What's in the Box
Thumb-Rollers
Hardware
B
D
E
(8)
x
Included in your
Radio Motor box
Thumb-Roller Quick Start Guide
A
C
Optional hardware
(2)
x
x(2) x(4) x(2)
Refer to the user manual included in your motor box or on our website for more comprehensive instructions.
Modern Sound For Your Classic
tech@retromanufacturing.com | help.retromanufacturing.com
Installation
D
B
C
Attach each InfiniMount
Bracket to the Radio Motor
with the eight small screws.
E
Complete the installation by plugging one end of the modular
cable into the left Thumb-Roller and the other end of the modular
cable into the left side of the Radio Motor. Then, repeat for the
right Thumb-Roller on the right side. Use the optional hardware if
needed to help mount the radio to the dash.
D
A
Insert the Thumb-Rollers into the InfiniMount
Brackets. Gently push to snap into place.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for RetroSound Redonodo
Summary of Contents for RetroSound Redonodo
- Page 1 Thumb-Roller Quick Start Guide What’s in the Box Installation Thumb-Rollers Attach each InfiniMount Bracket to the Radio Motor Insert the Thumb-Rollers into the InfiniMount with the eight small screws. Brackets. Gently push to snap into place. Hardware Optional hardware Complete the installation by plugging one end of the modular cable into the left Thumb-Roller and the other end of the modular cable into the left side of the Radio Motor.
- Page 2 PANEL mode. While holding the Thumb-Roller the unit will display the following sequence: minutes. Rotate the Right-Outside Thumb-Roller( ) up or down to adjust the minutes. Let the unit RETROSOUND>RADIO>GOODBYE>SEL PANEL. Once SEL PANEL is displayed, press time out to setup . and release the Left-Outside Thumb-Roller(...
