- Page 1 LTI’s TruPoint 300 Interface to Collector and Survey123 Quick Reference Guide...
- Page 2 Overview LTI’s TruPoint 300 laser is a versatile tool for making accurate measurements for Building Information Management, Joint-use Pole inventories and other applications. These dimensions can be consumed as text input directly within Esri’s Collector and Survey123 apps, providing a seamless integration into the workflow.
- Page 3 Configure the TruPoint 300 All of the measurement routines on the TruPoint 300 are available as text output over a Bluetooth connection. Distance, angles and dimensions can be sent directly into any text form (*The exception is any routine that includes data from the horizontal encoder – these are sent over WiFi only.) 1.
- Page 4 Configure the TruPoint 300 All of the measurement routines on the TruPoint 300 are available as text output over a Bluetooth connection. Distance, angles and dimensions can be sent directly into any text form (*The exception is any routine that includes data from the horizontal encoder – these are sent over WiFi only.) Select what to do with the Cursor and the Decimal format (Figure 5) Press the Left Arrow function button repeatedly to save these settings and return to the...
- Page 5 Connect the Laser to the Device The first time you use a TruPoint 300, you must pair it with your device. It is compatible with Windows, Apple and Android operating systems. Make sure your laser is powered On with BT On before continuing.
- Page 6 Send Measurements to the App Almost all of the measurement routines can be selected for Bluetooth output. Using the required measurement routine on the TruPoint 300, such as Height Tracking, complete the sequence to display the result (Figure 9) 10. Open the app, such as Collector, and position the cursor in the form (Figure 10) 11.
- Page 7 Sending Measurement Tips All of the onboard measurement routines on the TruPoint 300 can send the answer they generate over Bluetooth. • Look for the blue Transfer symbol (right program key) to send the data (Figure 13) • If you need to send another part of the solution, use the scroll arrows to place that data in the window and then press Transfer (Figure 14) •...
- Page 8 Keyboard Tips In this communication mode, the TruPoint 300 connects to your device as a keyboard. This will override the on-screen keyboard and here are the ways to get it back: Android: Install a Keyboard Manager from Google Play, such as “Quick Keyboard Switch” and use this app to display the on-screen keyboard (Figure 17) iOS: on the TruPoint 300, press the left program key (inside turns green) and then the +/- key in the lower right corner.
-
Page 9: Product Resources
Product Resources http://www.lasertech.com/TruPoint-300-Total- http://www.esri.com/products/survey123 Station.aspx https://www.esri.com/en- us/arcgis/products/collector-for-arcgis Stay informed! Find out about Laser Technology products, updates, and training resources by keeping track of us on FaceBook (/LaserTechnologyInc), Twitter (@LaserTechPro) and YouTube (/user/LaserTechPro) - Page 10 Contact Laser Technology, Inc. Questions regarding the interface of the TruPoint 300 to mobile apps? Please contact us at: 1.800.280.6113 or 1.303.649.1000 info@lasertech.com Laser Technology, Inc. 6912 S. Quentin St. Centennial, CO 80112 www.lasertech.com...
