TaiShan 200 Server
White Paper (Model 2180)
Issue
02
Date
2020-06-22
HUAWEI TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading

Related Manuals for Huawei TaiShan 200

Summary of Contents for Huawei TaiShan 200

  • Page 1 TaiShan 200 Server White Paper (Model 2180) Issue Date 2020-06-22 HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...

  • Page 3: Table Of Contents

    6 Software and Hardware Compatibility................26 6.1 CPU......................................26 6.2 Memory....................................27 6.3 Storage..................................... 30 6.4 I/O Expansion..................................31 6.5 PSU......................................31 7 System Management......................33 8 Maintenance and Warranty....................35 9 Certifications.......................... 36 Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.

  • Page 4: Overview

    White Paper (Model 2180) 1 Overview Overview The TaiShan 200 server powered by Huawei Kunpeng 920 processors is dedicated for data centers. Its 2180 balanced model (2180 for short) is a 2U single-socket rack server. It features high-performance computing, large-capacity storage, low power consumption, easy management, and easy deployment and is ideal for Internet, distributed storage, cloud computing, Big Data, and enterprise services.

  • Page 5: Features

    This simplifies maintenance, accelerates troubleshooting, and improves system availability. ● The Huawei intelligent baseboard management controller (iBMC) monitors system parameters in real time, triggers alarms, and performs recovery actions in case of failures. This helps minimize system downtime.
  • Page 6 ● Drives can be powered on at different times to reduce startup power consumption. ● The 2180 supports SSDs. SSDs consume 80% less power than HDDs. Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.

  • Page 7: Logical Structure

    2180. Figure 3-1 2180 logical structure ● The 2180 uses one Huawei-developed Kunpeng 920 processor, each supporting 16 DDR4 DIMMs. ● The Ethernet FlexIO can only be cards with four GE ports, and are connected to CPU through high-speed SerDes interfaces.
  • Page 8 The screw-in RAID controller card connects to the CPU through PCIe buses, and to the drive backplanes through SAS signal cables. ● The iBMC is based on the Huawei Hi1710 management chip and provides a VGA port, management network port, and debugging serial port. Issue 02 (2020-06-22)

  • Page 9: Hardware Description

    12 x 3.5- inch drives. Figure 4-1 Components on the front panel of a server with 12 x 3.5-inch drives Drive VGA port USB 3.0 port Label plate with an SN label Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.
  • Page 10 You are advised to use the VGA port on the rear panel. The serial number (SN) on the label is a string that uniquely identifies a server. The SN is required when you contact Huawei technical support. Figure 4-2 shows the SN format.
  • Page 11 Figure 4-3 Rear panel components I/O module 1 I/O module 2 Power supply unit (PSU) 1 PSU 2 PSU socket USB 3.0 port VGA port Serial port Management network port FlexIO Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.
  • Page 12 PSUs is greater than that of the server. You are advised to configure two PSUs to ensure reliable device operating. When one PSU is used, Predicted PSU Status cannot be set to Active/Standby on the iBMC WebUI. Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.

  • Page 13: Indicators And Buttons

    State Description Fault diagnostic ● ---: The server is operating normally. ● Error code: A server component is faulty. For details about error code, see the TaiShan Rack Server iBMC Alarm Handling Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.
  • Page 14 ● You can press this button to turn on or off the UID indicator. ● You can press and hold down this button for about 5 seconds to reset the iBMC. Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.
  • Page 15 Table 4-5 Indicators on the rear panel Indicator State Description Data transmission ● Blinking yellow: Data is being electrical status indicator transmitted. port/ ● Off: No data is being transmitted. Managem Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.
  • Page 16 ● Blinking green at 4 Hz: under online PSU firmware upgrade. ● Off: No power is supplied. SAS/SATA Drive Indicators Figure 4-6 shows the SAS/SATA drive indicators. Figure 4-6 SAS/SATA drive indicators Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.
  • Page 17 GE electrical ports status indicator transmitted. ● Off: No data is being transmitted. Connection status ● Steady green: The network port is indicator properly connected. ● Off: The network port is not connected. Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.

  • Page 18: Riser Cards And Pcie Slots

    ● The card must be used together with the power cables delivered with the server. Do not use the power cables of other servers. ● Only slots 2 supports full-height full-length dual-width GPUs. Figure 4-9 Riser card 2 (one x8 slot and one x16 slot) Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.
  • Page 19 When a two-slot PRM is installed in I/O module 1, slot 1 cannot be used. ● When one-slot PRM is installed in I/O module 1, slots 1 and 2 cannot be used. Table 4-8 describes specifications of the PCIe slots. Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.
  • Page 20 Slot PCIe x16 ● Single- Port 00/0C/ 04/00/ Full- slot PRM: height half- length ● 2-slot PRM: x8 ● 3-slot PRM: x8 RAID PCIe Port 8 00/08/ 03/00/ contr oller card Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.

