4. GV-Tower NVR System V2 (Rev. D)

4.1 Main Screen

1
No. Name
1 Logout / Exit / Minimize
2
Select screen divisions
Select a camera for full screen
3
mode
4 Start/stop recording
5 Set up recording schedules
6 Access system settings
Access ViewLog to play back
7
video
2 3
No.
8
9
10
11
12
13
14
11
10
4 5 6 7 8
Name
Start/stop screen rotation
Access remote applications
Camera Name
Date / Time / Storage Space
Status indicators for remote applications
Click to call up PTZ Control Panel
Click to call up I/O Control Panel
11
12
13
14
9
