ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7195V-1/2/3/4
DIFFICULT
Tools Required For Assembly:
Allen Wrench
2 PERSONS RECOMMENDED
Page 1 of 5
(Included)
Rev: 18-0 4 - 03
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7195V-1
Summary of Contents for Furniture of America CM7195V-1
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7195V-1/2/3/4 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Allen Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 2pcs #A x 16pcs Dresser Left/Right Bolt Ø1/4"x1-3/8" #2 x 1pc #B x 8pcs Bolt Ø1/4"x6/8"...
- Page 4 Exploded View #3 R #3 L 50x10mm Extend middle drawer (#2) fully out, then align the holes of the middle drawer (#2) to the dressers (#1L/R). Secure by going underneath dresser center (#2) and using bolts (#E) with washers (#F,G). #E x 8pcs #F x 8pcs #G x 8pcs...
- Page 5 Align mirror supports (#5) to the holes of the mirror (#3) and dressers (#1R/L). Secure by using bolts (#A) with washers (#C,D) #3 L #A x 16pcs #C x 16pcs #D x 16pcs #3 R Align mirror center (#4) to the holes of the mirror (#3), then align batches (#I) to the holes of the mirror (#3,4).
