Little Wren Cot Bed
L4943
Assembly Difficulty
two-person job
easy -
medium
- hard
Thank you for shopping with GLTC, we hope you enjoy
having this product in your home.
We know assembling furniture, toys or accessories is not everyone's
favourite way to spend their time, so we've tried to make assembling
this item as quick and painless as possible.
Hopefully our efforts will have been worthwhile and you'll sail
through the whole process. But if it all feels a bit too much
like hard work, then we do have an assembly company we
can recommend: the Flatpack Construction Company offers a
nationwide service and can be contacted on 0843 289 4951 or
www.flatpackconstruction.co.uk.
A few important pointers before you start:
•
Please read the instructions right through before you start, and check
that all the components have been included in the pack; we find
separating all the hardware into piles makes it easier to be sure that
everything is present and correct.
•
Make sure you have the right tools. Allen keys are provided if required,
but screw drivers and other tools are not. You'll find details of the tools
you need at the beginning of the instructions.
•
It's a good idea to build the unit in the room where you are going to be
using it, to avoid the need to move it after it's been assembled.
•
Do not throw away any packing materials until assembly is complete,
just in case you accidentally discard smaller parts or hardware.
V1
21/07/2020
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Great Little Trading Little Wren Cot Bed L4943
Summary of Contents for Great Little Trading Little Wren Cot Bed L4943
- Page 1 Thank you for shopping with GLTC, we hope you enjoy having this product in your home. We know assembling furniture, toys or accessories is not everyone’s favourite way to spend their time, so we’ve tried to make assembling this item as quick and painless as possible. Hopefully our efforts will have been worthwhile and you’ll sail Little Wren Cot Bed through the whole process.
-
Page 2: For Future Reference
IMPORTANT! READ CAREFULLY - RETAIN • DO NOT use the cot if any part is broken, torn or missing and use only FOR FUTURE REFERENCE. spare parts approved by the manufacturer. • DO NOT leave anything in the cot or place the cot close to another product, which could provide a foothold or present a danger of suffocation Safety Warnings: or strangulation, e.g. -
Page 3: Customer Service
Customer Service: • DO NOT use this child’s bed if any part is broken, torn or missing. Use only spare parts approved and supplied by the manufacturer. • If you find that any components are missing or damaged, please do not begin assembly and do not use the item. -
Page 4: Component Checklist
Component Check List Pre-assembled 8pcs 12x Top Hat Nuts 4x Base Support (8pcs currently inserted into the bed 1x LH Headboard/Footboard 1x RH Headboard/Footboard Brackets base) 2x Nuts 4x Wooden Dowels 2x Side Panels 1x Toddler Bed Front Panel (M6) 1x Slatted Base Panel 2x Split Washers 2x Flat Washers... - Page 5 Hardware for Step 2: Hardware for Step 1: 2x #1 Long Bolts (60mmL) 4x #7 Wooden Dowels FRONT extra drill holes Caution with using the Allen Key. Do not fully tighten. STEP 2: Take head/footboard panel A and attach side panel C using 2x long bolts (#1). Tighten the bolts with your fingers at this stage.
- Page 6 Hardware for Step 3: The help of a second The help of a second person is recommended person is recommended 2x #1 Long Bolts (60mmL) for this step. for this step. STEP 4: STEP 3: Take remaining side panel C and position in between the two head/footboards (A &...
- Page 7 STEP 6: Hardware for Step 5: Hardware for Step 6: Setting up the Cot Bed in the upper position The help of a second person is recommended 4x #1 Long Bolts (60mmL) 4x #5 Base Support Brackets for this step. Take 4x bed base support brackets (#5) and insert the non-threaded end into the upper holes of head/ STEP 5:...
- Page 8 STEP 8: Hardware for Step 7: NOW you can fully tighten ALL the hardware on the head and foot boards The help of a second using an allen key. There are 8 in total and some are now underneath the base person is recommended 4x #6 Top Hat Nuts - ensure all are tightened.
- Page 9 STEP 9: 5. When brackets Changing the Cot Bed from Upper to Mid Position. The help of a second are in place with Please follow these steps - No new hardware is needed. person is recommended their threaded for this step. ends facing up, carefully put the base panel back...
- Page 10 STEP 10: The help of a second person is recommended Changing the Cot Bed from Mid or Upper Position to Lowest Base Position. for this step. (this change involves different hardware from previous adjustments) STEP 12: Carefully remove the front side panel C. BACK Remove the 4x base support brackets (#5) from the head/foot boards.
- Page 11 STEP 13: STEP 14: Remove 4x short bolts (#3) from the head and Take base panel E and using both the allen keys remove all the pre-installed hardware foot boards as shown. from all 4 sides (4x #3 short bolts, 4x #2 mid bolts & 8x #6 Top Hat Nuts). HARDWARE NO LONGER REQUIRED - Keep in a safe place for future use.
- Page 12 STEP 15: Hardware for Step 15: The help of a second person is recommended Use the 4x #2 mid bolts (40mm) & 4x #6 Top Hat for this step. Nuts that were removed from step 14 to fill in the STEP 16: holes in the corners of base panel E.
- Page 13 STEP 18: The help of a second Re-position the front side panel (C) on the bed frame - STEP 17: Hardware for Step 17: person is recommended ensuring the wooden dowels are connected with the head for this step. Insert 2x mid bolts (#2) into the drill holes that and foot boards.
- Page 14 STEP 19: The help of a second STEP 20: person is recommended CHECK ALL FITTINGS ARE FULLY TIGHTENED BEFORE USING THE COT Transforming the Cot Bed into a Toddler Bed for this step. BED IN THIS POSITION. With the help of a 2nd person, carefully rotate the cot bed onto its back.
- Page 15 STEP 22: STEP 21: The help of a second With the help of a second person, stand the bed on its feet. Remove base panel E from the bed frame and put person is recommended for this step. Identify the panel C that is on the ‘front’ of the bed. to one side.
- Page 16 STEP 24: STEP 23: Remove the 4x short bolts (#3) that are inserted into the head and foot Carefully remove the front side panel C and put to one side. This panel is not boards. needed for the transformation into the toddler bed, so please wrap/store for future use.
- Page 17 STEP 26: STEP 25: Hardware for Step 25: Take the toddler bed front panel (D) and position over the threaded rod at Insert 2x threaded rods (#4) into BOTH head/ one end of the bed frame. foot boards (A & B). Once in place, gently ease the other end of the front panel over the threaded x2 #4 Threaded Rods (80mmL) Use the second hole up from the bottom and...
- Page 18 Hardware for Step 27: STEP 27: Holding the front panel in place, insert 4x long bolts (#1) The help of a second person is recommended into the upper and lower holes connecting the panel to the 4x #1 Long Bolts (60mmL) STEP 28: for this step.
- Page 19 HARDWARE instructions in a safe place so you can refer to them for future use. Copyright© 2020 G.L.T.C. Ltd. All rights reserved. Great Little Trading Company and GLTC are registered trade marks of G.L.T.C. Limited.
