Pentair Fleck 3150 Downflow Service Manual page 16

1800 SERIES BRINE SYSTEM AND
DRAIN LINE FLOW CONTROL
ASSEMBLY continued
Item No. QTY Part No.
21 ........................ 60711-000 .........DLFC, 2" NPT, Less BTTNS, w/4
........ 60711-00 ...........DLFC, 2" NPT, Less BTTNS,
........ 60711-01 ...........DLFC, 2" NPT, Less BTTNS,
........ 60711-20 ...........DLFC, 2" NPT, 20 gpm
........ 60711-25 ...........DLFC, 2" NPT, 25 gpm
........ 60711-30 ...........DLFC, 2" NPT, 30 gpm
........ 60711-35 ...........DLFC, 2" NPT, 35 gpm
........ 60711-40 ...........DLFC, 2" NPT, 40 gpm
........ 60711-45 ...........DLFC, 2" NPT, 45 gpm
........ 60711-50 ...........DLFC, 2" NPT, 50 gpm
........ 60711-55 ...........DLFC, 2" NPT, 55 gpm
........ 60711-60 ...........DLFC, 2" NPT, 60 gpm
........ 60711-65 ...........DLFC, 2" NPT, 65 gpm
........ 60711-70 ...........DLFC, 2" NPT, 70 gpm
........ 60711-75 ...........DLFC, 2" NPT, 75 gpm
........ 60711-80 ...........DLFC, 2" NPT, 80 gpm
........ 60711-85 ...........DLFC, 2" NPT, 85 gpm
........ 60711-90 ...........DLFC, 2" NPT, 90 gpm
........ 60711-95 ...........DLFC, 2" NPT, 95 gpm
........ 60711-100 .........DLFC, 2" NPT, 100 gpm
........ 60812-30 ...........DLFC, 2" BSP/Metric, 30 gpm
........ 60812-35 ...........DLFC, 2" BSP/Metric, 35 gpm
........ 60812-45 ...........DLFC, 2" BSP/Metric, 45 gpm
........ 60812-50 ...........DLFC, 2" BSP/Metric, 50 gpm
........ 60812-55 ...........DLFC, 2" BSP/Metric, 55 gpm
........ 60812-70 ...........DLFC, 2" BSP/Metric, 70 gpm
........ 60812-75 ...........DLFC, 2" BSP/Metric, 75 gpm
........ 60812-80 ...........DLFC, 2" BSP/Metric, 80 gpm
........ 60812-90 ...........DLFC, 2" BSP/Metric, 90 gpm
........ 60812-95 ...........DLFC, 2" BSP/Metric, 95 gpm
........ 60812-100 .........DLFC, 2" BSP/Metric, 100 gpm
22 ..............2 ....... 27913-21 ...........Housing, Flow Control, 2" BSP
23 ........................ 16804 ................O-ring, -150
24 ..............1 ....... 16649 ................Holder, DLFC Button
25 ..............1 ....... 16650 ................Cover Plate DLFC
26 ..............1 ....... 13898 ................Screw, Flat HD, Phil, Steel
27 ..............6 ....... 13386 ................Screw, Hex HD MACH, 1/4-20 x
6 ....... 17976 ................Screw, Hex HD, M6 x 25 mm
28 ........................ 16529 ................Washer, Flow, 10.0 gpm
........ 16736 ................Washer, Flow, 15.0 gpm
........ 16528 ................Washer, Flow, 20.0 gpm
........ 16737 ................Washer, Flow, 25.0 gpm
29 ..............1 ....... 19089 ................Body Regulator 3150
30 ..............1 ....... 10242 ................Fitting, Nipple, 1/2", Close
31 ..............1 ....... 19091 ................Pin, Regulator 3150
32 ..............1 ....... 19093 ................Stand-Off Regulator 3150
16 • OC11 Fleck 3150 Downflow
Description
HLS
W/2 HLS
W/1 HLS
1 OR Slot Hex Cap Screw 18-8
S.S.
Item No. QTY Part No.
33 ..............1 ....... 19095 ................Diaphragm, Regulator 3150
34 ..............1 ....... 19094 ................Washer, Regulator 3150
35 ..............1 ....... 19092 ................Retainer, Regulator 3150
36 ..............1 ....... 19101 ................Spring, Regulator 3150
37 ..............1 ....... 19399 ................Washer, Calibration 3150
38 ..............1 ....... 19090 ................Cap, Regulator 3150
39 ..............1 ....... 19278 ................Fitting, Tube, 90 Deg
40 ..............1 ....... 19693 ................Pressure Gauge
41 ..............1 ....... 41232 ................Bushing Reducer 1/4 x 1/8
42 ........................ 60710-1.2 ..........BLFC, 1"F x 1"M, NPT, 1.2 gpm
........ 60710-2.0 ..........BLFC, 1"F x 1"M, NPT, 2.0 gpm
........ 60710-2.4 ..........BLFC, 1"F x 1"M, NPT, 2.4 gpm
........ 60710-3.0 ..........BLFC, 1"F x 1"M, NPT, 3.0 gpm
........ 60710-3.5 ..........BLFC, 1"F x 1"M, NPT, 3.5 gpm
........ 60710-4.0 ..........BLFC, 1"F x 1"M, NPT, 4.0 gpm
........ 60710-5.0 ..........BLFC, 1"F x 1"M, NPT, 5.0 gpm
........ 60710-7.0 ..........BLFC, 1"F x 1"M, NPT, 7.0 gpm
43 ........................ 60710-9.0 ..........BLFC, 1"F x 1"M, NPT, 9.0 gpm
........ 60710-10 ...........BLFC, 1"F x 1"M, NPT, 10 gpm
........ 60710-12 ...........BLFC, 1"F x 1"M, NPT, 12 gpm
........ 60710-15 ...........BLFC, 1"F x 1"M, NPT, 15 gpm
........ 60710-20 ...........BLFC, 1"F x 1"M, NPT, 20 gpm
........ 60710-25 ...........BLFC, 1"F x 1"M, NPT, 25 gpm
44 ........................ 16530 ................Housing, BLFC, 1"M x 1"F
45 ........................ 19292 ................O-ring, -020
46 ........................ 19279 ................Retainer, Flow Control, Flow 9.0
47 ........................ 19053 ................Retainer, Flow Control, Flow 2.0
48 ........................ 12085 ................Washer, Flow, 1.2 gpm
........ 12087 ................Washer, Flow, 2.0 gpm
........ 12088 ................Washer, Flow, 2.4 gpm
........ 12089 ................Washer, Flow, 3.0 gpm
........ 12090 ................Washer, Flow, 3.5 gpm
........ 12091 ................Washer, Flow, 4.0 gpm
........ 12092 ................Washer, Flow, 5.0 gpm
........ 12408 ................Washer, Fow, 7.0 gpm
........ 17944 ................Washer, Flow, 9.0 gpm
........ 16529 ................Washer, Flow, 10.0 gpm
........ 16735 ................Washer, Flow, 12.0 gpm
........ 16736 ................Washer, Flow, 15.0 gpm
........ 16528 ................Washer, Flow, 20.0 gpm
........ 16737 ................Washer, Flow, 25.0 gpm
49 ........................ 16738 ................Retainer,Flow Control
50 ........................ 16805 ................Ring, Retaining
Not Shown - Option Without Brine Valve
1 ....... 16605 ................Retainer Plate
1 ....... 19860 ................Fitting, Brine Valve, 1800
Description
- 25 gpm
- 7.0 gpm
