Ethernet (8/Unit) - Siemens SIMATIC NET RUGGEDCOM RS969 Installation Manual

Accessories
6.4 Ethernet (8/unit)
6.4

Ethernet (8/unit)

M12 D-code Ethernet Port Mating Cable
Figure 6.7
M12 D-code Ethernet Port Mating Connector
Figure 6.8
34
M12 D-code Ethernet Port
Mating Cable
M12 D-code Ethernet Port
Mating Connector
Description
•
M12 D-code to RJ45; patch cable,
3meters
• Order Code
99-43-0040-001
• Cable Specifications
M12 D-code male 4 pin, CAT5e, 3m
• Description
M12-straight plug, 4 pole, D-coded,
IP67 rated
• Order Code
99-60-0008
Installation Manual, 01/2021, C79000-G8976-1038-03
RUGGEDCOM RS969