  • Page 21: Physical Structure

    Compatibility Checker. For PCIe cards not listed by the Intelligent Computing Compatibility Checker, contact the local Huawei sales personnel to submit the compatibility test requirements. ● When two 2.5-inch drives are installed in I/O module 1, this module also supports a PCIe x16 riser card in slot 3.
  • Page 22 2.5- or 3.5-inch drives. I/O module 3 cannot be used. ● The FlexIO can be configured with a TM210 NIC. ● CPU is integrated on the mainboard and cannot be replaced independently. Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.

  • Page 23: Product Specifications

    DIMMs of different specifications (such as the capacity, bit width, rank, and height) cannot be installed on one server. That is, all DIMMs on one server must have the same Part No.. Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.
  • Page 24 PCIe 4.0 x16 slot (width: PCIe 4.0 x8) – One full-height half-length PCIe 4.0 x16 slot ● The PCIe slots support Huawei-developed Atlas 300 AI accelerator cards to implement fast and efficient processing and reasoning, and image identification and processing.

  • Page 25: Environmental Specifications

    ● Storage humidity (≤ 72 hours): 5% to 95% (RH, ● Long-term storage humidity (> 72 hours): 30% to 69% non- ● Maximum change rate: 20%/h condensi ≥ 204 cubic feet per minute (CFM) volume Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.
  • Page 26 – LWAd: 6.08 Bels – LpAm: 45.2 dBA ● Operating: – LWAd: 7.0 Bels – LpAm: 53 dBA NOTE Actual sound levels generated during operation vary depending on server configuration, load, and ambient temperature. Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.

  • Page 27: Physical Specifications

    ● Cabinet depth: ≥ 1000 mm (39.37 in.) Requirements for guide rail installation: ● L-shaped guide rails: apply only to Huawei cabinets. ● Adjustable guide rails: apply to a cabinet with a distance of 543.5 mm to 848.5 mm (21.40 in. to 33.41 in.) between the front and rear mounting bars.
  • Page 28 The power consumption parameters vary according to consump configurations (including the ErP standard configuration of the tion European Union). Use the Intelligent Computing Product Power Calculator to obtain the specific power consumption value. Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.

  • Page 29: Software And Hardware Compatibility

    Each core integrates 64 KB L1 instruction cache, 64 KB L1 data cache, and 512 KB L2 cache. ● An L3 cache of up to 64 MB. ● Superscalar, variable-length, and out-of-order pipelines. ● One-bit and two-bit ECC error correction. Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.

  • Page 30: Memory

    ● DIMMs of different specifications (such as capacity, bit width, rank, and height) cannot be mixed on one server. That is, a server must use DIMMs of the same Part No.. Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.
  • Page 31 Table 6-2 Channels Channel DIMM TB_A DIMM060(G) DIMM061(O) TB_B DIMM020(C) DIMM021(K) TB_C DIMM040(E) DIMM041(M) TB_D DIMM000(A) DIMM001(I) TA_A DIMM030(D) DIMM031(L) TA_B DIMM070(H) DIMM071(P) TA_C DIMM010(B) DIMM011(J) TA_D DIMM050(F) DIMM051(N) Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.
  • Page 32 Huawei Server Product Memory Configuration Assistant. Install dummy DIMMs in vacant DIMM slots. Memory Protection The server supports the following memory protection technologies: ● ● SEC/DED ● SDDC ● Patrol scrubbing Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.

  • Page 33: Storage

    6 Software and Hardware Compatibility Supported DIMMs ● For details about component options, consult your local Huawei sales representative. ● DIMMs on one server must be of the same model, type (RDIMM or LRDIMM), and specifications (capacity, bit width, number of ranks, and height).

  • Page 34: I/O Expansion

    Fiber Channel (FC) host bus adapter (HBA) ● InfiniBand (IB) expansion card ● SSD card For details about component options, consult your local Huawei sales representative. 6.5 PSU ● The PSUs are hot-swappable and work in 1+1 redundancy mode. ●...
  • Page 35 ● If the input voltage ranges from 200 V to 220 V AC, the output power of the 2000 W AC platinum PSU decreases to 1800 W. Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.

  • Page 36: System Management

    White Paper (Model 2180) 7 System Management System Management The 2180 uses Huawei's proprietary intelligent baseboard management controller (iBMC) for remote server management. The iBMC complies with IPMI V2.0 standards and provides reliable hardware monitoring and management. The iBMC supports the following features and protocols: ●...
  • Page 37 Dual-image Starts software from a backup image if the software fails. backup Asset Provides intelligent asset management. management IPv6 Supports IPv6 to ensure sufficient IP addresses. Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.

  • Page 38: Maintenance And Warranty

    TaiShan 200 Server White Paper (Model 2180) 8 Maintenance and Warranty Maintenance and Warranty For details, see Maintenance & Warranty. Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.

  • Page 39: Certifications

    TaiShan 200 Server White Paper (Model 2180) 9 Certifications Certifications Country/ Certification Standard Region China GB4943.1-2011 GB9254-2008 (Class A) GB17625.1-2012 China CQC3135-2011 Issue 02 (2020-06-22) Copyright © Huawei Technologies Co., Ltd.
