Installation Guide

Bathroom Sink Faucet

M product numbers are for Mexico (i.e. K-12345M)

Los números de productos seguidos de

M corresponden a México (Ej.

K-12345M)

Français, page "Français-1"

Español, página "Español-1"

1244026-2-A

K-7514, K-7515, K-7516,

K-7517, K-7518, K-7519,

K-13460, K-13461, K-13462,

K-13463, K-13466, K-13467,

K-13468, K-13469, K-13472,

K-13473, K-13475, K-13475,

K-45344, K-45345

Need help?

Do you have a question about the K-7514 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kohler K-7514

Page 1 Installation Guide Bathroom Sink Faucet K-7514, K-7515, K-7516, K-7517, K-7518, K-7519, K-13460, K-13461, K-13462, K-13463, K-13466, K-13467, K-13468, K-13469, K-13472, K-13473, K-13475, K-13475, K-45344, K-45345 M product numbers are for Mexico (i.e. K-12345M) Los números de productos seguidos de M corresponden a México (Ej.
Page 2 The faucet shown in this guide may differ from your actual product. The installation steps still apply. In order for this faucet to function properly, install the faucet so the sensor points directly toward the user. The faucet is rated at 3 V DC 1 W. 1244026-2-A Kohler Co.
Page 3 1-1/4″ (32 mm). NOTE: Before drilling the mounting hole, use the following provisions for proper placement: A 1-1/4″ (32 mm) minimum to 1-1/2″ (38 mm) maximum diameter mounting hole is required. Kohler Co. 1244026-2-A...
Page 4 Insert the spout with ﬂexible hoses and stud through the mounting hole. From under the sink, slide the rubber washer and bracket onto the stud. Thread the nut onto the stud to secure the faucet to the mounting surface. 1244026-2-A Kohler Co.
Page 5 Tighten the connections with a small adjustable wrench. Turn on the water and ﬂush the faucet by activating it. NOTE: For optimum performance, clean your ﬁlter screens periodically. Refer to the Maintenance Guide. Kohler Co. 1244026-2-A...
Page 6 Mount the Hybrid Energy Cell (HEC) under the counter using two screws (not supplied). Connect the HEC to the faucet wire. Avoid the area in front of the sensor for 2 minutes. 1244026-2-A Kohler Co.
Page 7 Orient as shown. Remove the cover. Connect the faucet wire to the faucet. If needed, cut and strip the AC supply wires to length. Connect the stripped ends to the bottom terminal block (TB2) in the supply box. Kohler Co. 1244026-2-A...
Page 8 IMPORTANT! The area in front of the sensor must be free of objects during the 2 minute learning cycle or the faucet may not function properly. Allow 2 minutes for the sensor to cycle through the automatic sensing distance. 1244026-2-A Kohler Co.
Page 9 IMPORTANT! The area in front of the sensor must be free of objects during the 2 minute learning cycle or the faucet may not function properly. Allow 2 minutes for the sensor to cycle through the automatic sensing distance. Kohler Co. 1244026-2-A...
Page 10 105°F (41°C), complete the following steps. NOTICE: Do not rotate the handle when removing the screw. Using the 2.5 mm hex wrench provided, remove and retain the handle screw. Remove and retain the handle with the spring washer. 1244026-2-A Kohler Co.
Page 11 Using the handle, adjust the water to the desired temperature. Using the 2.5 mm hex wrench provided, remove and retain the screw, spring washer, and handle. Position the vandal-resistant plug button and ﬁrmly press into place. Kohler Co. 1244026-2-A...
Page 12 Check for leaks and adjust as needed. Temporarily cover the sensors on the faucet or close the water supplies. Using the key provided, reinstall the aerator to the spout. Uncover the sensors on the faucet or turn on the water supplies. 1244026-2-A Kohler Co.
Page 13 Maintenance Guide Touchless Bathroom Sink Faucet K-13460, K-13461 K-13466, K-13467 K-13472, K-13473 Français, page “Français-1” Español, pagina “Español-1” 1102759-5-D...
Page 14 October 10, 2008 EC DECLARATION OF CONFORMITY Kohler Company 444 Highland Drive, Kohler, WI 53044 Phone 920-457-4441 declare under our sole responsibility that our products, Wallmount Touchless sensor, models: K-13460 K-13461 K-13466 K-13467 K-13472 K-13473 K-13460W K-13461W K-13466W K-13467W K-13472W...
Page 15 • Use a soft, dampened sponge or cloth. Never use an abrasive material such as a brush or scouring pad to clean surfaces. For detailed cleaning information and products to consider, visit www.kohler.com/clean. To order Care & Cleaning information, call 1-800-456-4537. Kohler Co.
Page 16 Slide the spout forward and off the body. Reassemble Slide the spout over the body until the base of the spout is ﬂush against the mounting surface. Reinstall the screw into the back of the faucet. 1102759-5-D Kohler Co.
Page 17 Disassemble/Reassemble the Faucet (cont.) Reinsert the temperature lever with spring washer into the faucet. Reinstall the screw to secure the temperature lever to the faucet. Kohler Co. 1102759-5-D...
Page 18 Temperature Limiting Adjustment″ section and follow the instructions. If you are installing the handle assembly, refer to the illustration in the ″Optional Temperature Limiting Adjustment″ section. Otherwise, reinstall the plug button. Position the plug button and ﬁrmly press into place. 1102759-5-D Kohler Co.
Page 19 105°F (41°C), complete the following steps. NOTICE: Do not rotate the handle when removing the screw. Using the 2.5 mm hex wrench provided, remove and retain the handle screw. Remove and retain the handle with the spring washer. Kohler Co. 1102759-5-D...
Page 20 Using the handle, adjust the water to the desired temperature. Using the 2.5 mm hex wrench provided, remove and retain the screw, spring washer, and handle. Position the vandal-resistant plug button and ﬁrmly press into place. 1102759-5-D Kohler Co.
Page 21 Insert two AAA Alkaline batteries (not provided) into the battery case. Reinstall the two screws into the battery case. Reassemble the faucet. Wait approximately two minutes to allow the faucet to cycle through the automatic sensing distance before use. Kohler Co. 1102759-5-D...
Page 22 United States of America, Canada and Mexico (″North America″). If a defect is found in normal residential use, Kohler Co. will, at its election, repair, provide a replacement part or product, or make appropriate adjustment where Kohler Co.’s inspection discloses any 1102759-5-D Kohler Co.
