51 0.60
220 V~ 60 Hz
Low 5.5 1220 52 0.43
AIR CONDUCTING FAN
MODEL
AH-1006S1-E, AH-1509S1-E, AH-2009S1-E, AH-3012S1-E
OPERATING AND INSTALLATION INSTRUCTIONS
• Carefully read this manual before use for safe and correct operation.
For users
• Keep this manual where any person using the unit can refer at anytime.
• The unit has thermal fuses to prevent overheating. When they blow and some fan motors
stop, turn the circuit isolator off and contact the dealer.
• Carefully read this manual before work for safe and correct installation.
For dealers
• Installation must be performed by a qualified contractor/installer and electrical wiring by a
qualified electrician.
• This unit is for indoor use. Do not install the unit in a place where it may be exposed to rain.
• After completing installation, be sure to give this manual to the user.
• Installation in an inappropriate place may cause malfunctions. In addition to the following
WARNING and CAUTION, avoid the following locations:
- the salt damage area
- where the temperature range is outside between -10 and 45°C
- where freezing is anticipated, such as a refrigerated storage or freezing chamber
- where there is a high concentration of oil mist or steam
- where the air is likely to contain plenty of cotton, dust, or cloudy/powdery sand dust
- where it is exposed combustible gases, and acid or alkaline gases
- where troubles may occur when dust or the like accumulated on the unit falls.
Safety Precautions
• The following symbols denote the type and degree of danger resulting from incorrect handling.
No water
Prohibited
exposure
WARNING
Do not use the unit where the combustion
Starting
Weight
Current
(kg) device will be directly exposed to wind.
(A)
Otherwise, it may cause incomplete combustion
leading to carbon monoxide poisoning.
0.23 7
Do not install the unit where explosive
gas or dust could be emitted.
It could induce explosion or fire.
0.36 10.5
If the unit is installed where poisonous fume
is produced, be sure to ventilate sufficiently.
Otherwise, it may result in poisoning due to the
0.88 11
poisonous fume.
Do not modify or disassemble the unit.
Otherwise, it may result in fire, electric shock or injury.
0.91 13
Do not operate with wet hands.
Otherwise, it may result in electric shock.
Do not put your fingers or any objects in
the air outlet.
Otherwise, you may injure yourself.
If operation stops while the power is still
switched on, do not touch the unit under
any circumstances.
Sudden start may result in injury or electrical shock.
No
Do not
Do not wet
disassembly
touch
Incorrect handling could cause serious injury or death.
Do not expose with water.
Otherwise, it may result in short circuit or electric
shock.
Operate the unit at the rated voltage and
rated frequency.
Otherwise, it may result in fire or electric shock.
When the power supply cable passes
through metal or wire lath in the
wall, securely prevent the cord from
contacting to them.
Otherwise, it may result in fire or power leakage.
Make sure to ground and install an all-
pole electric leakage isolator securely.
Make sure to turn off the circuit isolator before
maintenance or in case of power failure.
Otherwise, it may result in injury or electrical shock.
Install the unit at least 2.3 m above the
floor.
Otherwise, it may result in injury.
If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in
order to avoid a hazard.
-1-
1805876H05001
Cannot be
Follow
installed in a
instructions
bathroom
