- Page 4 Prepare 10 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align headboard (#1) and headboard support (#5) to the holes of the headboard legs (#2R/L), then secure with bolts (#A). Attach threaded pins (#F) to the holes of the headboard (#1) and footboard (#3). Align the side rails (#4) to the threaded pins (#F) that are attached to headboard (#1) and footboard (#3).
- Page 5 Attach support legs (#7) to each slats (#6). Adjust adjustable foot on the support legs (#7) according to ground level. Align slats (#6) to the side rails (#4), then secure with screws (#E).
- Page 9 Prepare 10 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align headboard (#1) and headboard support (#5) to the holes of the headboard legs (#2R/L), then secure with bolts (#A). Attach threaded pins (#F) to the holes of the headboard (#1) and footboard (#3). Align the side rails (#4) to the threaded pins (#F) that are attached to headboard (#1) and footboard (#3).
- Page 10 Attach support legs (#7) to each slats (#6). Adjust adjustable foot on the support legs (#7) according to ground level. Align slats (#6) to the side rails (#4), then secure with screws (#E).
