Observe all local plumbing and building codes.
·
Prior to installation, unpack the new lavatory and inspect it
for damage. Return the lavatory to its protective carton
until you are ready to install it.
·
All information in these instructions are based the latest
product information available at the time of publication.
Kohler China reserves the right to make changes in
product characteristics, packaging, or availability at any
time without notice.
·
Fixture dimensions are nominal and conform to tolerances
established by ASME Standards (A112.19.2-2013).
·
The product complies with GB/T 6952-2015.
IMPORTANT:
Make sure that the wall and floor are square
and plumb to ensure proper installation.

ORDERING INFORMATION

Modern Life 600mm Vanity.................... K-77835T-1/-4/-8
REQUIRED MATERIALS/
(NOT SUPPLIED)
·
Level
·
Drill with
6mm
bit
·
14mm wrench
·
Framing square
·
Channel lock pliers
·
Tape measure
·
Pencil
