GENERAL SAFETY SPECIFICATIONS

Please read this manual in its entirety. This service information is intended for use by a qualified service techni-
cian, familiar with the proper safety and service procedures. Before repairing, replacing, or adjusting any FAST-
CORP machine components, the qualified service technician should be equipped with the proper tools and/or re-
placement components, using genuine FASTCORP factory parts.
!!WARNING!! ALL ADJUSTMENTS, ASSEMBLY, AND REPAIRS MUST BE PERFORMED IN ACCORDANCE
WITH FASTCORP INSTRUCTIONS AND SAFETY PROCEDURES. PERSONS ATTEMPTING TO SERVICE THE
MACHINE WITHOUT PROPER TRAINING MAY SUBJECT THEMSELVES TO HAZARDS SUCH AS ELECTRICAL
SHOCK, CAUSING SERIOUS INJURY OR DEATH.
ALWAYS POWER DOWN AND UNPLUG THE MACHINE WHEN SERVICING ANY AND ALL ELECTRICAL AND
MOVING COMPONENTS.
Only use a dedicated 115V 15 Amp electrical power supply with ground to power the machine. Lower volt-
age may result in vacuum related problems and/or improper coin acceptance.
!!WARNING!! TO ENSURE SAFETY AND PROPER OPERATION, THE MACHINE MUST BE PROPERLY
GROUNDED. IF THE GROUND STATUS OF AN OUTLET CANNOT BE READILY DETERMINED OR VERIFIED
BY THE FACILITY, HAVE IT CHECKED BY A LICENSED ELECTRICIAN. DO NOT REMOVE THE GROUND PIN
OR IN ANY WAY BYPASS, MODIFY, DEFEAT, OR DESTROY THE GROUNDING SYSTEM OF THE MACHINE.
EXTENSION CORDS OR POWER STRIPS MUST NOT BE USED TO SUPPLY POWER TO THE MACHINE.
Stay clear of the cabinet interior when power is on and the door is open. Moving robotic components may cause
head or body trauma if a person comes within the path of the robot. Refrain from standing inside or near the front
of an open cabinet while the robot attempts to dispense product. When vending product, the robot accelerates to-
wards the front center section of the cabinet known as the "Drop Point".
MEASUREMENT SPECIFICATIONS
General listing of Tools, Equipment and/or Supplies that May be Required When Installing or Servicing Machine
Installation or Transport:
Pallet Jack/Dolly or Forklift, Cutting Pliers, Phillips Screwdriver,
Flathead Screwdriver, 11/32" Deep Socket, 3/8" Socket, 7/16"
Socket, 1 1/2" socket , Bin Plan-O-Gram, Product with Product
Listing and Pricing, Product Cards and Price Tags, Peripheral
devices (Coin Mech.), Coins, Level, Original Transport Brack-
ets, Cable Ties, Protective Packaging Materials, Tape (low re-
sidual adhesive to secure freezer lid), Appropriate Power Sup-
ply
GENERAL
HEIGHT:
WIDTH:
DEPTH:
WEIGHT:
TRANSPORT CONSIDERATIONS
Always try to keep the FRI-Z400 in the upright position. If the machine must be laid down for delivery purposes, be
sure the machine is upright for at least 24 hours before it is plugged into an outlet and powered. This will give the
compressor fluid time to re-settle in the freezer compressor. Failure to do so can damage the compressor and
void the warranty.
Whenever the FRI-Z400 is moved or transported, always use the shipping brackets provided when the machine
was first delivered and new tie wraps. Refer to the uncrating instructions for tie wrap and shipping bracket installa-
tion.

SPECIFICATIONS

(Refer to manual for details under each specific heading)
72.0 in./182.9 cm.
37.0 in./93.98 cm.
36.0 in./91.44 cm.
604-lbs./273.97 kg.
Maintenance & Troubleshooting:
Cutting Pliers, Phillips Screwdriver, Flathead Screwdriver, Needle
Nose Pliers, 11/32" Deep Socket, 3/8" Socket, 7/16" Socket, 1/4"
Socket, 7/64" Allen Wrench w/ 8" T-handle, Bin Plan-O-Gram,
Product Listing and Pricing, Volt Meter, Replacement Parts and
Corresponding Tools, 15 Amp Fuses
ELECTRICAL
VOLTAGE: 110-115 A/C
FREQUENCY: 60 Hz
AMPERAGE: 8.9 Amps.
AMP DRAW: 2.5 Amps resting /9 Amps operating
A-1
