What's in the Box
10
Control Shaft
A
(2)
x
Hardware
B
E
D
(8)
x
Included in your
(8)
x
Radio Motor box
Control Shaft Quick Start Guide
C
F
Optional hardware
(10)
x
x(2) x(4) x(2)
Refer to the user manual included in your motor box or on our website for more comprehensive instructions.
Modern Sound For Your Classic
tech@retromanufacturing.com | help.retromanufacturing.com
Installation
D
B
Attach each InfiniMount
C
Bracket to the Radio Motor
with the eight small screws.
F
E
To complete the installation secure each Control Shaft with a Shaft Nut
and Shaft Washer then plug each shaft into the side of the Radio Motor.
Use the optional hardware if needed to help mount the radio to the dash.
F
E
D
Place a Shaft Nut and Shaft Washer onto each
Control Shaft before inserting them into the
InfiniMount Brackets. The Control Shaft depth and
height can be adjusted as needed.
A
