ASSEMBLY INSTRUCTION
INSTRUCTION D' ASSEMBLAGE
Thank you for purchasing this product. Please take time to read and follow the instructions below. Check that you have all parts and hardware
before assembly. Parts apparently missing are often found in the packing materials. If you do not have all the parts listed, call us and they will be
sent to you immediately. Should parts be damaged during transportation, give us a call and we will replace the damaged part as soon as possible.
Merci d'avoir achete ce produit de qualite. Veuillez lire et suivre les instructions ci-dessous. Verifiez avant le montage que vous avez toutes les
pieces et fixations. Les pieces qui semblent manquer se trouvent souvent dans les materiaux d'emballage. Si vous n'avez pas toutes les pieces
de la liste, appelez-nous et nous vous le enverrons immediatement. Si des p eces soient endommagees pendant le transport, appelez-nous et
nous remplacerons aussi tot que possible la piece endommagee.
PARTS LIST / LISTE DE PIECES
A
Table top / Dessus de Table
B
Leg B / Pied B
C
Leg C / Pied C
D
Leg D / Pied E
E
Leg E / Pied E
F
Top Shelf / Étagère Supérieure
G
Bottom Shelf / Étagère Bas
H
Drawer frame / Cadres Tiroir
I
Drawer I / Tiroir I
J
Drawer J / Tiroir J
K
Metal Bar / Barre De Métal
A
B
C
NE PAS SERRER LES BOULONS JUSQU'A CE QUE LE MONTAGE SOIT COMPLETMENT TERMINE
STEP 1 / ÉTAPE 1
C
C
A
It is recommended to install protective pads under all legs and supports to avoid damage or scratches when placing furniture on a
wood floor or other hard surface, and to limit indentation and prevent discoloration if placing on carpet .
Il est recommande de placer des coussins protecteurs sous tous les pieds et toutes les bases des meubles pour eviter d'endommager
ou d'egratigner les planchers en bois ou autres surfaces dures, et pour limiter l'empreinte et empecher la decoloration quand les
meubles reposent sur la moquette.
1
2
2
1
1
1
1
1
1
1
2
D
E
F
DO NOT TIGHTEN BOLTS UNTIL COMPLETELY ASSEMBLED.
7
6
4
9
B
Counter Height Table - Table de hauteur comptoir
HARDWARE LIST / LISTE DE QUINCAILERIE
1
Bolt / Boulon 1/4'' x 45mm
2
Lock Washer / Rondelle d'arret 1/4''
3
Flat Washer / Rondelle Plate 1/4'' x 16mm
4
Bolt / Boulon 5/16'' x 55mm
5
Bolt / Boulon 5/16'' x 45mm
6
Lock Washer / Rondelle d'arret 5/16''
7
Flat Washer / Rondelle Plate 5/16'' x 19mm
8
Screws/ Vis #3.5 x 20mm
9
Allen Key / Clè Allen M4
G
H
STEP 2 / ÉTAPE 2
B
ITEM : 5772-36/5772-36B
4
4
4
20
2
22
22
4
1
J
I
K
H
