- Page 1 KING-METER USERS GUIDE LED 790...
- Page 2 Appearance and Size ............2 1.1 Specifications ............... 2 1.2 Display Size (Unit：mm) ..........2 1.3 Operation Faceplate ............ 3 Function Instruction ............3 2.1 Battery Indication ............3 2.2 Turn on/off e-bike’s headlight ........4 2.3 Four levels of assistant power ........4 Quality Warranty ............
- Page 3 1. Appearance and Size 1.1 Specifications Rated Voltage Operating Room temperature -10℃ to 50℃, No condensation Environment 82*42*56 Size (unit: mm) Holder diameter 22.2mm CE, RoHS Certification 1.2 Display Size (Unit：mm)
- Page 4 1.3 Operation Faceplate 2. Function Instruction 2.1 Battery Indication The four LED will indicate the current voltage of battery. When battery is lack of voltage, the minimum power indicator will flash. But the controller will not power off. High voltage Low Voltage LED Flash...
- Page 5 2.2 Turn on/off e-bike’s headlight Press the button to turn on or off e-bike’s headlight. When turn the headlight on, the indictor is on. When turn headlight off, the indictor is black Turn headlight on Turn headlight off 2.3 Four levels of assistant power There are 4 levels of assistant power.
- Page 6 Assistant power Level 2, only assistant power indicator “ECO” is on. As follow picture. Assistant power Level 3, only assistant power indicators “TOUR” is on. As follow picture. Assistant power Level 4, only assistant power indicators “SPORT” is on. As follow picture. 3.
