Summary of Contents for Uni-ram UM80 Series
- Page 1 UM80 SERIES WALL MOUNT SPRAY GUN CLEANERS WATER BORNE UM80W, UM80WA,UM80WF SOLVENT BORNE UM80S CAUTION DO NOT USE WATER BORNE UNITS WITH SOLVENT BORNE PAINT SOLVENT BORNE UNITS WITH WATER BORNE PAINT UNI-RAM CORPORATION • ONTARIO • CANADA Revised 2015-5-30...
- Page 2 Aqua-Kleen is a state-of-the-art cleaning additive with an enhanced corrosion inhibitor for optimal protec- tion of spray guns. UM80W / UM80WA Two 5-litre bottle-type containers are included with the unit. • Fill one container with clean water and add half of a bottle of Uni-ram Aqua Kleen.
- Page 3 • Move the pail outside the unit. Remove the two filters. Pour half of a bottle of Uni-ram Aqua Kleen into the pail and add tap water until the combined liquid level reaches the bottom of the filter holder.
-
Page 4: Right Side
MANUAL - WALL MOUNT WATERBORNE GUN CLEANERS - UM80 SERIES REVISED 2015-5-30 FRONT UM80S UM80W / UM80WA RIGHT SIDE UM80S UM80W / UM80WA... - Page 5 MANUAL - WALL MOUNT WATERBORNE GUN CLEANERS - UM80 SERIES REVISED 2015-5-30 • Clean the Cap by rubbing it on the Flat Brush mounted on the inside of the tank. • Exterior Cleaning - Clean the exterior of the gun with the Flow-through brush. Activate the flow of liq- uid through the Brush by turning the long arm of the Selector Knob to the left to the Brush position.
-
Page 6: Left Side
MANUAL - WALL MOUNT WATERBORNE GUN CLEANERS - UM80 SERIES REVISED 2015-5-30 LEFT SIDE UM80S UM80W / UM80WA UM80WA HAS ADDTIONAL AIR OUTLET FOR EXTERNAL FLOCCULATION... -
Page 7: Troubleshooting Procedures
MANUAL - WALL MOUNT WATERBORNE GUN CLEANERS - UM80 SERIES REVISED 2015-5-30 TROUBLESHOOTING PROCEDURES PROCEDURE 1 Blocked Fluid Passage In Diaphagm Pump If the pump sounds like it is working but liquid does not flow, clear the fluid passage as follows: •... -
Page 8: Troubleshooting Chart
MANUAL - WALL MOUNT WATERBORNE GUN CLEANERS - UM80 SERIES REVISED 2015-5-30 TROUBLESHOOTING CHART SYMPTOM REASON ACTION PUMP LEAKS AIR OR Pump is defective Replace pump LIQUID WASH LIQUID DOES NOT • Wash pail empty • Check wash wash level... - Page 9 MANUAL - WALL MOUNT WATERBORNE GUN CLEANERS - UM80 SERIES REVISED 2015-5-30 FLOW DIAGRAM - UM80W (WA Model not shown) Use the diagram to trace the flow of compressed air and water.
- Page 10 MANUAL - WALL MOUNT WATERBORNE GUN CLEANERS - UM80 SERIES REVISED 2015-5-30 FLOW DIAGRAM - UM80WF Use the diagram to trace the flow of compressed air and water.
- Page 11 MANUAL - WALL MOUNT WATERBORNE GUN CLEANERS - UM80 SERIES REVISED 2015-5-30 FLOW DIAGRAM - UM80S Use the diagram to trace the flow of compressed air and water.
-
Page 12: Replacement Parts
MANUAL - WALL MOUNT WATERBORNE GUN CLEANERS - UM80 SERIES REVISED 2015-5-30 REPLACEMENT PARTS DESCRIPTION PART NUMBER AIR BLOW GUN 102-7010 DIAPHRAGM PUMP UDP2TAB AQUA-KLEEN PAINT GUN CLEANER 102-8200 COAG-KLEEN FLOCCULANT 102-8300 FILTER BAG, PRIMARY 102-8125 FILTER BAG, SECONDARY 102-8126... - Page 13 "Conditions of Warranty" as consumables are not covered. Uni-ram reserves the right to direct the customer to ship the unit collect to the Uni-ram factory or to an approved Service Center for repair using the Uni-ram Return Goods Procedure or to repair the unit on-site.
